Temperature Control; Temperature Mode Change; Table Of Contents; Temperature Setting - Frigidaire GLFH17F8HWF Guide Manual

Temperature Control .......................................................... 2
Temperature Setting .................................................... 2
Temperature Mode Change ........................................ 2
Extreme Freeze ........................................................... 2
Control Lockout ........................................................... 3
Sabbath Mode ................................................................... 3
Manual Defrost .................................................................. 3
Alarm Functions ................................................................ 3
Temperature Alarm ..................................................... 3
Door Ajar Alarm .......................................................... 3
Power Failure .............................................................. 3
System Error Alarms ................................................... 3
Alarm Function Table .................................................. 4
TEMPERATURE SETTING
The desired temperature inside the freezer can be set us-
ing the UP and DOWN arrow buttons on the control panel,
located on the door of the freezer. Press either the UP or
DOWN arrow buttons to change the temperature setting to
one which suits your needs. The range of settings is -IO°F
to IO°F ( -24°C to -12°C ) (See Figures 1 and 2).
extreme temp alarm control ::
freeze display reset lock
Door Ajar Power Loss hold for F/C o
Figure 1
extreme temp alarm control
freeze display reset lock
DoorAjar Power Loss hold for F/C o
Figure 2
You may also turn off the freezer by pressing the UP arrow
button until the display reads "10". With the display at
"10', press the Up Arrow button two more times within two
seconds. The display will read "OF".
The freezer can be turned ON by pressing the DOWN
arrow button, with the display 1O, two times within two
seconds. Continue by setting the control to the desired
temperature.
The freezer will not cool anything while it is in "OF" position.
The door light will continue to operate while in 'OF".
WARNING: The freezer still has electrical power
while in OF. Disconnect freezer from the outlet before
cleaning or moving it.
f .......................................
'i
extreme temp alarm control ::
freeze display reset lock
Door Ajar Power Loss hold for F/C o
Figure 3
TEMPERATURE MODE CHANGE
Temperature display can be changed from °F to °C by
pressing the "Temp Display". Press the button again to
change it back to the previous mode.
EXTREME FREEZE
Extreme Freeze enables the compressor to run
continuously to help cool large quantities of warm (room
temperature) foods faster. Always cool down hot foods to
room temperature before placing them in the freezer. Use
this feature just prior to adding large quantities of unfrozen
foods (not to exceed 3 pounds per cubic foot of freezer
space). For example, do not place more than 45 pounds of
room temperature food into a 15 cubic foot freezer.
To activate the Extreme Freeze feature, push the Extreme
Freeze button. The control panel will beep once and the
display will show "-F-". See Figure 4.
f 4\
'i
extreme temp alarm control :,
freeze display reset lock
i
Door Ajar Power Loss hold for F/C o
J
Figure 4
For your convenience, Extreme Freeze will automatically
turn off after a period of 72 hours and the freezer will
return to the previous temperature setting. You may
deactivate Extreme Freeze at any time by pressing the
Extreme Freeze button. The display will return to displaying
the last temperature setting.
