  • Page 1 15" Liquid Crystal Display Television User's Manual MAK-000026...

  • Page 2: Table Of Contents

    1.2.2 Control Panel ... 16 1.2.3 Input and Output Jacks ... 17 1.2.4 Remote Control ... 18 1.2.5 Inserting the Remote Control Batteries ... 21 Setting up your TV ... 23 Basic Connections... 23 2.1.1 Power Connection ... 23 2.1.2 Antenna/Cable Connections ... 24 Connecting External Devices ...
  • Page 3 Menu Setting ... 32 TV mode ... 34 3.1.1 Picture Setting ... 34 3.1.2 Audio Setting ... 37 3.1.3 TV Setting ... 39 3.1.4 Parental Control Setting(available in U.S. only) 44 3.1.5 Customize Setting ... 50 PC Mode... 52 3.2.1 Picture Setting ... 52 3.2.2 Audio Setting ...

  • Page 4: Regulatory Information

    Consult the dealer or an experienced radio/TV technician for help WARNING: The Federal Communications Commission warns that changes or modifications of the TV not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

  • Page 5: Description Of Warning Symbols

    TV on. 1. Keep this User’s Manual in a safe place for future reference. Keep the box and packaging in case the TV needs to be shipped in the future. 2. Follow the TV and warning label instructions.

  • Page 6: Safety Notices

    Electric power may cause personal injury and mechanical damage if misused. Although safety has been taken into consideration during the design and production of this TV, electric shock or fire can result if the TV is misused. To prevent potential danger, read and follow the instructions and warnings contained in this manual when setting up, operating or cleaning the TV.
  • Page 7 Antenna We suggest that you use an outdoor antenna to get the best signal possible unless you have cable TV or a centralized indoor antenna system. You may, however, use an antenna indoors if it is placed in a location free from interference.

  • Page 8: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 9 CAUTION 10 Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11 Only use attachments/accessories specified by the manufacturer. 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
  • Page 10 If any fluid is sprayed or dropped into the TV, contact an authorized service technician. The screen of the TV is made of glass. Avoid hitting or scraping it. If the screen is broken, do not touch the broken glass.
  • Page 11 Do not place the TV in locations where there is excessive steam or dust. Avoid blocking the TV's vents, do not place the TV on a bed, sofa, carpet, or in a sealed cabinet. Install the outdoor antenna (not included) away from power transmission lines to avoid possible danger.
  • Page 12 Do not attempt any methods not covered in this manual. Do not attempt to repair the TV by yourself. Contact an authorized service technician. Ask the service technician to complete a safety inspection before switching the power on after completing any maintenance.

  • Page 13: Preface

    Preface Thank you for purchasing a Hannspree Liquid Crystal Display Television Preface (LCD TV). Your new TV allows you to enjoy superior audio and video while enriching your lifestyle with advanced technology. Please carefully read this manual in its entirety before setting up, using or operating your TV.
  • Page 14 Hannspree (or of other third parties). The Hannspree logos presented herein are trademarks of Hannspree. All...

  • Page 15: Getting Started

    Getting Started Package Contents Getting Started Please make sure your package coming with the following items. If any item is found missing or damaged, contact Hannspree Customer Service Center immediately. • • User's manual • Quick start guide • Warranty and service manual •...

  • Page 16: Product Introductions

    1.2.1 Features This LCD TV allows viewers to watch NTSC/PAL television channels, and easily connect a VCR, VCD, or DVD player to the standard Video and S- Video input ports located at the rear of the unit. Moreover, you may connect your LCD TV to a PC, serving as a monitor.

  • Page 17: Control Panel

    OSD menu. Volume DOWN decreases the volume or moves to the left on the OSD menu. Under TV mode, press the button to eliminate the sound. Press it again or press the volume adjust buttons directly to restore sound.

  • Page 18: Input And Output Jacks

    1.2.3 Input and Output Jacks Description Connector - DC-IN Power connector - DC 12V Video & R/L/Video Audio connector Video & - AV2 Audio - AV In Connector Audio output Line Out Audio input Line In VGA/PC IN Antenna Earphone Earphone Function Connect to the included power adapter.

