Summary of Contents for Marantz UD9004

  • Page 1 ESPAÑOL FRANÇAIS ENGLISH Super Audio CD / Blu-Ray Disc player UD9004...
  • Page 2 ENGLISH FRANÇAIS ESPAÑOL IMPORTANT SAFETY CAUTION: SAFETY PRECAUTIONS should not be impeded by covering the ventilation INSTRUCTIONS openings with items, such as newspapers, tablecloths, curtains, CAUTION etc. Read these instructions. RISK OF ELECTRIC SHOCK Keep these instructions. placed on the unit. Heed all warnings.
  • Page 3 ESPAÑOL FRANÇAIS ENGLISH NOTE ON USE / OBSERVATIONS RELATIVES A L’UTILISATION FCC INFORMATION (For US customers) 1. COMPLIANCE INFORMATION product may not cause harmful interference, and (2) this product must accept any interference received, including interference that may cause undesired operation. 2.
  • Page 4: Table Of Contents

    ENGLISH Contents Features ·························································································· 2 Operations Enabled During Playback ········································ 43 GUI Menu Setup Pause Playback ··········································································· 43 Stop Playback (Resume Function) ············································· 43 Menu Map ···················································································· 23 Getting Started Skipping to the Chapter/Track/File You Want to Playback ········· 43 GUI Menu Operation ···································································...
  • Page 5: Features

    ENGLISH Features Getting Started Thank you for purchasing this MARANTZ product. To ensure proper operation, please read these owner’s manual carefully before using Universal Blu-ray Disc player that plays Super HDMI control ready the product. Audio CD and DVD-Audio formats vpage 49 “HDMI Control Function”...
  • Page 6: Cautions On Handling

    ENGLISH Cautions on Handling About Media Cautions on Installation • Before turning the power switch on Note: Playable Media Check once again that all connections are correct and that there are For proper heat dispersal, do not install this unit in a con ned no problems with the connection cables.
  • Page 7 ENGLISH About Media SD Memory Cards Files NOTE • A disc may not be accessible or play back incorrectly due to audio Playable Media Symbols and video interruptions, etc., depending on the recording conditions Symbols Used Playable les DVD-R/ when recorded with a BD recorder or DVD recorder. Playable Used Playable cards...
  • Page 8 ENGLISH About Media About DivX ® Video-on-Demand (VOD) n Super Audio CD GType of Super Audio CDH CDs are divided into several sections (tracks). These sections are ® le through the of cial site • When you purchase or rent a DivX all allotted numbers, called the track numbers.
  • Page 9: Cautions On Using Media

    ENGLISH About Media Cautions on Using Media Inserting a Disc About Handling of Media Cleaning Discs • Set the disc with the labeled side facing up. • Do not get ngerprints, oil or dirt on discs. • If there are ngerprints or dirt on discs, wipe them off before using •...
  • Page 10: About The Remote Control Unit

    Point the remote control unit at the remote sensor when operating Switches when the UD9004’s remote control operates another indicated direction. MARANTZ BD players in the vicinity. Set the remote control code simultaneously on the main unit, too. For how to set codes, see GUI menu: “Other Setup” – “Remote Control Setting”...
  • Page 11: Part Names And Functions

    ENGLISH Part Names and Functions Front Panel Display For buttons not explained here, see the page indicated in parentheses ( ). Playback mode indicators Time mode indicators 1 : During Playback TOTAL : Total time of Super Audio CD and CD 3 : During pause and step-by-step playback SING : Elapsed time of title/chapter/track/ le...
  • Page 12: Rear Panel

    ENGLISH Part Names and Functions Rear Panel For buttons not explained here, see the page indicated in parentheses ( ). VIDEO OUT S VIDEO OUT COMPONENT VIDEO OUT ( VIDEO ) ( AUDIO ) OPTICAL COAXIAL HDMI OUT DIGITAL OUT NETWORK 7.1ch AUDIO OUT OUT STRAIGHT CABLE...
  • Page 13: Remote Control Unit

