QSD9004 & QSD9008
User's Manual
Contact US:
Q-see Products
8015E.Crystal Dr
Anaheim,CA92807
Website:
http://www.q-see.com
Customer Service:
Phone:877-998-3440 x 538
Email:cs@dpsi-usa.com
Tech Support:
Phone:877-998-3440 x 539
Email:ts@dpsi-usa.com
Fax:
714-998-3509
Rev 021009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QSD9004 and is the answer not in the manual?

Questions and answers

Summary of Contents for Q-See QSD9004

  • Page 1 QSD9004 & QSD9008 User’s Manual Contact US: Q-see Products 8015E.Crystal Dr Anaheim,CA92807 Website: http://www.q-see.com Customer Service: Phone:877-998-3440 x 538 Email:cs@dpsi-usa.com Tech Support: Phone:877-998-3440 x 539 Email:ts@dpsi-usa.com Fax: 714-998-3509 Rev 021009...
  • Page 2: Table Of Contents

    CONTENTS Chapter 1: DVR Features..............................2 Chapter 2: Layout ................................3 2.1 Front Panel ..................................3 2.1.1 4-Channel Front Panel ............................3 2.1.2 8- Channel Front Panel ............................4 2.2 Rear Panel..................................4 2.2.1 4- Channel Rear Panel ............................4 2.2.2 8- Channel Rear Panel ............................5 2.3 Remote Control ................................6 Chapter 3: DVR Installation...............................7 3.1 Hard Drive Installation ..............................7 3.2 Camera and Monitor Connection...........................7...
  • Page 3 6.3.3 Live Play Control ...............................30 Chapter 7: Specification ..............................31 Chapter 8: Appendix................................32 8.1 Operation Function Table ............................32 8.2 Recording Alarm setting...............................33 8.3 Troubleshooting................................33 8.4 4 Channel System Connections ............................34 8.5 8 Channel System Connections ............................34 8.5 Accessory (Optional)..............................35 Q-See Product Warranty..............................36...
  • Page 4: User Manual

    User Manual Safety Instruction Use proper power source. Do not use this product with a power source that applies more than specified voltage (100-240V AC). Never insert anything metallic into the DVR case. Putting something into the DVR case can be a source of dangerous electric shock. Do not operate in wet &...
  • Page 5: Chapter 1: Dvr Features

    User Manual Chapter 1: DVR Features Real time monitoring Supports real time surveillance via Monitor Saves Recordings DVR saves real-time recording image to HDD Backup Recordings Supports DVR backup via USB flash drive and hard drive. Playback Recordings Supports DVR single CH and multiple CH playback of recorded files Network operation Supports remote surveillance by multiple users simultaneously Supports HDD &...
  • Page 6: Chapter 2: Layout

    User Manual Chapter 2: Layout 2.1 Front Panel 2.1.1 4-Channel Front Panel 13 14 15 9 10 11 12 Item Key title/Indicator Marks Functions Power Switch Turn Power on and off Power indicator If the “Green” indicator is on the system is getting power IR Receiver Receives signal from Remote Control When the “Red”...
  • Page 7: 8- Channel Front Panel

    User Manual 2.1.2 8- Channel Front Panel Power Switch PAUSE: Pause / Frame Play PWR: PWR Indicator PLAY: Play IR receiver for Remote Control FWD: Play Forward / Move Right HDD: HDD I…ndicator STOP: Stop Playback; Stop manual Recording SEARCH: Recording Search REC: Manual Recording MUTE: Audio Mute key MENU/ESC: Menu / Escape...
  • Page 8: 8- Channel Rear Panel

    User Manual RS485/Sensor/Alarm interface (see pin outs below) RS-485/Sensor/Alarm Power Port Connect power supply - DC12V 3A List 2-2 2.2.2 8- Channel Rear Panel CH1-8: Video inputs USB port Video Outputs Mouse port Audio Input RS-485/Sensor / Alarm port LAN: LAN port for Network Access Power switch port Audio Output 4-CH: RS485/Sensor/Alarm port functions...
  • Page 9: Remote Control

    User Manual 2.3 Remote Control Channel Select 1-8 ; Numeric key 9、0 Numeric Key Preview all Channel Menu Enter/Exit Main Menu ▲ Up Key ▼ Down Key ◄ / Left / Right Key Select Key/ Edit Key Rewind key Play Key, Enter to recording search menu Forward Key ●...
  • Page 10: Chapter 3: Dvr Installation

    User Manual Chapter 3: DVR Installation 3.1 Hard Drive Installation Caution: Please do not Install or take out hard drive when DVR is running! (1) Remove screws and open DVR upper cover carefully; (2) Insert Power Cord and data cable into Pin of hard drive securely; (3) Put the upper cover back carefully, re-attach screws.
  • Page 11: Chapter 4: Dvr Boot Up

