NEC Storage ReplicationControl SQL Option User Manual page 67

Chapter 6 Operations of NEC Storage ReplicationControl SQL Option
Procedure 8. Execute snapshot restoration (Business Server)
Execute a snapshot restoration by specifying the -remod norecovery option and the RV protection.
When using a service to monitor the disk state, it is necessary to stop the service before executing the
snapshot restoration. Start the service after executing the snapshot restoration.
When executing a snapshot restoration by specifying the RV protection, the separation is automatically
performed after synchronization has been completed as the result of the restoration. Therefore, it is
not necessary to execute the separation operation.
iSMsql_snapshotrst -db snap -metafile f:\snap.dat -remod norecovery -mode protect
Snapshot restoration execution
Data file
MV
Log file
MV
Figure 6-12 Execute Snapshot Restoration
Procedure 9. Reconfigure the drive name for the recovery target disk (Backup Server)
Reconfigure the removed drive name for the recovery target disk on the backup server side by
executing the MOUNTVOL command.
MOUNTVOL d: \\?\Volume{d9ea193d-9d59-11d6-ab08-806d6172696f}\
MOUNTVOL e: \\?\Volume{d9ea193e-9d59-11d6-ab08-806d6172696f}\
Data file
RV
Log file
RV
Metafile
Shared disk
61
