Specifications

Main Inputs
Description
Gain
Optimum Input Levels
Maximum Input Level Before Clipping
Maximum Input Voltages
Input impedance
CMRR
Talk Back And Listen Mic Inputs
Description
Gain
Maximum Input Level Before Clipping
Maximum Input Voltages
Phantom Power
Frequency Response
Monitor Outputs
Description
Maximum Output Level
Output Impedance
DC Offset
Full Signal Path
Frequency Response
Signal Breakthrough with Full Cut
Distortion
Crosstalk
Output Noise
Table 1 MC524 Performance Specifications
Solo, CR 7, Mon A, B, C, D
Electronically balanced, transformerless, differential input
Variable from 0 dB (unity) to -72 dB
Set to 0 dBFS = +27 dBU. Designed to be fed from Euphonix MA703 DAC.
+28 dBU (sine wave)
16 VDC, 25 VAC (common mode), 50 VAC (differential)
10 k 10% each leg, 20 Hz – 20 kHz
>40 dB (50 dB typical), 20 Hz – 20 kHz
T1, T2, L1–L4
Electronically balanced, transformerless, differential input with automatic level
optimization
AGC circuit optimizes front end gain to produce approx. +8 dBU signal; this is
variable from +8 to -64 dBU at the monitor outputs
10 dBU (sine wave)
50 VDC, 2.5 VAC (common mode), 5 VAC (differential)
48 V available, link selectable on PCB
Attenuated LF and HF response, -3 dB at 200 Hz and 10 kHz
Electronically balanced and floating, differential output
+28 dBU (sine wave)
100 10%, balanced or unbalanced, 20 Hz – 20 kHz
< 5 mV with respect to chassis GND
Main Input To Monitor Output
0/-0.4 dB, 20 Hz – 20 kHz (ref. 1 kHz)
<-110 dB, 20 Hz – 20 kHz
<0.005%, 20 Hz – 20 kHz, +15 dBU output level
< -100 dB at 1 kHz; < -90 dB at 20 kHz
<-90 dBU RMS (unweighted); >117 dB of dynamic range at unity gain