    User Manual Chapter 4: DVR Boot up 4.1 System Initialization After connecting the power adapter and turning On the power button, the system will boot-up and start initializing. Picture 4-1 4.2 Main Interface After finishing system initialization the system will enter into main interface.
  • Page 12: Main Menu Preview

    User Manual 5.1 Main Menu Preview Camera Color set Recording Search Network Playbac Rec. Detail File File Backup Alarm Setting E-mail Device PTZ Setting Manageme Mobile Motion Area setting Time Setting User Video Setting System Language Select System Information 5.2 Main Menu System Maintenance After clicking right button of mouse, pop-up menu will be displayed on the screen.
  • Page 13: Camera Setup

    User Manual 5.2.1 Camera setup Go to [Main Menu Camera] to set up the name display and position display of each channel (Shown as Picture 5-3), You can also adjust image brightness, saturation, contrast and hue settings of each channel after entering into [Color] Menu and set up whether each channel can be previewed or not under Live display and/or Recording mode.
  • Page 14: Network Setup

    User Manual Recording options include All, CH-1, CH-2, CH-3, CH-4 respectively. Please click the channel you need, the channel you select will be highlighted in “Blue” unselected channels will be “Grey”. To setup weekly schedules, click on the box of the recording status you want (Alarm, General, or No Record) and then click on each box in the schedule time line that you want this method to apply to.
  • Page 15: Port Forwarding

    User Manual (Picture 5-9), then type ipconfig at the prompt (RED arrow on Picture 5-9) to access the router settings. Write down the gateway and subnet mask numbers (GREEN arrows on (Picture 5-9) so you can copy them into the network settings on the DVR (Picture 5-10).
  • Page 16: Pop-Ups & Activex Controls

    User Manual When you access the DVR from a remote computer you also need to use a different address in the Internet Explorer browser window. Instead of entering the IP address of the DVR you need to enter the public IP address of the router the DVR is attached to. You can get this address by going to www.myipaddress.com from a computer that is attached to the same router as the DVR.
  • Page 17: Recording Search

    User Manual To connect to the DVR from the remote computer you would then open an Internet Explorer browser window and enter the internet IP of your router that you got by going to www.myipaddress.com. Notice : If you cannot use HTTP port 80 or 9000 because it is being used by another program, or it is being blocked by your service provider, you can use another port in the same range.
  • Page 18: Multi Player

    User Manual First : Indicates the first page of recording history you have searched. When you view other pages, clicking [First] button brings you back to Page one. PRE (Previous page): When viewing event list, clicking [Previous page] button will take you back to page before the one you are currently viewing (except the first page).
  • Page 19 User Manual 3、Open backup file: (1) 、Click [Play] menu (P) on the top of multimedia player interface to select playing the backup file; Picture 5-26 (2) 、Click pop-up menu button on the bottom of multimedia player and [Play- ] button, then the backup file will be played on the according channel.
  • Page 20: Device Management

    User Manual Picture 5-27A 5、Refer to the below for [Audio on] setting procedure. (Setting parameter will be available after re-starting multimedia player after [Audio on] set up.) Setting Audio channel setting Normal video Bar Select the channel you want to playback the audio Select the channel has audio files Apply OK.
  • Page 21: Alarm Set

    User Manual OVERWRITE: If you select “on” the system will automatically overwrite the oldest recordings once the hard drive is full; if you select “off”, recording will stop once the hard drive is full. HDD FORMAT: You use this option to format the hard drive, you can not record files to the hard drive until it has been formatted.
  • Page 22 User Manual On the [Email setup] mode, refer to its parameter setup shown as picture 5-34 when setting email alarm to “on”. SSL: is a security link transport protocol. You can encrypt your communication info (including your email) using SSL to prevent hackers from monitoring your email or communication info and even your password.
  • Page 23: Ptz Setup

    User Manual 5.2.6.3 PTZ Setup Enter into [Main menu Device PTZ Setup] to select the PTZ channel you want to control and set PTZ protocol (Pelco-D, Pelco-P), Baud rate (1200, 2400, 4800, 9600), Data bit (8, 7, 6, 5), Stop bit (1, 2), Parity Check (None, Odd, Even Mark Space)and address code respectively.
  • Page 24 User Manual 2. Click the windows mobile folder (red box in Pic 1) and choose the file QQeye” Select the file which will open the window in Pic 3. The file is generally faulted to save as Device, direct to phone, (shown in Pic 3) but you can save it to Device or Storage Card. 3.
  • Page 25 User Manual 8. Display mode: You can convert normal display into full-screen display by clicking the screen on the mobile phone (displayed as Pic 9) When accessing from a mobile phone with Symbian operating system, use the following procedure: 1. First you need to copy the file with suffix “QQeye.CAB” that is included on the CD disk to the mobile phone.
  • Page 26: Motion Detect

