Page 1: Quick Installation Guide
Quick Installation Guide 4 Channel H.264 Compression DVR with (CIF) Real-Time Recording and 4 Color CCD Camera Kits... -
Page 2: Part 1 - Package Contents
Q-SEE QUICK INSTALLATION GUIDE PART 1 - PACKAGE CONTENTS: 4 Cameras with Stands Pre-Installed QSDR74RTS User’s (2) QD28414 Cameras (6mm Lens) Hard Drive (2) QD28414W Cameras (3.6mm Lens) Manual Power Supply & Power Supply Camera Cables BNC (M) – RCA (F) - Page 3 Q-SEE QUICK INSTALLATION GUIDE PART 2 - DVR CAMERA AND POWER CONNECTIONS (Figure 1) 1. Connect one end of the 60 Ft. extension cables to the cables that are connected to the cameras. 2. Connect the other end of the 60 Ft. extension cable to the DVR as illustrated in Figure 1.
-
Page 4: Part 3 - Dvr Controls: Front Panel
Q-SEE QUICK INSTALLATION GUIDE PART 3 - DVR CONTROLS: FRONT PANEL 15. Select/Edit/Right 1. Enter/Exit Display Screen 8. Menu/Escape/Left 16. Reverse/PTZ Focus 2. Display Screen for Menu 9. Enter or Exit PTZ 17. Pause/Auto Sequence 3. Show Menu 10. Up Button 18. -
Page 5: Part 6 - To Start Recording
Q-SEE QUICK INSTALLATION GUIDE PART 5 - SETTING UP CAMERAS FOR VIEWING AND RECORDING From the Main menu, select CAMERA. Here you can setup the name display (up to 8 characters) and position of each channel (cameras). Select COLOR SETUP to adjust the image brightness, saturation, contrast and hue settings for each channel (camera). - Page 6 Q-SEE QUICK INSTALLATION GUIDE Grid Explanation: Red = Alarm (motion detection) recording Green = General (time schedule) recording Transparent = No recording Blue = The channel and date selected. Manual Recording: From the Record Setup screen set the Rec Mode to “ALWAYS”. Your DVR will continuously record and separate files will be created with the Pack Time intervals you selected.
- Page 7 Q-SEE QUICK INSTALLATION GUIDE The Motion detection Menu has three sections, including Channel Status, Sensitivity and Motion area. STATUS: This option allows you enable motion detection on any channel. SENSITIVITY: This option allows you to set sensitivity level of motion detection from 1 to 4, with 4 being the highest.
- Page 8 Q-SEE QUICK INSTALLATION GUIDE File List: On the Video search menu mode, click File list to display the sub-menu shown in the picture on the left. This option will allow you to view all of the available files by channel and type (all, normal, or alarm).
- Page 9 Q-SEE QUICK INSTALLATION GUIDE Questions or Comments? Contact Us: Mailing Address: Customer Service: DPS, Inc. Phone: 877-998-3440 x 538 8015 E. Crystal Dr. Email: cs@dpsi-usa.com Anaheim, CA 92807 Live Chat from our Website Website: Tech Support: http://www.q-see.com Phone: 877-998-3440 x 539 Fax: Email: ts@dpsi-usa.com...
