MODEL G0472/G0473/G0476
SANDBLASTING CABINET
OWNER'S MANUAL
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the G0472 and is the answer not in the manual?

Questions and answers

Related Manuals for Grizzly G0472

Summary of Contents for Grizzly G0472

  • Page 1 MODEL G0472/G0473/G0476 SANDBLASTING CABINET OWNER'S MANUAL WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........................2 SECTION 1: SAFETY ........................4 SECTION 2: SET UP ........................7 SECTION 3: OPERATIONS ......................11 SECTION 4: PARTS ........................14 WARRANTY AND RETURNS ......................20...

  • Page 4: Introduction

    INTRODUCTION Manual Accuracy Contact Info your machine may not exactly match the manual www.grizzly.com...
  • Page 5 MACHINE DATA Machine Data Sheet SHEET MODEL G0472 SANDBLASTING CABINET General Specifications: MODEL G0473 SANDBLASTING CABINET General Specifications: MODEL G0476 SANDBLASTING CABINET General Specifications: Specifications, while deemed accurate, are not guaranteed.

  • Page 6: Section 1: Safety

    SECTION 1: SAFETY For Your Own Safety, Read Instruction Manual Before Operating this Machine The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words intended to convey the level of importance of the safety messages.

  • Page 7: Safety Instructions For Machinery

    Safety Instructions for Machinery DISCONNECTING POWER SUPPLY. APPROVED OPERATION. INTENDED USE. CHILDREN & BYSTANDERS. STABLE MACHINE. FEED DIRECTION. SECURING WORKPIECE. FORCING MACHINERY. GUARDS & COVERS. UNATTENDED OPERATION. MAINTENANCE & INSPECTION. REMOVING TOOLS. AWKWARD POSITIONS. EXPERIENCING DIFFICULTIES. DANGEROUS ENVIRONMENTS.
  • Page 8 Additional Safety Instructions for Sandblasters CORRECT ABRASIVES. 8. MAINTAINING MACHINE. 9. SAFE SANDBLASTING. 2. PROTECTING LUNGS. 3. LEAVING THE AREA. 10. CORRECT LIGHTING. 4. PROTECTING EYES. 11. LOADING & UNLOADING. 5. PROTECTING ENVIRONMENT. 12. SAFE MAINTENANCE. 6. WORK AREA SAFETY. MAINTAINING COMPONENTS.

  • Page 9: Section 2: Set Up

    SECTION 2: SET UP Unpacking Set Up Safety This machine presents please immediately call Customer serious injury hazards Service at (570) 546-9663 for advice. to untrained users. Read through this entire manu- al to become familiar with the controls and opera- Otherwise, filing a freight claim can be difficult.
  • Page 10 G0472 Assembly Figure 4 To assemble the sandblaster: Figure 1 Figure 4. Figure 1. Figure 5 Figure 2 Figure 5. Figure 2. Figure 3 Figure 3.
  • Page 11 G0473 Assembly To assemble the sandblaster: Figure 3 Figure 1 Figure 1. Figure 3. Figure 2 Figure 4 Figure 4. Figure 2.
  • Page 12 G0476 Assembly Figure 5 To assemble the sandblaster: Figure 1 Figure 5. Figure 6 Figure 1. Figure 2 Figure 5. Figure 2. Figure 7 Figure 3 Figure 3. Figure 7. Figure 4 Figure 8 Figure 8. Figure 4.

  • Page 13: Section 3: Operations

    OMMEND that you read books, trade maga- zines, or get formal training before begin- ning any projects. Regardless of the con- tent in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training. Basic Operation...
  • Page 14 Plastic Type Abrasives Abrasive Options Blasting Media from Grizzly.Com PART # G6535: G6536: G6537: Other Types of Abrasives Available G6538: Nozzle/Jet Options Steel Type Abrasives Alumina Type Abrasives Glass and Garnet Type Abrasives Sand Type Abrasives...
  • Page 15 Notes...

  • Page 16: Section 4: Parts

    SECTION 4: PARTS Parts Breakdown (G0472)
  • Page 17 Parts List (G0472) REF PART # DESCRIPTION REF PART # DESCRIPTION P0472001 CABINET ASSEMBLY P0472025 AC/DC ADAPTER P0472001-1 DOOR SEAL P0472026 RECEPTACLE P0472002 SCREEN FRAME P0472027 COMPLETE LIGHT ASSY P0472003 MESH SCREEN 27-1 P0472027-1 LIGHT BULB P0472004 LEG-RIGHT 27-2 P0472027-2 LIGHT BULB CLIP P0472005 LEG-LEFT...
  • Page 18 Parts Breakdown (G0473)
  • Page 19 Parts List (G0473) PART # DESCRIPTION PART # DESCRIPTION P0473101 WINDOW FRAME AND SEAL P0473131 SUCTION HOSE 101-1V2 P0473101-1V2 WINDOW GLASS V2.03.10 P0473132 BLAST GUN 101-2 P0473101-2 WINDOW FRAME P0473133 CLEAR ADHESIVE FILM 4-PC 101-3 P0473101-3 WINDOW SEAL P0473134 SHORT LEG-LEFT P0473102 KNOB P0473135...
  • Page 20 Parts Breakdown (G0476)
  • Page 21 Parts List (G0476) PART # DESCRIPTION PART # DESCRIPTION 101V2 P0476101V2 WINDOW FRAME & GLASS V2.03.10 P0476129 PRESSURE SUPPLY HOSE 101-1V2 P0476101-1V2 WINDOW PLEXIGLASS V2.03.10 P0476130 SUCTION TUBE P0476102 KNOB P0476131 SUCTION HOSE PN01M HEX NUT M6-1 P0476132 BLAST GUN PW03M FLAT WASHER 6MM P0476133...

  • Page 22: Warranty And Returns

    WARRANTY AND RETURNS...
  • Page 23 WARRANTY CARD The following information is given on a voluntary basis. It will be used for marketing purposes to help us develop better products and services. Of course, all information is strictly confidential. Note: We never use names more than 3 times. _____________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________...

This manual is also suitable for:

G0473G0476
