  • Page 1: Quick Start Guide

    Quick Start Guide F I B R E C H A N N E L S W I T C H I N S T A L L A T I O N...
  • Page 2 Purchasers of OEM products should consult with the OEM for support. Please feel free to contact your QLogic-approved reseller or QLogic Technical Support at any phase of integration for assistance. QLogic Technical Support can be reached by the following methods: http://support.qlogic.com...

  • Page 3: Installation Instructions

    For a surface mount, attach the rubber feet to the locations on the bottom of the switch. For a rack mount, install the QLogic 3000/5000 series rail kit and the switch in a standard 19" rack as described in the QLogic 3000/5000...
  • Page 4 Step 3. Stack Switches You can connect up to six switches together through the XPAK ports using XPAK switch stacking cables. Stacking provides performance and fail-over while preserving ports for devices. ■ For a 2-switch stack, use two 3-inch stacking cables. ■...
  • Page 5 NOTE: If your QLogic 5802V Switch came with 20 SFPs and a 3-inch stacking cable, ports 0–23 are active. ❑ To install an SFP transceiver, insert the transceiver into the switch port and gently press until it snaps in place. The transceiver will fit only one way.
  • Page 6 Open an Internet browser and start a new QuickTools session. Enter the new IP address to log in to switch. Step 10. Connect Devices ❑ Connect fiber optic cables between the installed transceivers and their corresponding devices. Each port auto-negotiates the proper port type with the connected device. Congratulations! You have successfully installed your QLogic 5800V Series Switch.
  • Page 7 Sun Microsystems, Inc.. All other brands and product names are trademarks or registered trademarks of their respective owners. Information supplied by QLogic is believed to be accurate and reliable. QLogic Corporation assumes no responsibility for any errors in this brochure. QLogic Corporation reserves the right, without...
  • Page 8 Corporate Headquarters International Offices QLogic Corporation UK | Ireland | Germany 26650 Aliso Viejo Parkway India | Japan | China Aliso Viejo, CA 92656 Hong Kong | Singapore | Taiwan 949.389.6000 www.qlogic.com *50861-03 50861-03 A...
