MICROWAVE HOOD COMBINATION
INSTALLATION INSTRUCTIONS
This product is suitable for use above electric cooking products up to 36" (91.4 cm) wide.
These installation instructions cover different models. The appearance of your particular model may differ slightly from the
illustration in these installation instructions.

MICROWAVE HOOD COMBINATION SAFETY

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
8206650
MICROWAVE HOOD COMBINATION SAFETY .............................. 1
INSTALLATION REQUIREMENTS ................................................... 2
Tools and Parts............................................................................... 2
Location Requirements................................................................... 2
Product Dimensions ....................................................................... 3
Electrical Requirements .................................................................. 3
INSTALLATION INSTRUCTIONS ..................................................... 4
Remove Mounting Plate ................................................................. 4
Rotate Blower Motor....................................................................... 4
Locate Wall Stud(s) ......................................................................... 6
Mark Rear Wall................................................................................ 7
Drill Holes in Rear Wall.................................................................... 7
Attach Mounting Plate to Wall ........................................................ 8
Prepare Upper Cabinet................................................................... 8
Install Damper Assembly ................................................................ 9
Install the Microwave Oven ............................................................ 9
Complete Installation .................................................................... 10
VENTING DESIGN SPECIFICATIONS............................................ 11
ASSISTANCE ................................................................................... 12
Replacement Parts ....................................................................... 12
Accessories................................................................................... 12
Your safety and the safety of others are very important.
DANGER

Table of Contents

You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
