Using QuickLoop

QuickLoop Implementation

QuickLoop is implemented by a combination of hardware and software
components, and requires no actions on the part of the user once it is installed and
configured.
Topics in this section include:

Terminology

The terms and concepts introduced in this section are fundamental to
understanding the use of QuickLoop mode with StorageWorks SAN switches.
Topics include:

Storage Devices

The following two port types are on host or storage devices, not on switches.

Switch Ports

Each port can be independently configured as one of various types:
20
Terminology, page 20
Dual-switch QuickLoop, page 21
QuickLoop Initialization, page 22
Storage Devices
Switch Ports
N_port—(Node port) An equipment port that is not loop capable. Used to
connect the equipment to the fabric.
NL_port—An equipment port that is loop capable. Used to connect an
equipment port to the fabric in a loop configuration through the FL_Port on a
switch.
F_port—A fabric port that is not in loop mode. Able to transmit under fabric
protocol, and interface over links. N_Ports on equipment connect to F_Ports
on switches.
FL_port—A fabric port on a switch that is in loop mode. Used to connect loop
capable NL_Ports to the switch in a loop configuration.
L_port—A node port (NL_port) or fabric port (FL_port) that has arbitrated
loop capabilities.
QuickLoop Fabric Assist Version 3.1.x User Guide
