ADI A515 User Manual

15" tft lcd color monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NEXT
A515
A515
User's Guide
www.adi-deutschland.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A515 and is the answer not in the manual?

Questions and answers

Related Manuals for ADI A515

Summary of Contents for ADI A515

  • Page 1 NEXT A515 A515 User's Guide www.adi-deutschland.com...
  • Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Standards and Recommendations Safety and Radio Interference Approvals This product is designed in conformity with the following standards or other normative documents : Safety : EN 60950 : 1992 + A1, A2, A3, A4, A11 : EN 55022 : 1998, EN 55024 : 1998 EN 61000-3-2 : 1995+A1 : 1998+A2 : 1998 EN 61000-3-3 : 1995 to satisfy the basic requirements of Safety and EMC required by following Directives :...

  • Page 4: Table Of Contents

    Contents A515 15" TFT LCD Color Monitor 1. Introduction ...1/20 2. Safety Information ...1/20 3. Installing the monitor ...4/20 3-1. Packing List ...4/20 3-2. Selecting a suitable location ...5/20 3-3. Connecting the monitor ...5/20 USB hub ...7/20 3-4. Setting the refresh rate ...8/20 Preset Timing Table ...9/20...

  • Page 5: Introduction

    1. Introduction 2. Safety Information A515 15" TFT LCD Color Monitor This manual contains instructions for installing and operating A515. A515 is a highly ergonomic color display unit. • 15" viewable XGA LCD • Supporting full scan flicker-free picture quality •...
  • Page 6 A515 15" TFT LCD Color Monitor Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~35°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.

  • Page 7: Cleaning And Maintenance

    Cleaning and Maintenance A515 15" TFT LCD Color Monitor • To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning.

  • Page 8: Installing The Monitor

    3. Installing the monitor 3-1. Packing List A515 15" TFT LCD Color Monitor The following items should be found in the packaging. Compact Disc USB cable AC/DC Power adapter Above power cord can be changed upon different voltage areas. Please contact your dealer if anything is missing or damaged.

  • Page 9: Selecting A Suitable Location

    3-2. Selecting a suitable location 3-3. Connecting the monitor A515 15" TFT LCD Color Monitor • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. • Place the monitor in a position where no light shines directly onto or is reflected on the screen.
  • Page 10 A515 15" TFT LCD Color Monitor Turn on the power to the computer. The picture will appear within about 10 seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information.

  • Page 11: Usb Hub

    A515 15" TFT LCD Color Monitor USB hub The USB hub(Bus-powered mode hub) have 1 upstream port and 2 downstream ports. The upstream port can be connected to the root hub of host PC or other downstream port. Two(2) downstream ports allow to connect another USB device such as USB mouse, joystick, printer etc.

  • Page 12: Setting The Refresh Rate

    3-4. Setting the refresh rate A515 15" TFT LCD Color Monitor Power Switch / LED Indicator Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000. Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon.

  • Page 13: Preset Timing Table

    A515 15" TFT LCD Color Monitor Preset Timing Table The recommended setting is a resolution of 1024x768 and a refresh rate of 60Hz. * Recommended primary mode. If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user guide of videocard because the screen may not be displayed.

  • Page 14: User's Environment

    3-5. User’s Environment A515 15" TFT LCD Color Monitor With the double-hinge structure in the stand, this display unit is designed to Support the following user’s environment. • Without special Mounting Devices for VESA FPMPMI Standard, you can hang this display unit on the wall by using 2 holes in the bottom side of stand like the below picture.

  • Page 15: Vesa Mount'g

    * Ergotron, Inc. · Address : Ergotron Europe Kuiperbergweg 50 1101 AG Amsterdam The Netherlands · Tel : +3 1 20 696 60 65 · Fax : +3 1 20 609 04 59 · E-mail : info.eu@ergotron.com Desk Mount Wall Mount...

  • Page 16: Adjusting The Picture

    4. Adjusting the picture A515 15" TFT LCD Color Monitor You can adjust the screen display by using the buttons located below the screen. BACK NEXT 12/20...

  • Page 17: Using The On Screen Display

    4-1. Using the On Screen Display 4-2. Direct access buttons A515 15" TFT LCD Color Monitor Push the MENU button to call the OSD to the screen. The resolution and frequency are displayed at the top of the menu box for your information.

  • Page 18: Osd Adjustments

    You can play the movie file to see how to adjust the picture image by clicking each icon or title hereunder. A515 15" TFT LCD Color Monitor The OSD adjustments available to you are listed below. BRIGHTNESS Adjust the brightness of the screen.
  • Page 19 A515 15" TFT LCD Color Monitor CLOCK PHASE PHASE Adjust the noise of the screen image. CLOCK Adjust the horizontal size of the entire screen image. AUTO ADJUST You can adjust the shape of screen automatically at the full screen pattern.

  • Page 20: Display Power Management

    5. Display power management Reducing power consumption A515 15" TFT LCD Color Monitor If the power management function of your computer is enabled, your monitor turns on and off automatically. You can control power management features from your computer. Your computer may have power management features which enable the computer or monitor to enter a power saving mode when the system is idle.

  • Page 21: Troubleshooting

    6. Troubleshooting A515 15" TFT LCD Color Monitor If your monitor is not functioning properly, you may be able to solve the problem by following the suggestions below : Problem Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on.
  • Page 22 A515 15" TFT LCD Color Monitor Problem Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section OSD shape or quality Adjustment(4-3).

  • Page 23: Contacting Service

    Contacting service A515 15" TFT LCD Color Monitor Problem The power LED is a LED Indicator can be orange color on changing of video mode or orange color Input Signal. Check the Resolution and the frequency on the video part of your computer.

  • Page 24: Specifications

    7. Specifications A515 15" TFT LCD Color Monitor 15"viewable, Diagonal Pixel pitch 0.297 mm, A-Si TFT Brightness 250cd/m Response Time 20msec Display area 304 X 228 mm Number of color 16.2 million colors Input signals R.G.B Analog, 15 pin D-sub Frequency rate Horizontal : 31.0 to 60.0KHz, Vertical : 56 to 75Hz...
