NEC Storage ReplicationControl SQL Option User Manual page 66

Chapter 6 Operations of NEC Storage ReplicationControl SQL Option
Procedure 4. Restore from the tape to the RV (Backup Server)
Restore data from the tape to the RV by using the backup software.
Procedure 5. Remove the drive name for the recovery target disk (Backup Server)
Remove the drive name for the recovery target disk on the backup server side by executing the
MOUNTVOL command to prevent new access. When using a service to monitor the disk state, it is
necessary to stop the service before executing the MOUNTVOL command.
MOUNTVOL d: /D
MOUNTVOL e: /D
Procedure 6. Execute file system flush of the recovery target disk (Backup Server)
Flush the file system of the recovery target disk on the backup server side and then write the
still-unwritten data in the file system buffer to the disk.
iSMrc_flush -mvol \\?\Volume{d9ea193d-9d59-11d6-ab08-806d6172696f}\
iSMrc_flush -mvol \\?\Volume{d9ea193e-9d59-11d6-ab08-806d6172696f}\
Procedure 7. Unmount recovery target disk (Backup Server)
Unmount the recovery target disk of the backup server side and cancel the associations between the
volume and the file system.
iSMrc_umount -mvol \\?\Volume{d9ea193d-9d59-11d6-ab08-806d6172696f}\
iSMrc_umount -mvol \\?\Volume{d9ea193e-9d59-11d6-ab08-806d6172696f}\
Backup software such as
Data file
ARCserve
RV
BackupExec and
NetBackup
Log file
RV
Metafile
Shared disk
Figure 6-11 Restore from the Tape to the RV
60
Tape