    ENGLISH Part Names and Functions Remote Control Unit For buttons not explained here, see the page indicated in parentheses ( ). POWER ON/OFF buttons ·························································(22) SOUND MODE button ······························································(39) PURE DIRECT button ································································(40) RED/GRN/YEL/BLU buttons MODE button ············································································(33) SEARCH button ········································································(39) RANDOM button·······································································(46) SETUP button ···········································································(23) AUDIO button ···········································································(47)
  • Page 14: Connections

    ENGLISH Connections Connect the UD9004 as follows before using. Make connections according to the equipment you are connecting. Some UD9004 settings may be necessary depending on the connection method. Check each connection item for more information. vpage 13 Home Theater Playback Playing Back with a Direct Playing Back 2-Channel vpage 19...
  • Page 15: Preparation

    ENGLISH Preparation Cables Used for Connections Prepare the cables to match the devices you are to use. NOTE • Do not plug the power cord into the power outlet until all connections Video cables Audio and video cables are completed. Component video HDMI connections...
  • Page 16: Home Theater Playback - Playing Back Using Multi-Channel System

    ENGLISH 1. Home Theater Playback – Playing Back Using Multi-channel System – Using an HDMI Cable to Connect to an AV Amp or Television Default settings are underlined. q – t) using HDMI cable (sold separately). Con gure appropriate • There are 5 ways to connect ( Video and Audio Output Signal when Outputting to 2 HDMI Devices connection for HDMI mode rst and then set HDMI mode using HDMI MODE button.
  • Page 17 ENGLISH 1. Home Theater Playback – Playing Back Using Multi-channel System – Connection to a device with a DVI-D terminal q “HDMI Auto (Dual)”, w “HDMI Auto (Independent)” connection If you use a HDMI/DVI-D conversion cable (sold separately), HDMI video signals are converted to DVI- D signals, enabling connection to a device with a DVI-D terminal.
  • Page 18: Required Settings For Hdmi Connection

    ENGLISH 1. Home Theater Playback – Playing Back Using Multi-channel System – Setting HDMI Audio Output Required Settings for HDMI Connection • When you press SET UP button and set “HDMI Setup” – “Audio Setup” to “Auto” (vpage 25) on the Setting HDMI Video Output GUI menu, audio mode is set according to the connected device.
  • Page 19 ENGLISH 1. Home Theater Playback – Playing Back Using Multi-channel System – Audio signal from the HDMI output terminal You can change the audio format and playback number of channels according to the speci cations of Even if “HDMI Setup” – “Audio Setup” on the GUI menu is set to “Auto” (vpage 25), multilinear PCM the device to which the UD9004’s HDMI audio output signals are input.
  • Page 20: Connection To An Av Amp With No Hdmi Audio Input

    ENGLISH 1. Home Theater Playback – Playing Back Using Multi-channel System – Audio Signal from the Digital Audio Output (Optical/Coaxial) Terminal Connection to an AV Amp with No HDMI Audio Input The UD9004 can convert and output digital audio signal format recorded on media. When playing back Dolby Digital Plus/Dolby TrueHD/DTS-HD audio recorded on a BD disc, the UD9004 Convert the digital audio signal in accordance with the speci cations of the device that is to input digital outputs Dolby Digital or DTS bitstream from its digital audio output terminal.
  • Page 21: Connecting To A Device With An Analog Multi-Channel Audio Input Terminal

    ENGLISH 1. Home Theater Playback – Playing Back Using Multi-channel System – Connecting to a Device with an Analog Multi-channel Audio Connection to an AV Amp with No HDMI Video Input Input Terminal Check the video terminals and make the connection to one of them. Outputs multi-channel audio decoded by the UD9004.
  • Page 22: Playing Back With A Direct Connection To A Tv

    ENGLISH 2. Playing Back with a Direct Connection to a TV Check the television’s audio and video terminals and make the connection to one of them. When connected to the television’s component video input terminal • The UD9004’s component video output supports 480i/576i/480p/576p/720p/1080i output. Match the Audio terminals Video terminal S video input...
  • Page 23: Playing Back 2-Channel Audio

    ENGLISH 3. Playing Back 2-Channel Audio 4. Recording a CD Connecting to a Device with Analog 2-channel Audio Input Connecting to a Digital Recording Device Terminal with Balanced Cable MD Recorder Select “Audio Setup” – “XLR” (vpage 30) from the GUI menu beforehand to match the device to be AUDIO connected.
  • Page 24: Updating To The Ud9004'S Latest Software Version