    User Manual 5. Once the installation is complete the window in Pic 9 will be displayed to tell you that installation is completed. Then you can go to the Applications folder and select the QQEye program (white box in Pic 10) and click on the Open option (red box in Pic 10) to display the settings menu.
  • Page 27: System Function

    User Manual MD AREA: This option allows you select the area you want to be sensitive to motion. The channel is separated into a 13*10 area. When any object moves into the motion detection area, and the area where the object is located is displayed in red recording will be triggered. In the semi-transparent area the motion detection is off.
  • Page 28: Video Setup

    User Manual 5.2.7.3 Video Setup Click [Main Menu System VIDEO] to setup Video, here you can set Camera system (PAL, NTSC)In the USA we use NTSC. Note: This model does not have a VGA port so VGA resolution does not apply Picture 5-44 5.2.7.4 Language Enter into [System Language] menu to select the language...
  • Page 29: Menu Lock

    User Manual 5.3 Menu Lock As a system safety feature you can click [Menu Lock] menu to lock menu when leaving the DVR. If you want to login to the DVR, you would input device code and password (refer to the Menu Locking interface- Picture 5-48).
  • Page 30: Log-In To Netviewer

    User Manual 6.2 Log-in to NetViewer After webcam installs plug-ins, please select log-in language (Chinese or English) and enter into password and click [Log-in] button, and now you can view DVR remotely through NetViewer. Please note default password is empty. System allows Administrator to set new password as per instructions in section 5.2.6.2 - [Password set] menu.
  • Page 31: Replay

    User Manual 6.3.1.2 Replay This option allows you to playback recordings remotely. First select the day, channel and type and proceed searching and refreshing; second select any event from search result list to playback. Please note you can control playing speed by sliding the playing-control bar on the bottom of the interface (shown as Picture 6-4).
  • Page 32 User Manual ② Alarm Click [Alarm] menu to enter into its sub menu (shown as Picture 6-7). You can set I/O alarm for every channel, motion detection alarm, motion recording, motion trace, motion sensitivity, video loss alarm, HDD not enough space alarm, HDD not found alarm and alarm output time etc.
  • Page 33: Ptz Control

    User Manual ⑤ Setting Click [setting] menu to enter into the menu interface (shown as Picture 6-11); Click […] button to preview net-viewer recording saving path and screen capture saving path. The menu also allows you to set a lower bandwidth for Internet video transmission, set user password, turn daylight saving time on/off, etc.
  • Page 34: Chapter 7: Specification

    User Manual Chapter 7: Specification Model D9004 D9008 Video System NTSC / PAL(Optional) Compression Format Video:H.264 / Audio:8kHz*16bit ADPCM Video Output 4-CH BNC Input/ 2-CH BNC Output 8-CH BNC input/2-CH BNC output 1-CH RCA audio input/ 1-CH RCA audio Audio I/O 4-CH RCA audio Input / 1-CH RCA audio Output output Display Resolution...
  • Page 35: Chapter 8: Appendix

    User Manual Chapter 8: Appendix 8.1 Operation Function Table Type Title Description Page Time setting Setting system date, time and format and day-light saving time setting Language Select Setting system language Setting CH title and position; adjusting image color parameter value; setting CH display to CH Setting ON / Off and time display/recording time overlaying to On/Off.
  • Page 36: Recording Alarm Setting

    User Manual 8.2 Recording Alarm setting Please refer the below matrix: “⊥” stand for “only alarm but no recording”; “AMR” stand for “alarm recording”; “NLR” stand for “normal recording”; and “NOR” stand for “ no recording”. Once alarm is triggered, alarm icon will occur, and when many alarms are triggered, alarm remarks will occur on the screen.
  • Page 37: Channel System Connections

    User Manual 8.4 4 Channel System Connections (diagram is for reference only to show where to attach various devices to the DVR, the cameras, external alarms, USB flash drives, monitors and computers are not included with the standard DVR package) 8.5 8 Channel System Connections (diagram is for reference only to show where to attach various devices to the DVR, the cameras, external alarms, USB flash drives, monitors and computers are not...
  • Page 38: Accessory (Optional)

    User Manual 8.5 Accessory (Optional) Ethernee Cable Power Cord Power Adaptor User Manual Software CD Remote Controller USB Mouse BNC to RCA V ideo Cable...
  • Page 39: Q-See Product Warranty

    User Manual Q-See Product Warranty Thank you for choosing our products. All of our products users have a conditional free warranty repair service for hardware within 12 months starting from purchase date, and a free exchange service within one month (valid for manufacturing defects).
  • Page 40: Customer Information Card

    User Manual Customer Information Card User’s Name Mr./Mrs. Company Name Postal Address Postal code Phone Number E-mail Model Number of Product Serial Number of Product Purchase Date Distributor The material in this document is the intellectual property of our company. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without our company’s prior written permission.
