Frigidaire GLFH1779GW - 16.7 cu. Ft. Upright Freezer Wiring Diagram

Upright freezer w/ice maker
Hide thumbs

Advertisement

P08F0093.eps P08D0563.eps P08C1148.eps P08S0472.eps P08ICE03.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GLFH1779GW2
Series
Gallery
Color
white
Volts
115
Wiring Diagram 297005601
Owner's Guide 297208600
Market
North America
Energy Guide
216910408
UPRIGHT FREEZER
Publication No.
5995526117
08/10/13
(EN/SERVICE/MLR)
365
Copyright
W/ICE MAKER
Model No.
GLFH1779GW
©
2008 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Also See for Frigidaire GLFH1779GW - 16.7 cu. Ft. Upright Freezer

  Related Manuals for Frigidaire GLFH1779GW - 16.7 cu. Ft. Upright Freezer

  Summary of Contents for Frigidaire GLFH1779GW - 16.7 cu. Ft. Upright Freezer

  • Page 1 Product No. GLFH1779GW2 Series Gallery Color white Volts Wiring Diagram 297005601 Owner's Guide 297208600 Market North America Energy Guide 216910408 UPRIGHT FREEZER P08F0093.eps P08D0563.eps P08C1148.eps P08S0472.eps P08ICE03.eps W/ICE MAKER Electrolux Major Appliances Model No. North & Latin America GLFH1779GW P.O. BOX 212378 AUGUSTA, GA 30917 Publication No.
  • Page 2 Publication No: 5995526117 GLFH1779GW2 DOOR P08D0563 10/08...
  • Page 3 GLFH1779GW2 Publication No: 5995526117 DOOR POS. NO PART NO. DESCRIPTION 216522309 Gasket-door, white 216527813 Panel-inner door 297245216 Panel-outer door, white 241808701 Nameplate 297254101 Door Stop, LH 240536809 Handle-door, white 240537301 Nut-anchor, door hdl screw 297048000 Screw, anchor, #8, white 297197500 Screw, door stop mtg, FH38-16X.750, P Twin 216970800 Bearing, hinge w/o'ring, top...
  • Page 4 Publication No: 5995526117 GLFH1779GW2 CABINET P08C1148 10/08...
  • Page 5 GLFH1779GW2 Publication No: 5995526117 CABINET POS. NO PART NO. DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 297200600 Breaker Kit w/corners, no lock slot 297200100 Breaker Kit w/corners, 32", top and bottom 13 # 216934100 Motor, fan, 115 V 216998000 Switch, light/lamp, ramp 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V 297048600...
  • Page 6 Publication No: 5995526117 GLFH1779GW2 CABINET P08C1148 10/08...
  • Page 7 GLFH1779GW2 Publication No: 5995526117 CABINET POS. NO PART NO. DESCRIPTION 297053000 Wire, jumper 5303313703 Clip, (2) 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2) 297092700 Bracket, crisper cover, RH 297092701 Bracket, crisper cover, LH 297107600 Slide, crisper, RH 297107601 Slide, crisper, LH 297099500...
  • Page 8 Publication No: 5995526117 GLFH1779GW2 SYSTEM 10/08...
  • Page 9 GLFH1779GW2 Publication No: 5995526117 SYSTEM POS. NO PART NO. DESCRIPTION 297152201 Condenser 5308000110 Strap-evap/heater, aluminum, (2) 216987500 Drier-filter 297171700 Harness-main 240555002 Screw-#8-32 X 3/8 216730700 Heater-defrost 15 # 216997300 Evaporator 297238700 Heat Exchanger 297078700 Insulator-evap, styrofoam 297078800 Insulator-evap, styrofoam 216872200 Thermostat, defrost 23 # 216744500...
  • Page 10: Ice Maker

    Publication No: 5995526117 GLFH1779GW2 ICE MAKER M O V M O V L O C L O C K E D K E D U N T U N T IN T O IN T O P L A P L A INSTALLATION PARTS P08ICE03 10/08...
  • Page 11 GLFH1779GW2 Publication No: 5995526117 ICE MAKER POS. NO PART NO. DESCRIPTION 297044900 Tube-water inlet, inlet valve, to ice maker 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ice maker 5304456657 Nameplate 5304456658 Gear 5304456659 Plate-mounting 5304456691 Screw, M 3x20 #3, valve plate 5304445222 Motor-ice maker Svo 5304445223...