    • The router you can use varies with the ISP . For more information, contact your ISP or PC dealer. • MARANTZ assumes no responsibility whatsoever for any communication errors or troubles resulting from customer's network environment or connected devices.
  • Page 25: Connecting The Power Cord

    ENGLISH Connecting the Power Cord Once Connections are Completed Connect the included power cord to the UD9004, and plug it into an AC outlet. Turning the Power On To household power Press the unit’s POWER ON/STANDBY button or the outlet (AC 120 V, 60 Hz) remote control’s POWER ON/OFF button.
  • Page 26: Gui Menu Setup

    ENGLISH GUI Menu Setup Menu Map Pressing SET UP button displays the GUI menu. From this menu, you can move to various setting screens. Language Setup (vpage 25) Dialog Disc Menus Subtitle GUI Language HDMI Setup (vpage 25, 26) Auto Format Audio Setup Color Space SA-CD Audio Out...
  • Page 27: Gui Menu Operation

    ENGLISH GUI Menu Operation Press SET UP button. Examples of GUI Menu Screen Displays The GUI menu is displayed on the TV screen. Press d, f, 1 buttons to select the Typical examples are described below. menu to be set or operated. GExample 1H Menu selection screen (Top menu) GExample 2H Rating Country Code input screen (with 0 or...
  • Page 28: Language Setup

    ENGLISH Language Setup HDMI Setup Default settings are underlined. Default settings are underlined. Set the language used for playback dialogs, subtitles, and menus. Set the HDMI output signal or HDMI control function. Setting items Setting contents Setting items Setting contents Dialog Original : Plays the dialog selected at the top in the language menu...
  • Page 29: Video Setup

    ENGLISH HDMI Setup Video Setup Default settings are underlined. Setting contents Setting items Set the video output signal according to the connected TV. SA-CD Audio Out On : Super Audio CD audio is output. Setting items Setting contents Set to output stereo/multi Off : Super Audio CD audio is not output.
  • Page 30: Audio Setup

    ENGLISH Audio Setup Default settings are underlined. Set the speaker or audio to be output. Setting items Setting contents Setting related to each channel setting and other audio in the case of outputting analog GSurroundH 7.1ch Audio Out Set the presence and size of the Surround speakers. audio signals decoded by the UD9004.
  • Page 31 ENGLISH Audio Setup Setting contents Setting contents Setting items Setting items 7.1ch Audio Out GCrossover Freq.H : Set the upper limit of the low frequency signals n Channel Level : Set the volume of the test tone to be the same when 7.1ch Audio Out output from the subwoofer.
  • Page 32 ENGLISH Audio Setup Setting contents Setting contents Setting items Setting items Source Direct Off : Enable the speaker and subwoofer settings. BD Effect Sound On : Outputs BD effect sound. Disable the speaker and On : 50kHz : Output the disc contents as is. When playing Super Audio Sets for a click sound and Off : Does not output BD effect sound.
  • Page 33: Pure Direct Setup

    ENGLISH Audio Setup Pure Direct Setup Default settings are underlined. Setting contents Setting items Makes settings regarding digital audio and video output modes during Pure Direct mode, GTerminal PolarityH Set the polarity of the XLR terminal. as well as display messages. Two types of setting can be registered. Set the signal to be output •...
  • Page 34: Ratings

    ENGLISH Ratings Network Setup Default settings are underlined. Default settings are underlined. Set BD or DVD parental lock or display DivX ® registration codes. Set to connect to the Internet. To obtain update support for your UD9004, you can download the latest rmware from Setting items Setting contents our website.
  • Page 35: Display Setup

    Remote Control Setting “Off” by the Dimmer Control (Main unit side) Switches the UD9004’s remote control ID code when other MARANTZ (vpage 49) or Pure Direct Set the remote control. BD Players are in the vicinity. Function (vpage 40), this •...
  • Page 36: Various Settings

