Summary of Contents for Electrolux ESF 6146 S-Visi
-
Page 1: Instruction Book
D i s h w a s h e r Model ESF 6146 S - Visi Instruction book... -
Page 2: Table Of Contents
Contents Safety instructions Disposal Economical and ecological dishwashing Installation instructions Fitting under a counter Levelling Water supply connections Water inlet hose with safety valve Water outlet hose connection Electrical connection Description of the appliance Outside door Function buttons Washing programmes Prior to using for the first time The water softener Filling with dishwasher salt... -
Page 3: Safety Instructions
Check your dishwasher for any transport damage. Never persons may cause injury or serious malfunctioning. connect a damaged machine. If your dishwasher is Contact your local Electrolux Service Centre. Always insist damaged, you should contact your supplier. on genuine spare parts. -
Page 4: Installation Instructions
- A water inlet hose with safety valve must only be replaced by Levelling a specialist or by your local Electrolux Service Centre. - Place the water inlet hose in such a way that it is never Good levelling is essential for correct closure and sealing of higher than the bottom edge of the safety valve. -
Page 5: Water Outlet Hose Connection
In case that the electrical cable has to be replaced, If you use a drain hose extension it must be no longer than 2 please contact your local Electrolux Service Centre. metres and its internal diameter must be no smaller than the The appliance should not be connected to the diameter of the hose provided. -
Page 6: Description Of The Appliance
- the washing programme has ended, and turns off when: - the closure of the dishwasher’s door occurs. In case that this light has to be replaced, please contact your local Electrolux Service Centre. Outside door Function buttons Door handle... -
Page 7: Function Buttons
Function buttons The buttons of this dishwasher have backlit lights and carry out 4. Delay start button different functions. Pressing this button once will delay the start of the programme by 4 hours (corresponding backlit light 1. On/Off / Automatic button illuminated). -
Page 8: Washing Programmes
Washing programmes Programme Degree of soil Programme Cycle description (3) Consumption values button Programme Energy Water type of load to press consumption consumption duration (in minutes) (in kWh) (in litres) Main wash up to 50°C or to 65°C Heavy / normal soil. 1 or 2 cold rinses Crockery, cutlery, 30 - 100... -
Page 9: Prior To Using For The First Time
Prior to using for the first time Before using your dishwasher for the first time: b) Setting electronically The dishwasher is factory set at level 5. 1. Ensure that the electrical and water connections comply with the installation instructions If you want to change the setting of the water softener: 2. -
Page 10: Filling With Dishwasher Salt
Filling with dishwasher salt Rinse aid Only use salt specifically designed for use in Rinse aid is automatically added during the last rinse, ensuring dishwashers. thorough rinsing, and spot and streak free drying. All other types of salt not specifically designed for use in The integrated dispenser of rinse aid and detergent is a dishwasher, especially table salt, will damage the water positioned in the centre of the upper basket and holds about... -
Page 11: In Daily Use
In daily use Check if it’s necessary to refill with dishwasher salt or rinse Loading cutlery and dishes Sponges, household cloths and any object that can Load cutlery and dishes into the dishwasher. absorb water may not be washed in the dishwasher. Fill with dishwasher detergent . -
Page 12: Removable Knife Basket
Removable knife basket The upper basket The upper basket is designed for plates (dessert plates, Warning! saucers, dinner plates of up to 24 cm in diameter), salad Long bladed knives stored in an upright position are a bowls, cups and glasses. potential hazard. -
Page 13: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper basket Use of detergent If washing very large plates you can load them in the lower Only use detergents specifically designed for use in basket after moving the upper basket to the higher position. dishwashers. -
Page 14: Different Kinds Of Detergent
Different kinds of detergent Detergent tablets Detergent tablets from different manufactures dissolve at different rates. For this reason, some detergent tablets do not attein their full cleaning power during short washing programmes. Therefore please use long washing programmes when using detergent tablets, to ensure the complete removal of detergent residuals. -
Page 15: Starting A Washing Programme
Starting a washing programme 1. Check that the baskets have been Cancel a washing programme in progress loaded correctly and that the spray Press simultaneously buttons 2 and 3 until only the On/Off backlit light remains illuminated. arms can rotate freely 2. -
Page 16: Maintenance And Cleaning
Maintenance and cleaning Clean the external surfaces of the machine and control panel Attention! with a damp soft cloth. If necessary use only neutral Under no circumstances may the dishwasher be used without detergents. Never use abrasive products, scouring pads or filters. -
Page 17: Something Not Working
Once the checks have been carried out, close the door and press the On/Off button, the programme will continue from the point at which it was interrupted. If the alarm reappears contact your local Electrolux Service Centre..there are problems when operating the dishwasher... -
Page 18: The Wash Results Are Not Satisfactory
The detergent may be the cause. Contact the detergent manufacturer’s consumer care line. If after all these checks, the problem persists, contact your local Electrolux Service Centre, quoting the model (Mod.), product number (PNC) and serial number (S.N.). This information can be found on the rating plate located on the side of the dishwasher door (see picture).
