- Page 2 If you have questions or do NOT understand the information presented, contact The Genie Company or an authorized Genie®Dealer. The safety alert symbol and following signal words DANGER, WARNING, and CAUTION are used throughout this manual to call attention to and identify different levels of hazard and special instructions.
- Page 3 INTELLICODE ® Rolling Code Security System. An electronic rolling code system that enhances the security of the door opener by continuously changing the access code each time the remote control is used. The door opener responds to each new code only once. An access code copied from a working system and tried again will not control the door opener.
- Page 4 Thsgs to co_"_s de__ f you a_e p_an s ng to _©o_ t_you_o_'self,_ This opener is designed for use with SECTIONAL doors only. De Sse £_s8 operer insX,;::stled Seso ace some pso-ZsIstlsIk/J) hs_es <iJ iot need Jl<> be s</<:/mssed TTey s_}) as fL>/Cows: _7_e Gese Oompsny £s_cemme£_7...
- Page 5 Pg. 13 Pg. 12-13 TYPICAL SUPPORT ADDED BRACKET HEADER BRACKET (NOT PROVIDED) MOUNTING BOARD BRACES POWER CORD (APPROX. 45 iN.) TO 120V GROUNDED OUTLET EXTENSION SPRING TORSION SPRING NOTE: This opener is designed use with SECTIONAL doors only. Pg. 17-18 Pg.
- Page 6 I_JI c ) I_JI c ) I_JI o Pencil 3/16" Drill Bit Carpenter's level Drill Adjustablewrench Wire strippers Ratchet Tapemeasure Safety Glasses Hammer Step ladder 1/4", 7/16", 3/8" and Phillips screwdriver 1/2" Sockets _E5727: 1t81t1_ Child can be pinned under automatic garage door. •...
- Page 7 iiiiill ,_Ii!ii'i!ili ii;il _! ii;il _! ii;ii!iii!iii!iiiii!iiiiiii;!iii;!iiiiii _ii!i! _ii_i_ ii_iii_i_::i!iii! ,i!ii_!iiii_iilii:i!i_ili!_!!_i!i ii:iil! iii_il _iii!i!iili_iiii_ i_i!ii'i'ii'ii::i _i!i_ii_i_ iliiii_iill ii_i_ii_;il _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii _;ii i_ i! RAIL SECTION CLAMP RAIL CLAMP BOLT 5/16 -18 x 5/8"...
- Page 8 Power Cord Rail withchain Carriage Slide Power Head CHAIN Release Knob Tensioner Belt Clamp Chain Rail Clevis Pin, Long Header & Cotter Pin BELT _Belt Carriage Slide Bracket Rail with chain Ra, Clam _s t_UAIM _#1 I_,11_i Rail Clamp Bolts_. _ _/°_-, ,._//k.-,,_/Ci_ k___._ enobease _...
- Page 9 IMPORTANT INSTALLATION INSTRUCTIONS 1. READ AND FOLLOW ALL SAFETY, INSTALLATION Do NOT connect the opener to source of power until instructed to do so. AND OPERATION INSTRUCTIONS. ( yo_J_ave qvesto_so do o u_dosS;,_v_i_:s_ _st_;cto_ ca/ i/% Locate the Wall Control: L/34 <_ •...
- Page 10 Rail Assembly for CHAIN DRIVE OPENER CHAIN DRIVE RAILS NOTS: FoJ" sp£I ;ss£ c/__mps, n s, ,s, nd bohfs /oc,sS_ S_£ 0 Fro_r Box 1, 3. Remove the two rai sections that are not connected to the chain and place them on floor (Fig.
- Page 11 Assembly for CHAIN DRIVE OPENER chsn Bolts ,._:._ u,_.. y ..of "<_L HO'_£!: F@" powe£ he,_d end ss£ esse£ DJy/oceSe t!:_g f £msy 8ox IVO_!: Copy se_/_,_ury bet _soFs'power heed _qs, sy e and _'eco_J £ on w#/,_uy"_,_n_y p,sWe, 1.
- Page 12 b) - extend vertical line d) - final c) - door at height mark highest point Finding header bracket mounting location. , Close garage door. -Use a pencil and level. a) Mark center of garage door (one-half overall width) on the wall with 6" vertical line at top top of door edge of door.
- Page 13 1. Getting started. , Position assembled rail on wall next to header bracket (Fig. 2-4). -Place material on floor under power head to protect from scratching. (A box, stool, or similar device may be needed to clear a torsion spring.) So;<...
- Page 14 oc,s, e 8_;'{11 ho_, b;os' 2 Finding door bracket mounting location. . Door bracket is mounted as high on door as possible along vertical centerline and NO LOWER THAN top set of rollers (Fig. 2-7). Mounting the door bracket. • Proper bracing should be verified at this point. - Align door bracket centered on your vertical centerline (Fig.