    Do not turn off the power until updating is completed. • Information regarding the “Firmware Update” function will be announced on the MARANTZ web site In the case of Dolby TrueHD, Dolby Digital Plus and DTS-HD audio each time related plans are de ned.
  • Page 37: Changing The Playback File Display

    ENGLISH Setting the Audio Mode Default settings are Changing the Playback File Display underlined. Setting contents Setting items Setting items Setting contents GPLgx ModeH : Sets to Dolby Pro Logic gx mode. Surround Parameters All : Plays back MP3/WMA/AAC/LPCM/JPEG/DivX ® les. File lter GPLg ModeH : Sets to Dolby Pro Logic g mode.
  • Page 38: Adjusting The Picture Quality (Picture Control)

    ENGLISH Adjusting the Picture Quality (Picture Control) You can adjust the picture quality to your liking. About Gamma Correction Setting You can store up to a maximum of 5 values in memory. Setting items Default contents When you select “Gamma Correction”, and then press ENTER button, Press PICT.
  • Page 39: Playback

    ENGLISH Playback Introduction About Playback Information Disc playback vpage 37, 38) Playing BD and DVD-Video ( Displayed playback information changes between vpage 39) Playing Back Super Audio CD ( Before Playing a Disc the information bar and media player screen each vpage 39) CD Playback ( time DISPLAY button is pressed.
  • Page 40: Media Player Display

    ENGLISH About Playback Information Playing BD and DVD-Video Disc Information Display Media Player Display DVD-V • Title Title being played/total number of titles • Chapter Chapter being played/total number of SA-CD LPCM Playback preparation (“Before Playing a Disc” chapters vpage 36). •...
  • Page 41 ENGLISH Playing BD and DVD-Video Playing Bonus View Press MODE button to select the secondary video display you wish to playback. GSelectable itemH : Does not display Secondary Video. 1/X z : Displays the rst Secondary Video . GExampleH Disc menu GExampleH Top menu 2/X z : Displays the second Secondary Video.
  • Page 42: Playing Back Super Audio Cd

    ENGLISH Change Group/Track CD Playback Playing Back Super Audio CD During stop or during playback, select search mode SA-CD Playback preparation (“Before Playing a Disc” with SEARCH button. vpage 36). Playback preparation (“Before Playing a Disc” Search mode is displayed in the top right of the screen. vpage 36).
  • Page 43: Playing Back High-Quality Audio

    ENGLISH DVD-Audio Playback Playing Back High-Quality Audio File Playback Bonus Group playback (Pure Direct Function) About the File Display DVD-Audio may have a bonus group that can be played back on entry The limits on the number of folders and les that can be displayed DVD-A DVD-V SA-CD...
  • Page 44: File Playback

    ENGLISH File Playback About folder and le displays File Playback n File Browser Screen All Track Mode LPCM DivX JPEG Press RANDOM Folder Mode Turn the UD9004 power on. button. Press PROG/DIRECT Random playback off button. Selected folder number/ Random playback on Folder Mode Total number of folders Press SD/DISC button, and select the...
  • Page 45: About Screen Display During Playback

    ENGLISH File Playback About Screen Display During Playback Operation During Playback • Set the image display time on the GUI menu with: “Display Setup” – “Slide Show Time” (vpage 32). Audio le and DivX ® le operation Display during Playback of Audio Files •...
  • Page 46: Operations Enabled During Playback

    ENGLISH Operations Enabled During Playback Skipping to the Chapter/Track/File You Operations Enabled During Playback If the video is blurred during pause, stop playback Want to Playback vpage 43) Pause Playback ( and press SET UP button, then, on the GUI menu, vpage 43) Stop Playback (Resume Function) ( change “Display Setup”...
  • Page 47: Looking For Speci C Sections Using The Search Modes

    ENGLISH Operations Enabled During Playback GSearch mode-compatible media and lesH Looking for Speci c Sections Using the Media / le DVD-A SA-CD DivX • Entering numbers Search Modes Entering 3 ··········································· 3, ENTERz DVD-V LPCM JPEG DVD-A DVD-V SA-CD Entering 26 ············· 2, 6, ENTERz or +10, +10, 6 Entering 138 ·······························1, 3, 8, ENTERz Search mode LPCM...
  • Page 48: Memorizing Locations You Want To Replay (Marker Function)

