Dell PowerEdge R420

Getting Started Guide

Regulatory Model: E18S Series
Regulatory Type: E18S001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerEdge R420 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dell PowerEdge R420

  • Page 1: Getting Started Guide

    Dell PowerEdge R420 Getting Started Guide Regulatory Model: E18S Series Regulatory Type: E18S001...
  • Page 2: Notes, Cautions, And Warnings

    Information in this publication is subject to change without notice. © 2012 Dell Inc. All rights reserved. Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell...
  • Page 3: Installation And Configuration

    Installation And Configuration WARNING: Before performing the following procedure, review the safety instructions that came with the system. Unpacking A Rack System Unpack your system and identify each item. Assemble the rails and install the system in the rack following the safety instructions and the rack installation instructions provided with your system.
  • Page 4: Connecting The Power Cables

    Connecting The Power Cable(s) Figure 3. Connecting the Power Cable(s) Connect the system’s power cable(s) to the system and, if a monitor is used, connect the monitor’s power cable to the monitor. Securing The Power Cable(s) Figure 4. Securing the Power Cable(s) Bend the system power cable(s), as shown in the illustration, and attach to the cable strap.
  • Page 5: Turning On The System

    Dell Software License Agreement Before using your system, read the Dell Software License Agreement that came with your system. You must consider any media of Dell-installed software as BACKUP copies of the software installed on your system’s hard drive. If you do...
  • Page 6: Other Information You May Need

    NOTE: Always check for updates on support.dell.com/manuals and read the updates first because they often supersede information in other documents.
  • Page 7 1 °C/300 m above 900 m (1 °F per 550 ft). NOTE: For information on supported expanded operating temperature range and configurations, see support.dell.com/ manuals. Storage –40 °C to 65 °C (–40 °F to 149 °F) with a maximum temperature gradation of 20 °C per hour...
  • Page 8 Environmental Operating 20% to 80% (noncondensing) at a maximum wet bulb temperature of 29 °C (84.2 °F) Storage 5% to 95% at a maximum wet bulb temperature of 38 °C (100.4 °F) Maximum vibration Operating 0.26 G at 5 Hz–350 Hz (all operation orientations) Storage 1.87 G at 10 Hz–500 Hz for 15 min (all six sides tested)
