Euphonix ML530 Mic-Line Interface Operation Manual

Specifications

Gain Range
Phantom Power
Maximum Input Level
Differential Input Impedance
Maximum Output Level
Output Impedance
Frequency Response
Gain Accuracy
Distortion (THD+N)
Equivalent Input Noise (EIN)
Common Mode Rejection (CMR)
Phase Linearity
High-pass Filter
Phase Invert
Operating Temperature
Power Requirements
Power Consumption
Table 1 Performance Specifications
-12 dB to 72 dB in 0.5 dB increments
+48 V ±2% (Switched per channel)
41 dB (Pad inserted, unity gain, @1 kHz, @1% THD+N)
200 kΩ (Hi Z, Pad off, +48V off)
200 kΩ (Hi Z, Pad on, +48V off)
12.7 kΩ (Hi Z, Pad on, +48V on)
12.7 kΩ (Hi Z, Pad off, +48V on)
1.5 kΩ (Lo Z, Pad off, +48V off)
1.5 kΩ (Lo Z, Pad on, +48V off)
1.4 kΩ (Lo Z, Pad on, +48V on)
1.4 kΩ (Lo Z, Pad off, +48V on)
29 dB (@1 kHz, @1% THD+N)
100 Ω
10 Hz – 60 kHz (-0.5 dB @ unity gain)
10 Hz – 50 kHz (-0.5 dB @ 30 dB gain)
10 Hz – 40 kHz (-0.5 dB @ 66 dB gain)
±0.15 dB (@1 kHz)
0.004% (@ 1 kHz @ 0 dB gain with
+13.5 dB applied, 22 kHz filtered)
< 0.02% (20 Hz – 20 kHz @ 13.5 dB 80 kHz filtered)
-127 dB (@66 dB gain, 22 Hz – 22 kHz filtered, Low Z mode, 150 Ω source)
>50 dB (10 Hz – 20 kHz)
±10° (25 Hz – 20 kHz)
80 Hz 18 dB/octave switched per channel
180° switched per channel
Table 2 Environmental and Power Specifications
11
5–35°C
90–250 VAC, 50/60Hz
100 W
