Part names

TV set

TV front

POWER switch
Turns on and off the main power.
Infrared sensor window
Receives the infrared wave
from the remote control.
Behind the door
MENU/PRESET
MENU/PRESET button
Tunes the channels.
Used for MENU setup.
/
Volume up/down buttons
Adjusts the volume.
Makes adjustments in PRESET.
Channel up/down buttons
Tunes or sets the channels.
• When using headphone, see
E 7
8
POWER
Power indicator
Power can be turned on by
the remote control when the
indicator is dimly.
6
12
8
/
CH 8
CH
Selects the channels.
.
9
8
26
26 Video input terminal (AV-2)
Connects to a camcorder,
video game, etc.
9 Headphone jack
Use to listen to the
audio with headphone.
Audio input terminals
(AV-2)
Connects to a camcorder,
video game, etc.
