- Page 1 Nemesis Silver Series Owners Manual NA120 / NA80 Bass Guitar Amplifier Chassis For Silver Series Combos Covering Models N10S(E), N12S(E) N15S(E), N28S(E) 3/15/2005 U. S. Music Corp.
- Page 2 Publishing Date 3-15-05 Foreword Congratulations on your purchase of your new lightweight Nemesis Silver Series Combo Amplifier System. All of us at Eden are totally committed to providing you with the very best bass guitar systems in their class. Our goals are to offer you the outstanding performance quality of a top-...
- Page 3 Thank you for your purchase of an Eden Nemesis Series bass guitar product. This unit has been designed and constructed to give you years of trouble-free service.
-
Page 4: General Features
D.I. with ground lift switch and level control, effects loop, all plywood enclosure, and powerful, great sounding Eden designed loudspeakers. SET UP AND GETTING STARTED Before turning on your Nemesis Combo, you need to do a few things first. -
Page 5: Input Jacks
position. This will set your amplifier up flat and with the auto compressor operating. Next, plug in the power cord to the AC inlet on the back of the unit. Use only a safe grounded receptacle for proper operation at the correct voltage for your country. - Page 6 This control regulates the first amplification stage and controls the gain of the first stage in the overall system. The compressor automatically tracks the input level and follows the gain. This is a fixed-threshold type compressor. You control the compressor threshold by setting the gain higher or lower;...
- Page 7 can also be used with the other tone controls. MAIN TONE CONTROL 3-BAND EQ Main Channel The main tone control section is a 3-band tone equalizer. The audio spectrum is divided into three bands, the bass, mid, and treble. The bass and treble are shelving type filters and the midrange control is a band pass type filter.
-
Page 8: Back Panel Features
This switch turns off your internal and external speakers for quiet practicing with the headphones. BACK PANEL FEATURES AC POWER INLET/ FUSE This is where you plug in your AC line cord. This is also where the fuse is located. The fuse for US operation is a 2 amp. 5x20 MM slow-blow type fuse. -
Page 9: Effects Loop
Your unit is designed to be played hard and to hold up well. However, it is not designed to replace, or to perform as loudly as, the more powerful Eden separate systems. If you find you are pushing your amplifier so hard that you are... - Page 10 The D.I. output is used to connect your unit to P.A. systems and recording consoles. This is adjustable from microphone level to a high line level signal. The level control sets the amount of signal level that appears at the output of the XLR connector. The ground lift is used to reduce noise when plugging into another system.
-
Page 11: Speaker Break In
The USM service department is open Monday through Friday between 8:30 AM and 5:00 PM. US Music Corp. 444 East Courtland St. Mundelein, IL 60060 USA. International customers please contact your local dealer or distributor. You can also contact us at info@usmusiccorp.com or visit our website at www.eden-electronics.com...
