- Page 1 RF-505 PROFESSIONAL VEHICLE SECURITY OPERATIONS MANUAL THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY...
- Page 2 Congratulations on your purchase of the RF-505 vehicle security system. AutoPage, Inc. is one of the companies with the longest history and experience in vehicle security in the United States, and a wholly owned subsidiary of Iwata Electric Co., Tokyo, Japan. Iwata has been an industry leader for over 45 years, establishing a reputation for ingenuity in its engineering capability and innovative communication products.
- Page 3 RF-505 OPERATION INSTRUCTIONS Remote Transmitter Operation— Your Autopage Security comes with two 5-button Remote Control Transmitters. The transmitters feature a sophisticated code hopping system that will prevent illegal use of a code-grabbing device that may be used to record and steal your transmitter codes. ARM &...
- Page 4 CHANNEL AUXILIARY FUNCTION (OPTIONAL)— You may use the CAR button on your remote transmitter for a separate function. For example, if your vehicle is equipped with a factory electronic trunk release. The security system can be interfaced with the factory switch and electronically open your trunk by pressing the CAR button for 2 seconds on the remote transmitter.
-
Page 5: Passive Arming By-Pass
PASSIVE ARMING BY-PASS— The RF-505 security system can temporarily by-pass the passive arming function via the remote transmitter. To temporarily by-pass passive arming, exit the vehicle and close all doors. The LED will begin to fast flash the 30- second timer for passive arming. Within the 30-second timing window press the CAR button on the remote transmitter firmly twice, the security system will respond with (1) chirp and the LED will turn ON. - Page 6 PASSIVE ARMING OPERATION— The RF-505 provides a choice of arming capabilities. The alarm can be set to automatically arm, or be manually armed. This selection can be done using the remote transmitter. Follow these steps to turn ON or OFF passive (automatic) arming and manual arming: Press the “M”...
-
Page 7: Remote Transmitter Programming
To Exit the SIS-5P adjustment mode, press the “M” & “Lock/Unlock” buttons together. The siren or horn will sound 4 chirps confirming exit. The sensor adjust mode will automatically exit in 30 seconds if no signal is received. Transmitter Button Actions System Function Press &... -
Page 8: Second Car Operation
Second Car Operation— The transmitter for RF-505 has the capability to operate a second RF-505 alarm system. To program the transmitter to a second RF-505 follow these steps: 1. Repeat steps 1 & 2 from transmitter programming. 2. Press the side Shift button on the transmitter of the 2 car. - Page 9 Note: If your vehicle has the Keyless Entry option installed, you can still lock and unlock the vehicles doors with Remote Control Transmitter while in the Valet Mode. Automatic Rearm (Programmable)— If this feature is selected, the Security System will automatically re-arm itself 60 seconds after disarming with the Remote Control Transmitter.
- Page 10 LIMITED LIFETIME WARRANTY PROVISIONS (U.S. and Continental U.S. Only) AutoPage, Inc. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your AutoPage equipment is guaranteed for “life” to the original purchaser/user of the equipment under the following conditions: If the product proves defective (according to AutoPage’s testing) within the first year, the defective unit may be exchanged or repaired free of charge.
- Page 11 This WARRANTY CARD is for your record. However, AutoPage reserves the right to request you to submit this WARRANTY CARD which must have complete information to receive warranty service. Please keep this card in a secured place. AUTOPAGE WARRANTY SERVICE CARD Model RF-505 Serial # CUSTOMER TO COMPLETE...
- Page 12 1815 West 205 Street Suite 101 Torrance, California Main Office: 310-618-2002...