  • Page 19: Remote Control

    1.2.4 Remote Control Description Icon Menu/Enter (Enter: not Menu/ for all remote Enter control) Arrow </> Number Last/Recall (not for all Last/ remote Recall control) (not for all remote caption control) Display Display Function Turn the on-screen display (OSD) menu on and off/ confirm your selection or setting.
  • Page 20 Press this button to eliminate sound. Press it again or press the volume adjust buttons to restore sound. Press this button repeatedly to set the TV timer(30, 60, 90, or 120 minutes). A timer appears on the top right corner of the screen to show the time remaining.
  • Page 21 Description Icon Parental (available in U.S. only/ Parental not for all remote control)) Auto (not for all AUTO remote control) Reset (not for all RESET remote control) Function Open the parental setup menu.This button allows you to change parental settings. Under PC mode, press to adjust H.

  • Page 22: Inserting The Remote Control Batteries

    1.2.5 Inserting the Remote Control Batteries 1. Open the battery compartment cover at the back of the remote control (A). 2. For AAA batteries, insert the batteries paying attention to the polarity markings inside the battery compartment (B). For lithium batteries, insert the battery/batteries with the positive side (+) facing up (B).
  • Page 23 CAUTION • If the remote control is not used for a long period, remove the batteries and store them separately. • Handle damaged or leaking batteries carefully, and wash hands after such handling. • Refer to your local recycling or waste disposal rules and contact a local waste disposal vendor to dispose of used batteries.

  • Page 24: Setting Up Your Tv

    Setting up your TV Setting up your TV Basic Connections The following sections provide users with some basic instructions to use the TV. Please read them carefully before you start utilizing the functions. 2.1.1 Power Connection DC-IN Power adapter 1 Connect the power cord to the power adapter as illustrated.

  • Page 25: Antenna/Cable Connections

    2 Connect the other end of the VHF/UHF (Antenna) or CATV cable to the antenna or CATV socket. Note: If you cannot receive channels after connecting to an antenna or cable TV line, try scanning for channels (please refer to “TV Setting” on page 39). Antenna Antenna/...

  • Page 26: Connecting External Devices

    Connecting External Devices 2.2.1 Connecting to Earphones Earphone jack You may use earphones instead of built-in speakers to listen to the TV. Connect earphones to the earphone line out port as illustrated. Note: • Earphones are not included in the package.

  • Page 27: Connecting To An Amplifier/Powered Speaker

    2.2.2 Connecting to an Amplifier/Powered Speaker Amplifier LINE OUT Speakers (Built-in amplifier) Connect an external amplifier or powered speakers to the line out port to provide better sound quality. Refer to the above illustration. Note: Only one external device for sound can be connected at a time.

  • Page 28: Connecting To Av Devices

    AV 2 4-IN-1 AV cable The above illustration shows you how to connect your TV to a video camera, VCR, VCD or DVD player. Actual connections may vary according to the make and model of your device. Refer to the user's manual included with the AV device for more detailed instructions.

  • Page 29: Connecting To A Pc

    2.2.4 Connecting to a PC For VGA Jack LINE-IN VGA Cable LINE-OUT For PC-IN Jack PC-IN LINE-OUT PC Link Cable The above illustrations demonstrate how to connect to a PC. For VGA jack, please refer to the first picture. For PC-IN jack, please refer to the second picture.

  • Page 30: Connecting To A Video Game Console

    2.2.5 Connecting to a Video Game Console The instructions presented here are a general guide to connecting the TV to a game console using the RCA jacks (some game devices may require a unique adapter that is not provided.) Actual connections may vary according to the make and model of the game device.

  • Page 31: Basic Operations

    Power on/off Press the POWER button on the remote control or control panel to turn on the TV. Press the POWER button again; the TV is in off mode. 2.3.2 Switching Source Signals Press the SOURCE button to select different souce signals. The selected source signal appears on the top right corner of the screen.

  • Page 32: Using The Remote Control

    2.3.6 Using the Remote Control Aim the transmitter on the remote control at the remote IR sensor of the TV and ensure that there is no obstacle between them. The operational distance may be shortened when the remote IR sensor is directly exposed to strong light.

  • Page 33: Menu Setting

    This Chapter guides you through adjusting the On-Screen Display (OSD) Menu Setting menu system under TV and PC mode. You may adjust the setting from your remote control or the buttons located on the TV's front control panel. TV & Remote Control button...
  • Page 34 The following menus can be set by different adjustment methods. Adjustment methods are described after function description of each setting's menu. URRENT TV or PC Display the setting/value of the adjustable items. Video Mode Brightness Contrast...

