- Page 1 PORTABLE SOUND SYSTEMS From Fender Pro Audio Owner's Manual for LTB Portable Sound System P/N 051923 REV B...
- Page 2 Whether you need a simple box top powered mixer for your Saturday afternoon jam, or a professional full-size concert system, Fender has the sound reinforcement equipment to meet your needs. Likewise, your decision to purchase Fender pro audio gear is one you will appreciate with each performance for years to come.
- Page 3 MIXER MIXER The LTB: an 80 watt professional powered mixer from your friends at Fender you will find your new LTB sound system to be both a unique and effective sound reinforcement product, providing years of trouble-free service. With ease of...
- Page 4 INPUT CHANNEL CONTROL FUNCTIONS A. EQ - Adjusts the tone / frequency boost or cut of its respective channel. When the tone control is set at the 12 o’clock (notched) position, the channel is “flat” with no frequencies cut or boosted. As the dial is rotated clockwise, the treble response increases.
-
Page 5: Rear Panel Functions
MASTER CONTROL PANEL FUNCTIONS A. LOW - Adjusts the amount of low frequency boost or cut in the LTB. When all the tone controls are set at their 12 o’clock (notched) position, the LTB is “flat” with no frequencies cut or boosted. B. - Page 6 BASIC SETUP OF YOUR LTB Before using the LTB, please read and follow the steps listed below: 1. IMPORTANT Heed all safety warnings when operating the LTB. 2. Please be sure to check for these items. The LTB sound system comes complete with 2 LTB-10 Speaker cabinets, 2 speaker cables, 1 microphone cable and 1 dynamic cardioid microphone.
-
Page 7: Troubleshooting
• Are the levels on your outboard gear above their minimum positions? • (If applicable) does your instrument have power? If after checking all of the above the LTB is still not performing correctly, consult your nearest authorized Fender Service Center. - Page 8 SIMPLE LTB SETUP 1. Connect the speaker cords from the PARALLEL SPKR JACKS to the LTB-10 speakers. 2. Connect a microphone to a LOW Z input jack and any keyboard or other instrument to a HIGH Z input jack. Volume Value Value Value...
- Page 9 RUNNING AN EFFECTS PROCESSOR THRU YOUR LTB Volume Value Value Value Value 1. Connect speakers, microphones and other equipment to the LTB as before. 2. Next, connect a cord from the EFX jack to the input on the effects processing unit. Return the signal to the LTB by connecting a cord from the output of the effects unit to the AUX IN jack on the LTB.
- Page 10 SPECIFICATIONS FOR THE LTB POWERED MIXER DESIGNATION TYPE PART NUMBER POWER SPECIFICATIONS PRE-AMPLIFIER SECTION MIC INPUT IMPEDANCE LINE INPUT IMPEDANCE MIC INPUT SENSITIVITY LINE INPUT SENSITIVITY CHANNEL TONE CONTROLS Low +/- 15 dB @ 30 Hz OVERALL AMPLIFIER FREQUENCY RESPONSE PHANTOM POWER POWER AMPLIFIER SECTION POWER OUTPUT...
- Page 11 94 dB, 1W - 1M 111dB continuous, 117 dB peak 4 kHz Height: 16.75 in Width: 12.75 in Depth: 11.75 in 16 lbs A PRODUCT OF: FENDER MUSICAL INSTRUMENTS CORP. CORONA, CA 91720 USA 42.5 cm 32.4 cm 29.8 cm 7.3 kg...
