- Page 1 ULTRA SLIM FLUSH MOUNT UNIVERSAL FOR 26” - 55” TVS UP TO 130 LBS XMF1300 - QUICK INSTALL GUIDE...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Read the Important Safety Information on this page before installing or using this mounting system. Always follow the instructions in this Quick Install Guide. VIZIO is not liable for damage or injury caused by incorrect mounting, assembly, or use. -
Page 3: Step 1 - Before You Begin
STEP 1 - BEFORE YOU BEGIN Before you begin the installation, ensure you have all of the items listed on this page. Do TWO-PERSON JOB not begin the installation unless you have all of the following items. Mounting a TV requires power tools. If you are unfamiliar with safe power tool use, consult a professional installer. - Page 4 Before you begin, ensure all parts are included and undamaged. To prevent loss, do not unpack the small parts until they are required. If any parts are missing or damaged, contact VIZIO Customer Service (877) 698-4946. Quick Install Guide &...
- Page 5 ANCHOR MISC...
- Page 6 STEP 3A - MOUNTING TO A WALL WITH WOOD STUDS The mount can be attached to walls with wood studs. The wall covering (drywall, lath, plaster, etc.) may not be thicker than 1/2”. If you are mounting on a concrete wall, go to Step 3B on page 6. 16”...
- Page 7 3. Place the mount on the floor. Using the power drill and the 7/32” drill bit, drill into the pencil marks as shown. Ensure you are drilling into the studs. Drill 7/32” each hole about 2” into the stud. P e n c i l M a r k 4.
- Page 8 STEP 3B - MOUNTING TO A CONCRETE WALL 1. Hold the mount against the wall Use the built-in level to level the mount. Built-In Level When the mount is level, hold it in place and use the pencil to mark the areas inside the slots where bolt holes will be drilled. Instead of holding the mount against the wall, you can use the included template.
- Page 9 3. Remove 4 anchors from the pouch labeled ANCHOR. Push the anchors into the holes you just drilled. Ensure the anchors are completely inserted and flush with the wall. 4. Remove 4 lag bolts and 4 washers from the pouch labeled LAG. Place the mount against the wall, and use a wrench to insert the lag bolts and washers into the anchors.
- Page 10 STEP 4 - ATTACHING THE TV BRACKETS 1. Gently place the TV on the floor screen-down. You may want to place a rug or blanket beneath the screen to prevent scratches. Mounting Holes In your TV’s User Guide, find the size of your TV’s mounting holes. These will be listed as M4, M5, M6, or M8.
- Page 11 3. Using the screwdriver, insert the screws, star washers, and washers as shown. Because each TV is different, your VIZIO TV mount includes screws of different lengths. Use screws that can be inserted completely. Do not use a short screw if a longer screw can be inserted completely.
- Page 12 4. To keep the pull-down handles accessible, they should hang near the bottom edge of the TV. To adjust the pull-down handles, use a screwdriver to remove the 2 philips-head screws from the bracket as shown. Handle Near Bottom Edge of TV 5.
- Page 13 STEP 5 - HANGING THE TV ON THE MOUNT This step requires lifting the TV. To prevent injury to yourself or damage to your TV, perform this step with the help of another person. 1. With the help of another person, lift the TV and hang the brackets on the mount as shown.
- Page 14 3. Pull down the handles on the brackets. The latches open and the TV rests fully against the mount. Gently release the handles. The latches close. The bracket is now locked to the mount. The mount setup is complete. Pull Down on Handles OPTIONAL: Your mount includes an anti-theft cable.
-
Page 15: Warranty
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS VIZIO provides a warranty to the original purchaser of a new Product against defects in materials and FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET FORTH workmanship for a period of one year of non-commercial usage and ninety (90) days of commercial ABOVE. - Page 16 TRADEMARKS SHOWN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. VIZIO, THE V LOGO, WHERE VISION MEETS VALUE, AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