  • Page 35: Tv Mode

    TV mode 3.1.1 Picture Setting PICTURE Enter： Function Description: Video mode Standard Video Mode Brightness Contrast Sharpness Saturation Color Temp Neutral Preset Select： The Video mode enables you to customize the video display. The following options are: Standard: Set the display for normal viewing (default).
  • Page 36 Brightness is the quality where a source appears to emit a given amount of light.The Brightness brightness ranges from 0 to 50. The default value is 25. Contrast is the difference in visual properties between the brightest and the darkest.The Contrast contrast ranges from 0 to 50.
  • Page 37 Adjustment (Picture setting) 1 Press Menu key to display the OSD Main Menu. 2 Go to Picture setting by pressing CH UP or CH DOWN and confirm by pressing VOL UP. For Video Mode and Color Temp 3 Go to (Video Mode or Color Temp) by pressing CH UP or CH DOWN. 4 Press VOL DOWN or VOL UP to navigate through available options.

  • Page 38: Audio Setting

    3.1.2 Audio Setting AUDIO Enter： Function Description: Treble Bass Balance Treble Bass Balance SRS WOW Preset Select： Treble allows you to adjust high sound tones. The treble ranges from 0 to 50. The default value is 25. Bass allows you to adjust low sound tones. The bass ranges from 0 to 50.
  • Page 39 SRS WOW Preset Adjustment (Audio setting) 1 Press Menu key to display the OSD Main Menu. 2 Go to Audio setting by pressing CH UP or CH DOWN and confirm by pressing VOL UP. For Treble, Bass, and Balance 3 Go to (Treble, Bass or Balance) by pressing CH UP or CH DOWN. 4 Press VOL UP or VOL DOWN to change the value.

  • Page 40: Tv Setting

    Channel Add/Erase Channel Skip Favorite CH.Edit Select： TV system allows you to select the one avaiable system in your region. Cycle through NTSC M, PAL B/G, PAL I/I, and PAL D/K. Select TV or cable TV channels. Cycle through TV and CATV. This feature is for NTSC only.
  • Page 41 Favorite CH. Edit Adjustment (TV setting) 1 Press Menu key to display the OSD Main Menu. 2 Go to TV setting by pressing CH UP or CH DOWN and confirm by pressing VOL UP. For TV System, TV/CATV 3 Go to (TV System or TV/CATV) by pressing CH UP or CH DOWN.
  • Page 42 For Channel Skip 3 Go to Channel Skip by pressing CH UP or CH DOWN and confirm by pressing VOL UP. The screen displays the following adjustment box: Channel Skip Adjust： 4 Press CH UP or DOWN to select a channel to be skipped. 5 Press VOL UP or VOL DOWN to turn on/off the function.
  • Page 43 6 Press MENU key to confirm and return to Main menu. For Channel Add/Erase 3 Go to Channel Add/Erase and press VOL UP to confirm. The screen displays the following adjustment box: Channel Add/Erase 4 Press CH UP or CH DOWN to select a channel. Press VOL UP or VOL DOWN to add or erase channels.
  • Page 44 4 Press CH UP or CH DOWN to select the favorite channel to be edited (Favorite 1 to Favorite 4). 5 Press VOL UP once to set the currently viewed channel as your favorite channel or press VOL UP or VOL DOWN again to select a channel other than the currently viewed channel.

  • Page 45: Parental Control Setting(Available In U.s. Only)

    Movie ratings are used for original movies rated by the Motion Picture Association of America (MPAA) as watched on cable TV and not edited for television. The Parental Control Function can also be set to block MPAA-rated movies.

  • Page 46: Function Description

    If the wrong password is entered, "Wrong Password" displays on the screen. • TV Rating and Movie Rating are available when the Rating is set to Custom. The feature allows parents to lock certain programs that are unappropriate for children.
  • Page 47 Selecting Custom under Rating menu allows you to adjust the following items including TV Rating, Movie Rating. For TV Rating 3 Go to TV rating by pressing CH UP or CH DOWN and VOL UP to confirm. A box pops out: TV Rating Adjust：...
  • Page 48 For Movie Rating 3 Go to Movie Rating by pressing CH UP or CH DOWN and VOL UP to confirm. A box pops out: Movie Rating Adjust： 4 Press CH UP or CH DOWN to move the cursor. 5 Press VOL UP or VOL DOWN to lock or unlock the highlighted item . 6 Press Menu key to return to Main Menu.
  • Page 49 Ratings MPAA Ratings PG-13 NC-17 MPAA Ratings allow you to block or unblock broadcast programs based on their movie ratings. Suitable for a general audience, all children Parental guidance suggested Parental guidance for children under 13 suggested Restricted viewing. Parental guidance suggested for children under 17 No one under 17 is allowed to view Adults only...
  • Page 50 • More information about the rating system can be found by visiting these websites: http://www.mpaa.org, http//www.tvguidelines.org The TV rating menu allows you to block or unblock braodcast programs based on their TV rating. Suitable for a general audience, all children...

