- Page 1 NEXT A715 A715 User's Guide...
- Page 2 BACK U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION NEXT RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 BACK Standards and Recommendations NEXT Safety and Radio Interference Approvals This product is designed in conformity with the following standards or other normative documents : Safety : EN 60950 : 2000 : EN 55022 : 1998+A1 : 2000 CLASS B EN 55024 : 1998+A1 : 2001, EN 61000-3-2 : 2000 EN 61000-3-3 : 1995+A1:2001 to satisfy the basic requirements of Safety and EMC required by following Directives :...
-
Page 4: Table Of Contents
BACK A715 17" TFT LCD Color Monitor NEXT Contents 1. Introduction ........1/23 2. Safety Information ......1/23 3. Installing the monitor ....4/23 3-1. Packing List .........4/23 3-2. Selecting a suitable location ....5/23 3-3. Connecting the monitor .....5/23 3-4. Setting the refresh rate ......9/23 Preset Timing Table ......9/23... -
Page 5: Introduction
BACK A715 17" TFT LCD Color Monitor NEXT 1. Introduction This manual contains instructions for installing and operating A715. A715 is a highly ergonomic color display unit. • 17" viewable SXGA LCD • High quality screen re-scaling capability • Real Color flesh-tone adjustment and digital color control with innovative color management. - Page 6 BACK A715 17" TFT LCD Color Monitor NEXT Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~35°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.
- Page 7 BACK A715 17" TFT LCD Color Monitor NEXT Cleaning and Maintenance • To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning.
-
Page 8: Installing The Monitor
BACK A715 17" TFT LCD Color Monitor NEXT 3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Power Cord Japan Signal Cable America/Canada Europe DVI-D Cable (Option) Australia South Africa USB Cable Compact Disc... -
Page 9: Selecting A Suitable Location
BACK A715 17" TFT LCD Color Monitor NEXT 3-2. Selecting a suitable location • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. • Place the monitor in a position where no light shines directly onto or is reflected on the screen. - Page 10 BACK A715 17" TFT LCD Color Monitor NEXT Turn on the power to the computer. The picture will appear within about 10 seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information.
- Page 11 BACK A715 17" TFT LCD Color Monitor NEXT • USB hub / PC Audio The USB hub(Bus-powerd mode hub) have 1 upstream port and 2 downstream ports. The upstream port can be connected to the root hub of host PC or other downstream port.
- Page 12 BACK A715 17" TFT LCD Color Monitor NEXT • Audio system This monitor has an audio system including two micro loudspeakers. Each of two micro loudspeakers has an 2Wrms (max.) output power. This system also supports a headphone output jack.
-
Page 13: Setting The Refresh Rate
BACK A715 17" TFT LCD Color Monitor NEXT 3-4. Setting the refresh Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000. rate Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab. - Page 14 BACK A715 17" TFT LCD Color Monitor NEXT ANALOG R.G.B INPUT The recommended setting is a resolution of 1280x1024 and a refresh rate of 60Hz. Resolution Horizontal Frequency Refresh rate 720 x 400 31.5 KHz 70 Hz 640 x 480 31.5 KHz...
-
Page 15: User's Environment
BACK A715 17" TFT LCD Color Monitor NEXT 3-5. User’s Environment With the double-hinge structure in the stand, this display unit is designed to support the following user’s environment. • You can adjust the tilt angle and height at your suitable level and can fold the stand during carriage. - Page 16 BACK A715 17" TFT LCD Color Monitor NEXT VESA MOUNT’G • This display unit supports VESA FPMPMI standard for 100mmx100mm screw mounting by giving 4 screw holes inside the base stand of the unit. • To buy VESA Flat Panel Monitor Mounting Devices, please contact following information.
-
Page 17: Adjusting The Picture
BACK A715 17" TFT LCD Color Monitor NEXT 4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. In case of applying Analog RGB Input 1280x1024 H:63.9 V:60.0 BRIGHTNESS BRIGHTNESS 13/23... - Page 18 BACK A715 17" TFT LCD Color Monitor NEXT In case of applying Digital TMDS Input 1280x1024 H:63.9 V:60.0 BRIGHTNESS BRIGHTNESS 14/23...
-
Page 19: Using The On Screen Display
BACK A715 17" TFT LCD Color Monitor NEXT 4-1. Using the On Screen Push the MENU button to call the OSD to the screen. The resolution and Display frequency are displayed at the top of the menu box for your information. -
Page 20: Osd Adjustments
BACK A715 17" TFT LCD Color Monitor NEXT 4-3. OSD Adjustments The OSD adjustments available to you are listed below. BRIGHTNESS You can play the movie Adjust the brightness of the screen. file to see how to adjust the picture image by... - Page 21 BACK A715 17" TFT LCD Color Monitor NEXT CLOCK PHASE PHASE Adjust the noise of the screen image. CLOCK Adjust the horizontal size of the entire screen image. MISCELLANEOUS RECALL Recall the saved color data. OSD TIMER You can set the displayed time of OSD Menu window on the screen by using this adjustment.
- Page 22 BACK A715 17" TFT LCD Color Monitor NEXT AUDIO VOLUME Adjust the audio volume level. AUDIO This menu is used to choose audio on or off. AUTO ADJUST You can adjust the shape of screen automatically at the full screen pattern.
-
Page 23: Display Power Management
BACK A715 17" TFT LCD Color Monitor NEXT 5. Display power If the power management function of your computer is enabled, your monitor management turns on and off automatically. You can control power management features from your computer. Reducing power... -
Page 24: Troubleshooting
BACK A715 17" TFT LCD Color Monitor NEXT 6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by following the suggestions below : Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on. - Page 25 BACK A715 17" TFT LCD Color Monitor NEXT Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section OSD shape or quality Adjustment(4-3).
- Page 26 BACK A715 17" TFT LCD Color Monitor NEXT Problem Possible solution The power LED is LED Indicator can be orange color on changing of video mode or a orange color Input Signal(D-sub/DVI). Check the Resolution and the frequency on the video part of your computer.
-
Page 27: Specifications
BACK A715 17" TFT LCD Color Monitor 7. Specifications 17"viewable, Diagonal, Pixel pitch 0.264 mm, A-Si TFT Brightness 250cd/m Response Time 25msec Display area 337.92 x 270.336 mm Number of color 16,7 million colors Input signals R.G.B Analog, Digital TMDS(DVI-D), Frequency rate Horizontal : 31.0 to 80.0KHz, Vertical : 56 to 75Hz...
