OPERATING INSTRUCTIONS
Crevice Tool, Upholstery and
Dusting Brush
1.
Crevice Tool
For radiators, crevices,
corners, baseboards and
between cushions.
2.
Dusting Brush
The dusting brush is used for
the furniture, venetian blinds,
books, lamp shades and
shelves.
3.
Upholstery Brush
The dusting brush is used
for the furniture.
Warning:
To reduce the risk of electric
shock, the power cord must be
disconnected before removing the dust
cup, dust cup filter,changing the filters or
performing maintenance/trouble shooting
checks.
Note:
Before using the appliance,
unwind a sufficient length of cable and
Insert the plug into the wall socket. A
yellow mark on the power cord shows the
ideal cable length. Don't pull the power
cord beyond the red mark.
Power Cord
Your vacuum cleaner includes a power
cord, which is automatically retractable.
To extend your power cord, pull from
rear and extend to desired length.
When cleaning is finished, first switch
off power and disconnect plug from
electrical outlet. Then press on cord
rewind button. If the cord does not fully
retract, pull it out again and then press
on cord rewind button.
1. Insert the power plug into the wall
outlet.
2. Press the Power On/Off Switch to
activate the vacuum cleaner.
Power On/Off Button
3. To rewind the power cord,
press the cable rewind button
with one hand and guide the
power cord with the other hand to
ensure that it does not whip
causing damage.
Cord Rewind
Yellow
Red
Symbol
Symbol
Warning:
Hold the plug when rewinding
the cord. Do not allow the cord to whip
when rewinding.
Cleaning Air Driven Turbo Brush
Locking Latch
Turbine
1. Slide locking latch forward then tilt the
top housing of the brush upwards. The
top housing is hinged and will tilt up
approximately 45° only.
2. Inspect turbine wheel and air passage
for debris and/or blockage. Remove
debris if present.
3. Inspect the rotating brush for built-up
hair or string. If present, remove by
carefully cutting with scissors. Avoid
damaging or cutting bristles.
4. Once clean, close the top cover of the
turbo brush and slide the locking latch
toward the rear of the brush to lock.
5
Cleaning & Changing the
HEPA Dust Cup Filter
Warning:
Always unplug the unit from
electrical outlet before opening the Dust
Cup (container).
Important:
Do NOT use the HEPA filter
cartridge without the debris screen in
place.
Warning
After each Use - Always
:
remove the Filter Debris Screen from the
HEPA Dust Cup Filter, then vigorously
"TapClean" HEPA Filter until no more
dust can be removed.
IMPORTANT, Please Note : The
"TapClean" HEPA Dust Cup Filter &
Debris Screen will stop most of the tiniest
dust particles and airborne allergens from
re-entering the air you breathe. In fact it
stops 99.97% of all particles as small as
0.3 microns - many times smaller than a
Tilt
human hair!!! Because of this incredible
Upwards
filtration performance, the HEPA Dust Cup
Filter will quickly accumulate, inside the
white filter folds, many fine dust particles
that are difficult to see but which will
eventually block or reduce your suction
power - if not cleaned properly. This can
cause the motor to overheat and the re-
settable thermostat to trip. (Should this
happen turn off the switch, unplug the unit
and allow unit to cool down. Clean the
HEPA Filter and Debris Screen as
described in this section, then reconnect
unit and proceed with vacuuming.)
1. Push the Power On/Off switch
to the OFF position to
disconnect the power.
2. Remove the flexible hose.
3. Remove the dust cup by lifting
the dust cup handle. See
illustration below.
Dust Cup Handle
OPERATING INSTRUCTIONS
4. Take the HEPA dust cup filter
out of the dust cup, do not let
dust fall out of dust cup.
5. Take the dust cup and dispose
of the dust inside.
6. Separate the debris screen from the
HEPA filter cartridge by grasping the
debris screen with one hand and the
filter frame with the other and pull
apart.
HEPA Filter
7. Vigorously "TapClean"
the HEPA Dust
Cup Filter on a
hard surface until no
more dust is observed
falling out from
between the pleats of
the filter. Please note
that on the under side of the HEPA
dust cup filter there is a small brush
which you can use to brush out the
pleats of the filter.
8. "TapClean" the Debris
Screen or rinse under
a faucet until clean.
Remember that
the Debris Screen
must be completely
dry before reinstalling
in the vacuum.
6
Debris Screen