  • Page 51: Customize Setting

    CC/TEXT Preset Color System Select： Sleep time allows the TV to be turned off automatically after a certain period of time. Cycle to the desired sleep time: 30min., 60 min., 90min., 120min., or off. Set the duration before the OSD disppears from the screen.
  • Page 52 4 Press VOL UP or VOL DOWN to execute Preset function. 5 Press Menu key to return to Main Menu. C.C Text is the enclosed captioning text included with TV programs as they air. Cycle to the desired mode: Off, CC1-CC4, TEXT1- TEXT4, and XDS.

  • Page 53: Pc Mode

    Picture Setting The setting provides four options: Brightness, Contrast, Color Temp and Preset. Please refer to 3.1.1 for detailed description. Note: Make sure the TV's power cord is plugged in before turning on the PC. 3.2.2 Audio Setting The Audio setting provides four options: Treble, Bass, Balance, and Preset.
  • Page 54 Function Description: H. Position V. Position Phase Clock DOS Mode The option allows users to adjust the horizontal position of the screen. The H position ranges from -25~25. The default value is 0. The option allows users to adjust the vertical position of the screen.

  • Page 55: Customize Setting

    Adjustment (Image setting) 1 Press Menu key to display the OSD Main Menu. 2 Go to Image setting by pressing CH UP or CH DOWN and confirm by pressing VOL UP. For H. Position, V. Position, Phase, and Clock 3 Go to (H. Position, V. Position, Phase, or Clock) setting by pressing CH UP or CH DOWN and VOL UP to confirm.

  • Page 56: Technical Information

    For best results, use a clean lens cloth to remove dust and fingerprints from the screen. Do not wipe the shell of the TV with alcohol, methanol, gasoline or oil products to avoid damaging the finish. Wipe the shell with a dry soft cloth and use neutral cleaning fluids.

  • Page 57: Troubleshooting

    Press the SOURCE key to cycle through connected video sources. • Press CH UP or CH DOWN to switch to other TV stations. • Check the TV/CATV OSD settings. • Make sure all cables are connected properly. • Check the antenna and cable connections. •...
  • Page 58 Turn the mute off. Adjust the balance in the OSD menus. Make sure the audio cable is connected properly. Try the Auto Program function in the OSD TV Setting menu. Use the Preset function in the OSD Picture and Audio menu.
  • Page 59 Make sure the TV power cord is plugged in. • Make sure the path between the remote control and the remote IR sensor is clear. • Try operate the remote control at a closer distance to the TV. Refer to 2.3.1 on page 30.

  • Page 60: Specifications

    Specifications LCD Panel Size Aspect Ratio Display Resolution Maximum Display Area TV System Video System Audio System Built-in Stereo Audio Amplifier Power Supply Power Consumption 15-inch TFT 1024 (horizontal) x 768 (vertical) 304.1 mm (H) x 228.1 mm (V) NTSC M, PAL B/G, PAL I/I, PAL D/K...

  • Page 61: Pc Mode Support Timing

    PC Mode Support Timing Pixel Hor. Freq. Format (kHz) 640*400 31.47 720*400 31.47 640*480 31.47 640*480 37.861 640*480 37.5 800*600 35.156 800*600 37.879 800*600 48.077 800*600 46.875 10 1024*768 48.363 11 1024*768 56.476 12 1024*768 60.023 832*624 49.7 14 1024*768 60.2 640*480 V.

  • Page 62: Warranty And Service

    Warranty and Service For complete warranty service informaiton, please refer to the “Warranty Warranty and Service and Service Manual” enclosed with your TV.

  • Page 63: Appendix A. Glossary

    (standard TV broadcast). CATV: Community Antenna Television, the original name for cable TV. A television distribution system that uses coaxial cable instead of the traditional radio broadcasting (over-the-air) method to deliver television, FM radio and other services to consumers.
  • Page 64 is a trademark of SRS Labs, Inc. WOW technology is incorporated under license from SRS Labs, Inc.
  • Page 65 MEMO...