    ENGLISH Operations Enabled During Playback To Play Back Memorized Locations Memorizing Locations You Want to Step-by-Step Playback Use 0, 1 buttons to select the marker number, Replay (Marker Function) then press ENTER button. DVD-V DivX DVD-V DVD-A DivX To erase markers Press 3 button during pause.
  • Page 49: Playback In Any Order (Random Playback)

    ENGLISH Operations Enabled During Playback Playing Back Repeatedly Playback in Any Order Repeat Playback Between Speci ed (Repeat Playback) (Random Playback) Points (A-B Repeat) DVD-A DVD-V SA-CD SA-CD DVD-A DVD-V SA-CD LPCM DivX DivX LPCM DivX JPEG Press RANDOM button during stop. During playback, press REPEAT A-B button at the The “RAND”...
  • Page 50: Playing Back In Your Preferred Order (Program Playback)

    ENGLISH Operations Enabled During Playback Erasing Programmed Tracks One by One Select your desired audio language with d, f Playing Back in Your Preferred Order Press CLEAR button during stop. buttons. (Program Playback) Erasing All Programmed Contents SA-CD Press PROG/DIRECT button. Audio Primary 2/5 : Dolby Digital 3/2.1 Japanese...
  • Page 51: Changing The Subtitles And Subtitle Style

    ENGLISH Operations Enabled During Playback Audio Switching (Media Other than BD) Changing the Subtitles and Subtitle Press AUDIO button during playback. • If a disc does not include subtitles and subtitle style, “Not Available” Style is displayed. The audio number currently being played is displayed. DVD-V DivX •...
  • Page 52: Switching The Angle

    ENGLISH Operations Enabled During Playback HDMI Control Function Switching the Angle When you make an HDMI connection with a TV or AV Amp compatible Set the HDMI output terminal corresponding with DVD-V with UD9004 and HDMI control functions, you can perform the the HDMI control function.
  • Page 53: Other Information

    ENGLISH Other Information About Copyright Protection Trademark Information ® , HDCD ® , High De nition Compatible Digital ® and Microsoft ® are Technology This product uses the following technologies: either registered trademarks or trademarks of Microsoft Corporation, Inc. in the United This product incorporates copyright protection technology that is “Blu-ray Disc”...
  • Page 54: Language Code List

    ENGLISH Language Code List Language Code Language Code Language Code Abkhazian 4748 Icelandic 5565 Samoan 6559 Afar 4747 Indonesian 5560 Sangho 6553 4752 5547 6547 Afrikaans Interlingua Sanskrit 6563 5551 5350 Albanian Interlingue Scots Gaelic 4759 5557 6564 Amharic Inupiak Serbian Arabic 4764...
  • Page 55: Country Code List

    ENGLISH Country Code List Country Code Country Code Country Code Country Code Country Code AFGHANISTAN CUBA JORDAN NORFOLK ISLAND TAJIKISTAN NORTHERN MARIANA TANZANIA, UNITED ÅLAND ISLANDS CYPRUS KAZAKHSTAN ISLANDS REPUBLIC OF ALBANIA CZECH REPUBLIC KENYA OMAN TIMOR-LESTE ALGERIA DJIBOUTI KIRIBATI PALAU TOGO KOREA, DEMOCRATIC...
  • Page 56: Explanation Of Terms

    ENGLISH Explanation of Terms Dolby Digital (5.1ch Surround) Numerics This is a stereophonic effect developed by Dolby Laboratories. This is 4:3 letterbox maximum 5.1 channels of independent multi-channel audio system. When a wide (16 : 9) disc is played back by connecting a 4 : 3 TV and This is an abbreviation of Low Frequency Effect, which is an output Dolby Digital Plus the UD9004, this function plays back the image with black area at the...
  • Page 57: Index

    ENGLISH Index Playback(DVD) ·················································································37 vNumerics page page Playback(Super Audio CD) ······························································39 2ch Balanced Connection ·······························································20 File ·································································································4, 5 Playback(CD) ···················································································39 File Browser Screen ········································································41 Playback(DVD-Audio) ······································································39 page Finalise ························································································4, 53 Playback(JPEG) ···············································································42 Firmware Update ············································································33 Power Saving ··················································································32 Adjusting the Picture Quality ··························································35 Folder ································································································5 Analog 7.1ch Connection ·······························································18 Primary Audio ··················································································53...
  • Page 58: Troubleshooting

