For Models: KEBS208DBL7, KEBS208DWH7, KEBS208DBS7, KEBS208DSS7
Illus.
Part
No.
No.
DESCRIPTION
NOTE: The screws and nuts
required to attach a part are
listed immediately following
that part.
1
Trim, Side
4450850 RH Black & BS Mdls
4450851 RH White Model
4450853 LH Black & BS Mdls
4450854 LH White Model
Screw
4449747 Black & BS Models
4449041 White Model
4
4448520 Bumper, Door
6
4452201 Divider, Vent
4449809 Screw
7
4452237 Top Chassis
4449809 Screw
9
4452158 Tube, Vent
4449154 Screw
10
4452163 Lens, Light
11
4448972 Oven Light Assy
4449748 Screw
12
4452164 Bulb, Light
OVEN PARTS
(BLACK) (WHITE) (BLACK−STAINLESS) (STAINLESS STEEL)
Illus.
Part
No.
No.
DESCRIPTION
14
4451740 Frame, Front
4449040 Screw
4450118 Nut
15
4449372 Gasket, Door
19
4451478 Support, Insulation
4449809 Screw
20
4451605 Cap, Spacer
21
Rail, Side
4450581 Right Side
4450582 Left Side
4448444 Grommet
4449154 Screw
22
4451896 Latch Assy
4449154 Screw
23
4452224 Solenoid
24
4451422 Micro Switch N.C.
25
4454691 Side, Chassis
(R.H. & L.H.)
4449809 Screw
26
4452234 Back, Chassis
4449809 Screw
27
Liner, Oven
(Not serviceable)
28
4451426 Micro Switch
29
4451665 Sensor
4449154 Screw
30
4451537 Spring, Latch
2
Illus.
Part
No.
No.
DESCRIPTION
33
4451619 Deflector, Vent
34
4452267 Vent, Center
37
4452223 Thermostat (TOD)
4449809 Screw
43
4451398 Base, Chassis
4449809 Screw
49
4448933 Retainer, Gasket
4449154 Screw
50
4451747 Cover, Back
4449809 Screw
51
Trim, Bottom
4448478 White Model
4448477 Black & BS Models
53
4449845 Support, Bracket
4449809 Screw
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
885470
