Operating Instructions & Parts Manual
Model
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
ADVERTENCIA
!
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Hydraulic Toe Jacks
13060
13120
13200
Capacity
3 Ton
6 Ton
10 Ton
WARNING
!
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use adequately rated
jack stands.
http://www.omegalift.com
SFA Companies
Printed in Taiwan
13060-M0 rev 07/08
Advertisement
Table of Contents
Related Manuals for Omega Lift 13120
Summary of Contents for Omega Lift 13120
- Page 1 Operating Instructions & Parts Manual Hydraulic Toe Jacks Capacity Model 13060 3 Ton 6 Ton 13120 10 Ton 13200 This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING ADVERTENCIA To avoid crushing and related injuries:...
-
Page 2: Product Description
Save these instructions. For your safety, read, understand, WARNING and follow the information provided with and on this jack before using. The owner and/or operator of this equipment To avoid personal injury and/or property damage: shall have an understanding of this jack and safe operating •... -
Page 3: Specifications
SPECIFICATIONS Base Size Toe Saddle Head Saddle Model Capacity Hydraulic Lift (L x W) Min. / Max Height Min. / Max. Height 13060 3 Ton 8-5/8" x 7-1/2" 5/8" ~ 5-3/4" 9" ~ 14-1/8" 5-1/8" 13120 6 Ton 11" x 7-1/2" 7/8"... -
Page 4: Maintenance
MAINTENANCE Important: Use only good grade hydraulic jack oil. Avoid mixing different types of fluid and NEVER use brake fluid, turbine oil, transmission fluid, motor oil or glycerin. Improper fluid can cause premature failure of the jack and the potential for sudden and immediate loss of load. - Page 5 Replacement Parts Illustration for Model 13060 Figure 2 - Replacement Parts Illustration for Model 13060...
- Page 6 Replacement Parts List for Model 13060 Item Part# for 13060 Description Qty. 136-3-1108-109 Saddle 522-2-0206-104 Return Spring 115-6-1808-102 Retainer Ring O-ring 136-6-1204-103 Guide Ring O-ring Piston Rod Back-up Ring U-cup 599-7-0360-103 Guide Ring Base Assy. Steel Ball 511-2-0050-025 Spring Washer 649-1-0080-046 Bolt Oil Seal...
- Page 7 Replacement parts illustration for Model 13120 Figure 3 - Replacement Parts Illustration for Model 13120...
- Page 8 Replacement Parts List for Model 13120 Item Part# for 13120 Description Qty. 186-3-1108-109 Saddle 522-2-0206-104 Return Spring Dust Wiper 186-6-1810-304 Cylinder Fastener O-ring O-ring 186-6-1204-103 Guide Ring Piston Rod Back-up Ring U-cup Guide Ring Base Assy. 181-3-2100-103 Handle Assy. 226-3-1300-102 Handle Sleeve Assy.
- Page 9 Replacement parts illustration for Model 13200 Figure 4 - Replacement Parts Illustration for Model 13200...
- Page 10 Replacement Parts List for Model 13200 Item Part# for 13200 Description Qty. 226-3-1108-100 Saddle 522-2-0206-104 Return Spring 226-6-1808-106 Retainer Ring Dust Wiper Dust Wiper Set 226-5-1204-108 Guide Ring O-Ring Piston Rod Back-up Ring U-cup 226-6-1209-104 Bearing Base Assy. G55-4-1900-105 Vent Screw Assy. 226-3-1300-102 Handle Sleeve Assy.
-
Page 11: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products, which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy. - Page 12 Note Page Contact: SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. Tel:(888)332-6419 Fax:(816)891-6599 E-Mail:sales@omegalift.com Omega Website: http://www.omegalift.com...
