Transmitter Programming Guide
These transmitters make use of icons (symbols) to identify the reaction
your security system/keyless entry/and or remote start system, where
applicable, will have when any icon (button) is pressed. These
icons are programmed at time of installation to meet the needs of the
individual and to complement the vehicle that the system is installed in.
To replace a transmitter or add transmitters, please follow the
programming instructions listed on the pages of this manual.
RECEIVER
BUTTON
CHANNEL
1
2
1
3
3
*4
*5
* Where So Equipped
Model 07S
SYSTEM FUNCTION
Lock And Arm Alarm, also initiate and
terminates *Panic
Unlock And Disarm, also initiates and
terminates *Panic. Programmable to
unlock drivers door and or all doors.
Lock and arm/unlock and disarm. May
be programmed to unlock driver's door
or all doors. Also will initiate and
terminate *Panic.
Pulsed or switched output to control
Remote Trunk Release or optional
device connected to channel 3.
When pressed and release two times,
will provide pulsed output or activate the
Remote Start option when installed.
When so equipped, this button can be
used to operate an optional device
connected to channel 4.
When so equipped, this button can be
used to operate an optional device
connected to channel 5.
1
128-8119
1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 07SP - Remote 434MHz Transmitter and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Prestige 07SP - Remote 434MHz Transmitter

  • Page 1 Model 07S Transmitter Programming Guide These transmitters make use of icons (symbols) to identify the reaction your security system/keyless entry/and or remote start system, where applicable, will have when any icon (button) is pressed. These icons are programmed at time of installation to meet the needs of the individual and to complement the vehicle that the system is installed in.
  • Page 2 Some of the more popular options available for the unused Option Buttons of your transmitter are: AS 9075 Remote car starter AS 9153 Remote window roll up AS 9256 Remote trunk release relay Although the most common use of the transmitter buttons are shown on the front page of this guide, any button or button combination can be programmed into any receiver channel.
  • Page 3 4) Press and hold the lock or lock/unlock symbol button of the transmit- ter you wish to program for 4 seconds or until a long chirp is heard from the siren. "Repeat step 4 for each transmitter you wish to program". Note: If your transmitter button has the Lock/Unlock icon on one button, press and release the valet push button switch 2 times then move on to step #8.
  • Page 4 14) Within 10 Seconds, Press and hold the unlock button, (or any unused button(s)), of the first transmitter you wish to control Channel 6 output, (Driver Priority 1) until a long chirp is heard from the siren. (Repeat this for each transmitter you wish to operate the Channel 6 output, Driver Priority 1) 15) Within 10 seconds, press and release the valet program switch one time.
  • Page 5 Note: The button or combination of buttons entered will also control the arm or arm/disarm function until additional transmitters are added. All unwanted transmitters are now deleted. REPRIORITIZING A TRANSMITTER’S PROGRAMMING: To reprogram a receiver channel with a different transmitter button once a code has been stored, there will be two options: 1.
  • Page 6 Remove two #0 Phillips head screws where indicated to gain access to the CR 2032 battery. Carefully remove transmitter back cover keeping hold of the metal key ring to prevent it's loss. Carefully remove the discharged battery by sliding it out from under the clip in the direction indicated by the arrow in the diagram below.
  • Page 7 Credit card purchasers can order additional or replacement transmitters by phone. Simply dial 1 - 800 - 645 - 4994, and follow the instructions from the operator interface. Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y., 11788 Attn.: TRANSMITTER DEPARTMENT 128-8119...
  • Page 8 © 2007 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY, 11788 128-8119 128-8119 8 of 8...
