Summary of Contents for Q-See QSD004C4-250
-
Page 2: Table Of Contents
INDEX 1. DVR Features............... 1 2. Layout Front Panel ....................Rear Panel ....................Remote Control ..................3. Installation Installing the Hard Drive ..............Connecting Camera and Monitor ..........Connecting Power Supply…………………………..…..3 4. System Boot Detecting Installed Hard Drive ............. Recovering Lost Data ................ - Page 3 ..........7. Playback................14 8. USB Programming............. 15 PC Viewer Program............15 Program Buttons ............15 PC Backup ....................9. Specifications..............17 10. Appendix 10.1 System Connection Diagram......... 18 10.2 DVR Accessories (included) ......... 19 Q-SEE Product Warranty ............19...
-
Page 4: Dvr Features
QSD004C4-250 User’s Manual Chapter 1: DVR Features 4 Channel BNC Camera Input 1 Channel BNC Video Output Video Source Option: NTSC / PAL Motion Detection with Sensitivity and Area Settings Time Schedule Recording / Motion Triggered Recording One ATA-100 Hard Drive Interface USB 2.0 Back up to computer Remote Control Chapter 2: Layout... -
Page 5: Rear Panel
QSD004C4-250 User’s Manual 2.2 Rear Panel 1 BNC video output 4 BNC video inputs Power Supply Input Grounding Terminal USB Port is located on the right side of the case. 2.3 Remote Control Select or enlarge Channel #1 Select or enlarge Channel #2 Select or enlarge Channel #3 Select or enlarge Channel #4 Quad View... -
Page 6: Installation
QSD004C4-250 User’s Manual Chapter 3: (optional) Installation 3.1 Installing Hard Drive Note: This model comes with a 250GB Hard Drive already installed, so this would only be necessary if you are replacing the hard drive. 1. Unplug the power supply. Don’t install or uninstall HDD when DVR is on!! 2. -
Page 7: System Boot
QSD004C4-250 User’s Manual Chapter 4: System Boot 4.1 Detecting Installed Hard Drive After connecting the power, the system will boot-up and detect the installed hard drive. Checking HDD …… On the screen it will show the hard drive MASTER… information. 4.2 Recovering Lost Data RECOVER HDD? A power error can cause data to be lost, the... -
Page 8: Main Screen
QSD004C4-250 User’s Manual 4.4 Main Screen While the DVR is running, the monitor will display the information from the cameras as follows: Upper left: Percentage of space used on hard drive. Middle: Channel number (CH1 through CH4) Bottom right: Date and Time Bottom left: System status. -
Page 9: Camera Select
QSD004C4-250 User’s Manual Menu]: enter system menu MAIN MENU Note: If you are recording to enter CAMERA SELECT 1 2 3 4 RECORD SELECT 1 2 3 4 RESOLUTION EACH RECORD FRAME Menu you need to push stop button to RECORD QUALITY HIGH SCHEDULE SET... -
Page 10: Resolution
QSD004C4-250 User’s Manual 5.4 Resolution There are two resolutions for video recording: EACH Mode: The DVR compresses and records each video channel separately so you can enlarge a single channel to full screen display and still be recording on all channels. You can also record on specific channels, for example, you can turn off the recording function of CH1 and CH2 and then the system will only record video on CH3 and CH4. -
Page 11: Record Quality
QSD004C4-250 User’s Manual 5.6 Record Quality There are three levels of recording quality: High, Normal, and Low. Higher quality uses more hard drive space. Record frame rate, record quality and available hard drive space will all affect the total recording time of the DVR system. 5.7 Schedule Set You can set the video recording method by Time, and Motion Detection Triggered Recording. -
Page 12: Miscellaneous Menu-Auto Record
QSD004C4-250 User’s Manual 5.8 Miscellaneous Menu-Auto Record When the function is set to “ON” DVR will be awaked to record automatically by record schedule if DVR is without any manual operation in five (5) minutes. When you choose “OFF”, DVR will not record until you press the [ REC] button. -
