P700
P700
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P700 and is the answer not in the manual?

Questions and answers

Related Manuals for ADI P700

Summary of Contents for ADI P700

  • Page 1 NEXT P700 P700 User's Guide...
  • Page 2 BACK U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION NEXT RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 BACK Standards and Recommendations NEXT Safety and Radio Interference Approvals This product is designed in conformity with the following standards or other normative documents : Safety : EN 60950 : 1992 + A1, A2, A3, A4 : EN 55022 : 1998, EN 55024 : 1998 EN 61000-3-2 : 1995+A1 : 1998+A2 : 1998 EN 61000-3-3 : 1995 to satisfy the basic requirements of Safety and EMC required by following Directives :...

  • Page 4: Table Of Contents

    BACK P700 Multiscanning Color Monitor NEXT Contents 1. Introduction ......1/19 2. Safety Information ....1/19 3. Installing the monitor ....3/19 3-1. Packing List ........3/19 3-2. Fastening the swivel and tilt base ..4/19 3-3. Selecting a suitable location ..4/19 3-4. Connecting the monitor ....5/19 3-5.

  • Page 5: Introduction

    BACK P700 Multiscanning Color Monitor NEXT 1. Introduction This manual contains instructions for installing and operating P700. P700 is a highly ergonomic color display unit; • 17” diagonal (15.7” viewable) 0.26mm dot pitch CDT • Supporting high screen refresh rates and full scan flicker-free picture quality •...
  • Page 6 BACK P700 Multiscanning Color Monitor NEXT Cleaning and Maintenance • To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning.

  • Page 7: Installing The Monitor

    BACK P700 Multiscanning Color Monitor NEXT 3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Japan Attached Signal Cable America/Canada Europe South Africa Australia Korea Tilt and Swivel Compact Disc Power cord Above power cord can be changed upon different voltage areas. Please contact your dealer if anything is missing or damaged.

  • Page 8: Fastening The Swivel And Tilt Base

    BACK P700 Multiscanning Color Monitor NEXT 3-2. Fastening the swivel and tilt base • Place the base against the bottom of the monitor so that the base fasteners are aligned with appropriate slots. • Push the base towards the front of the monitor until the latch locks into position.

  • Page 9: Connecting The Monitor

    BACK P700 Multiscanning Color Monitor NEXT 3-4. Connecting the Before you start cabling your monitor, check that monitor the power is off on all units. To avoid any possibility of electric shock, always connect your equipment to properly earthed outlets.
  • Page 10 BACK P700 Multiscanning Color Monitor NEXT Insert the 15-pin signal cable connector to the VGA connection on your computer and screw it down. Plug the display unit’s power cable first to the back of the display unit. Then plug the power cable to a 100V - 240V earthed electrical outlet or to the system unit, if it has an outlet for the display power cable.

  • Page 11: Setting The Refresh Rate

    BACK P700 Multiscanning Color Monitor NEXT 3-5. Setting the refresh Follow the instructions below to set your refresh rate in Windows 98. rate Go to the configuration window (Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab.

  • Page 12: Adjusting The Picture

    BACK P700 Multiscanning Color Monitor NEXT 4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. 8/19...

  • Page 13: Using The On-Screen-Display

    BACK P700 Multiscanning Color Monitor NEXT 4-1. Using the On Screen Push the MENU button to call the OSD to the screen. The resolution and Display frequency are displayed at the top of the menu box for your information. Push the button to choose the item you want to adjust.

  • Page 14: Osd Adjustments

    BACK P700 Multiscanning Color Monitor NEXT 4-3. OSD Adjustments The OSD adjustments available to you are listed below. H. SIZE You can play the movie file Adjust the horizontal size of the entire screen image. to see how to adjust the picture image by clicking H.
  • Page 15 BACK P700 Multiscanning Color Monitor NEXT PIN BALANCE If the sides of the picture are bowed to the right or to the left, you can correct the pincushion balance by using this adjustment. V. MOIRE Clears vertical moire if a series of concentric circles or arcs appear on your screen.
  • Page 16 BACK P700 Multiscanning Color Monitor NEXT H. LINEARITY If either left or right side of the picture is out of proportion to the other, you can correct horizontal linearity by using this adjustment. V. LINEARITY If top and bottom side of the picture is out of proportion to the center area, you can correct vertical linearity by using this adjustment.
  • Page 17 BACK P700 Multiscanning Color Monitor NEXT COLOR CONTROL Color temperature affects the tint of the 93.8K 75 image. With lower color temperatures the image turns reddish and with higher temperatures bluish. There are three color settings available: 9300K, 6500K or USER. With the USER setting you can set individual values for red, green and blue.
  • Page 18 BACK P700 Multiscanning Color Monitor NEXT If you have tilted, swiveled or moved the display unit, you can perform demagnetization. During this process the picture is distorted for a few seconds. After demagnetizing, the color impurities have disappeared if caused by stray magnetic fields.

  • Page 19: Display Power Management

    BACK P700 Multiscanning Color Monitor NEXT 5. Display power If the power management function of your computer is enabled, your monitor management turns on and off automatically. You can control power management features from your computer. Reducing power Your computer may have power management features which enable the computer consumption or monitor to enter a power saving mode when the system is idle.

  • Page 20: Troubleshooting

    BACK P700 Multiscanning Color Monitor NEXT 6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by following the suggestions below : Problem Possible solution Blank screen If the power LED is not lit, push the Power switch to turn the monitor on.
  • Page 21 BACK P700 Multiscanning Color Monitor NEXT Problem Possible solution The display does The video signal from the computer does not comply with VESA not enter power DPMS standard. Either the computer or the graphics adapter is not management using the VESA DPMS power management function.
  • Page 22 BACK P700 Multiscanning Color Monitor NEXT Contacting service If the above troubleshooting hints do not help you find a solution to the problem, contact an authorized service agent. If the monitor is sent for service, use the original package if possible.

  • Page 23: Specifications

    BACK P700 Multiscanning Color Monitor 7. Specifications 17"(viewable size : 15.7") Dot pitch 0.26 mm Picture tube Anti-Static, anti-glare, TCO treatment coated. Display area factory preset area : 305X229 mm Number of color Infinite Input signals R.G.B Analog, 15 pin D-sub...