    ENGLISH Troubleshooting If a problem should arise, rst check the following: Symptom Cause / Countermeasure Page 1. Are the connections correct? audio • Set “BD Audio Mode” to “HD Audio Output”. 2. Is the set being operated as described in the owner’s manual? output.
  • Page 59 ENGLISH Symptom Cause / Countermeasure Page No return to start-up • There may be an internal error. Set the power to standby, wait – screen when disc is awhile, then turn the power back on. removed. The set cannot be •...
  • Page 60: Speci Cations

    ENGLISH Speci cations Audio performance General Signal format : NTSC Power supply : AC 120 V, 60 Hz Applicable discs /memory cards : (1) BD-Video discs : Power consumption : 88 W 12 cm 1 side 1 layer, 12 cm 1 side 2 layers (vpage 32 “Power Saving”) •...
  • Page 62 License This section describes software license used for UD9004. To maintain the correct content, the original 4. You may not copy, modify, sublicense, or distribute These requirements apply to the modi ed work as a whole. If identi able sections of that work are not the Program except as expressly provided under this (English) is used.
  • Page 63 8. If the distribution and/or use of the Program is restricted END OF TERMS AND CONDITIONS Finally, software patents pose a constant threat to the in certain countries either by patents or by copyrighted How to Apply These Terms to Your New Programs existence of any free program.
  • Page 64 TERMS CONDITIONS COPYING, in the event an application does not supply such function 5. A program that contains no derivative of any portion b) Use a suitable shared library mechanism for linking DISTRIBUTION AND MODIFICATION or table, the facility still operates, and performs whatever of the Library, but is designed to work with the Library with the Library.
  • Page 65 9. You are not required to accept this License, since 13. The Free Software Foundation may publish revised <one line to give the library’s name and a brief idea of you have not signed it. However, nothing else grants and/or new versions of the Lesser General Public what it does.>...
  • Page 66 install.doc How to con gure and install the The library is intended to be reused in other applications. These conditions apply to any software derived from or (Adjacent articles in that issue discuss MPEG motion IJG software. In order to support le conversion and viewing software, based on the IJG code, not just to the unmodi ed library.
  • Page 67 A PostScript version of this document is available by FTP If you are on a Unix machine, we highly recommend Jef The current method for scaling the quantization tables The PNG Reference Library is supplied “AS IS”. at ftp://ftp.uu.net/graphics/jpeg/j f.ps.gz. There is also a Poskanzer’s free PBMPLUS software, which provides is known not to be very good at low Q values.
  • Page 68 1. No Warranty • http://www.freetype.org b) use the modi ed Package only within your THE FREETYPE PROJECT IS PROVIDED ‘AS IS’ Holds the current FreeType web page, which will allow corporation or organization. The FreeType Project LICENSE WITHOUT WARRANTY OF ANY KIND, EITHER you to download our latest development version and c) rename any non-standard executables so the 2002-Apr-11 Copyright 1996-2002 by David Turner, Robert...
  • Page 69 ALTERNATIVELY, this product may be distributed under THIS SOFTWARE IS PROVIDED BY THE REGENTS AND IN NO EVENT SHALL ISC BE LIABLE FOR ANY SPECIAL, The author (Panagiotis Tsirigotis) grants permission to use, the terms of the GNU General Public License, in which CONTRIBUTORS “AS IS”...
  • Page 70 THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT IN NO EVENT SHALL THE OpenSSL PROJECT OR THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS 1. Redistributions of source code must retain the WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, IS”...
  • Page 71 Laboratory, which is operated by Universities Research 1. Redistributions of source code must retain the Association, Inc., under contract DE-AC02-76CHO3000 MARANTZ provides the source code based on the above copyright notice, this list of conditions and the with the U.S. Department of Energy.
  • Page 72 You can find your nearest authorized distributor or dealer on our website. is a registered trademark. Printed in Japan 07/2009 541110297028M mzh-d...
