Craftsman 315.23743 Owner's Manual

7 1/2 inch radial arm miter saw double insulated with mechanical brake
Hide thumbs

Advertisement

OWNERS
MANUAL
MODEL NO.
315.23/43
Serial
Number
Model
and
serial
number
may be found
on plate
at
motor
end cap,
You
should
record
both
model and serial number
in
a safe place for future
use.
CAUTION:
Read Rulesfor
Safe Operation
and Instructions
Carefully
SAVE THIS
MANUALFOR
FUTURE
REFERENCE
CRAFTSMAN _
71/2 INCH RADIAL
ARM MITER SAW
DOUBLE INSULATED
WITH MECHANICAL
BRAKE
Introduction
Assembly
Operation
Maintenance
Repair Parts
q,-,J,4h,, q_'&_S,
ROEBUCK
AND CO., Dept. 698/731A,
Sears Tower,
Chicago,
IL 60684
612547-228
PP, I NTEO
IN
U,S,A