- Page 15 Wire from power head ..to Wall Control .... : :::. Wall Control "Entrapment" ¢) warning label Separate entry door EXAMPLE ONLY! I This is an example of wire routing __---I when NOT pre-wired. Your wire Jrouting may be different. 1.
- Page 16 3. Securely fasten wires. , Securely fasten wires to ceiling and wall using insulated staples provided. -Use insulated staples. -Staples should be snug only. Insulated , if rear cover is attached to power head, Staple remove it. , On power head: -Route Wall Control wires through wire guide on power head.
- Page 17 Mounting bracket extensions are available through an authorized Genie ® Dealer. b) Blocks of wood, etc. may be substituted extensions. , Center bracket on your mark (Fig. 4-2). • Fasten each with 2 screws (Fig. 4-2).
- Page 18 Wiring (pre-wired). Route wire from wall to Safe-T-Beam ® sensors (Fig. 4-5b). Splice pre-wiring to shortened sensor wire, match wire pairs dash-to-dash (striped-to- Source striped) and plain-to-plain (white-to-white). - Trim sensor wire to approximately one foot (1 ft) from sensor. - Split and strip ends of sensor wires and Ceiling 21Jor165...
- Page 19 Motor Cover Screws Do NOT use an extension cord. Do NOT use a portable generator. This product is designed to operate using standard household current. Plug the opener into a properly grounded powe_supplies. Do NOT use alternate electrical outlet (Fig. 5-1). instructions for Electrician.
- Page 20 Open Indicator Light Open Set Limit Up Force _;,.(_,',} ..Travel Limit Button, OPEN C°stt_Clen t The OPEN (UP) and CLOSE (DOWN) door positions are controlled by making the adjustments on the panel located on the bottom of the power head. The adjustments that can be made are: •...
- Page 21 DOOR The Carriage Lock can be manually engaged or disengaged. , To disengage Carriage Lock -Pull handle downward opener power head. , To engage Carriage Lock -Pull handle towards door. UNLOCK LOCK TO RELEASE TO RECONNECT PULLTOWARD PULLTOWARD THE OPENER DOOR 1.
- Page 22 1. Press and hold both of the "SET" buttons ([] & Pq)together until the green indicator light blinks (about 5 seconds). 2. All close and open travel limit settings are erased. Then follow the steps above to reprogram close and open travel limits...
- Page 23 This device complies with FCC Part 15 and RSS 210 of industry Canada. This equipment has been tested and found to comply with the limits for a Class B PsIO'LY£!'; Bo< sen oI_e cont_{;_ /oe_Ie Box 3 digital device, pursuant to Part 15 of the FCC Rules. Single Button Remote...
- Page 24 1. Battery replacement. , To open, gently push straight out on battery cover lock tab as shown. (Fig. 8-1). , Slide open battery cover. - Remove old battery. , Make sure new battery is facing proper direction (Match battery polarity with symbols inside battery housing) (Fig.
- Page 25 SAVE T ESE I STRUCTIONS. If you have any questions, please do not hesitate to contact Genie ®customer service at: 1.800.354.3643 2. Contact reverse. • Place a 2"x 4" board laid flat on floor.
- Page 26 Opener circuit wiring diagram. This wiring diagram is for reference only. Diagrama del circuito del abrelatas. Este diagrama es solo para referenda. Schema de c_blage de I'ouvreur. Ce schema de c_blage est indique a titre de ref6rence uniquement. POWER CORD CORDON DE SECTEUR CABLE...
- Page 27 • Check "OPEN FORCE" adjustment (See section n). • ,i_ WARNING: If you suspect a problem with the garage door hardware or springs, contact an authorized Genie® Dealer or a trained door system technician, or contact The Genie at 1-800-35-GENIE.
- Page 28 • Check button(s) and wiring. (Repeat) Staples can cut insulation and shorts wires. Replace Wall Control, repair or replace wiring. - Contact The Genie Company at 1-800-35-GENIE • Wall button wires reversed • Reverse wire placement in power in power head connector.
- Page 29 TRANSMITTER COMPLIANCE STATEMENT Transmitters comply with all United States and Canadian legal requirements as of the date of manufacture. No warranty is made that they comply with all legal requirements of any other jurisdiction. If transmitters are to be used in another country, the importer must determine compliance with any local laws and regulations...
- Page 30 LIMITED WARRANTY GMI Holdings, Inc. d/b/a The Genie Company ("Seller") warrants to the original purchaser of the below identified opener, Model 2022/2024/2042 ("Product"), subject to all of the terms and conditions hereof, that the Product and all components thereof will be fi'ee fi'orn defects in materials and workmanship...
