- Page 1 RF-425LCD PROFESSIONAL VEHICLE SECURITY SYSTEM OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY...
-
Page 2: Transmitter Operation
TRANSMITTER OPERATION: Transmitter System Function Remark Button Lock Doors & Arm System Panic function Press and Hold for 3 seconds Car Locator Under armed mode Arm and Delete The 2 Stage Shock Press twice within 3 seconds Sensor Silent Arming / Disarming Ignition in "off"... -
Page 3: Passive Arming
PASSIVE ARMING: Active arming / disarming is controlling your security system via the remote transmitter. This security system is equipped with an optional Passive Arming feature, which allows the security system to arm 30 seconds after the last door is closed. Operation is as follows. 1. - Page 4 PATHWAY ILLUMINATION: This feature turns the parking light “ON” for 30 seconds upon a unlock signal and for 10 seconds upon the lock signal if programmed. TWO STEP DOOR UNLOCK: This feature will independently unlock the driver’s door only when disarming the security system.
-
Page 5: Noise Abatement Circuit
1. Light impacts will trigger the warn-away signal. A long chirp from siren/horn. 2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the ignition switch- All will trigger the programmed sequence. The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The siren and parking lights will turn on to alert of an intrusion for 30 seconds. -
Page 6: Car Locator
Press and hold button on transmitter for two seconds to remote control the trunk release or other electric devices. CHANNEL 3 CONTROL OUTPUT Press the buttons on the transmitter to active Channel 3 function CHANNEL 4 CONTROL OUTPUT Press the buttons on the transmitter to active Channel 4 function. -
Page 7: Battery Replacement
BATTERY REPLACEMENT: A 1.5V type AAA Alkaline battery powers the Remote Transmitter. When the power of the battery weakens a icon shall be displayed on the LCD screen. When the old battery is replaced to new one, there will be beep sounds indicate the power is up. - Page 8 2nd Car Operation: While the “II” icon display on the LCD screen, you can remote control and communicate with a second Autopage AM frequency security system. It has two short “bi” sounds while pressing the button of the LCD screen transceiver 1.
- Page 9 While the power save mode, the LCD remote transceiver “sleep” until a b utton is pushed, extends the life of battery. When power save mode is “Off”, the remote control will wake up periodically to check for messages from the security module. 1.
-
Page 10: Chirp Indicators
ALARM OPERATING CONDITION Function Siren Parking Doors Starter Dome Lights Disable Light 1. Arm 1 Chirp 1 Flash Slow flash Locking 2. Disarm 2or4 2 or 3 Off or Fast Unlocking Off On for Chirps Flashes flash 30 sec 3. Trigger Alarming Flashing Slow flash flashes... - Page 11 LIMITED LIFETIME WARRANTY PROVISIONS ( U.S. ,Continental U.S. and Canada Only) Auto Page, Inc. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your Auto Page equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the product proves defective (according to Auto Page's testing) within the first year, the defective unit may be exchanged or repaired free of charge.
- Page 12 Auto Page will void the product’s limited lifetime warranty. This WARRANTY CARD is for your record. However, AutoPage reserves the right to request you to submit this WARRANTY CARD which must have complete information to receive warranty service.
- Page 13 960 Knox Street Unit B Torrance, California 90502 Main Office: 310-323-1800 Customer Service: 800-262-2527 Ext. 462 www.autopageusa.com...