Page 13: Miscellaneous Menu-Time Set
QSD004C4-250 User’s Manual 5.12 Miscellaneous Menu-Time Set TIME SET Configure system date and time: ∨ 2008/08/08 20:08:08 [ Up] and [ Down]: move the cursor [ SEL]: modify the value PRESS (UP,DOWN), ENTER (SELECT) PRESS (MENU) TO EXIT Menu]: exit and save 5.13 Hard Disk Set OVERWRITE ENABLED: If you choose “YES”, recording... -
Page 14: Motion Set
QSD004C4-250 User’s Manual 5.14 Motion Set MOTION RECORD TIME: This number indicates how many seconds the motion detection recording continues MOTION SET after a motion triggered event ends. MOTION RECORD TIME: MOTION ALARM TIME: MOTION ALARM TIME: MOTION SET This number indicates how many seconds the buzzer inside the DVR will sound PRESS (UP, DOWN), ENTER (SELECT) PRESS (MENU) -
Page 15: Video Mode
QSD004C4-250 User’s Manual 5.15 Video Mode Select NTSC or PAL video source (NTSC is used in the United States). 5.16 Factory Reset Press [ SEL] button to reload factory defaults, then the DVR will reboot, all custom settings (including password) will be restored to factory default. Caution: There is no confirming dialog box for this selection after you press [ SEL] button, please be patient! If you forget your password, please keep the system on main screen, and then... -
Page 16: Stop Recording
QSD004C4-250 User’s Manual 1. Hard Drive Usage (Displayed as a percentage) 2. Recording symbol (channel is currently recording) 3. Channel Number 4. Record Resolution (QUAD or EACH) 5. Status (REC, Play, FF1, FF2, FF3, REW, PAUSE) 6. HDD Info. ([M] Master Hard disk) 7. -
Page 17: Playback
QSD004C4-250 User’s Manual Chapter 7: Playback Press [ Play] button to play the latest recording. Menu] button to list all recorded video clips During playback press the [ from the hard drive. Newest video will be listed at the top. Press [ Up] and [ Down] to move the cursor and select an event, press [ Play] button to start playback. -
Page 18: Usb Programming
QSD004C4-250 User’s Manual Chapter 8: USB Programming By connecting the DVR to a PC you can use PC Viewer software to play back and backup DVR recorded video through the USB 2.0 port. 8.1 PC Viewer Program 1. Put the USB Driver Program CD into your CD-ROM Drive 2. -
Page 19: Pc Backup
QSD004C4-250 User’s Manual Item Remark 1. Capture picture Save an image of current frame 2. Save video clip Save DVR’s video clip to PC in .mys/.avi file 3. Directory Setting Change location of capture directory On PC 4. Time Search Search for time file on DVR hard disk 5. -
Page 20: Specifications
QSD004C4-250 User’s Manual Chapter 9: Specifications ITEM DESCRIPTION NOTE Video Format NTSC / PAL Operation System None Stand-alone Camera Input Channel 4 channel Composite BNC Video Output Channel 1 channel Composite BNC NTSC 120 frames/second 4×30 frames/second Display Frame Rate 100 frames /second 4×25 frames/second NTSC... -
Page 21: Appendix
QSD004C4-250 User’s Manual CAMERA Dimension: 46(W) × 46(D) × 107(H)mm Color Video Camera All Weatherproof Camera with 11 IR LEDs for Night Vision Weight: 280g Easy Installation – Wall Mount or Standing Operation Temperature: -20℃ - +55℃ 1/4” Color CMOS image sensor Horizontal Resolution: 380 TVL Auto Gain Control: On/Off Minimum luminance: 1.5Lux/F2.0... -
Page 22: Dvr Accessories (Included)
QSD004C4-250 User’s Manual 10.2 DVR Accessories (included) Q-SEE Product Warranty Thank you for choosing our products. All of our products users have a conditional free warranty repair service for hardware within 12 months starting from purchase date, and a free exchange service within one month (valid for manufacturing defects). -
Page 23: Customer Information Card
If you have questions: Contact Us: Mailing Address: Customer Service: DPS Inc. Phone: 877-998-3440 x 538 8015 E. Crystal Dr Email: cs@dpsi-usa.com Anaheim, CA 92807 Website: Tech Support: http://www.q-see.com Phone: 877-998-3440 x 539 Fax: Email: ts@dpsi-usa.com 714-998-3509 - 20 -...
