Controls and Indicators

1 2 3
8 9

Operation with AC Power

Check the setting of the AC voltage selec-
tor located on the rear panel before plug-
ging the unit into an AC socket. If neces-
sary, adjust the selector to match the AC
power voltage used in your area.
Selector adjustment:
Slide the selector with a screwdriver to the ap-
propriate voltage number. (AC 110 - 127 V or
AC 220 - 240 V)
QT-222W(B)_E.pm
4 5 6 7
10 11 12 13 14
15 16 17 18
To AC INPUT
E-2
9
01. Earphone Socket
02. Built-in Microphone
03. Function Switch
04. Band Selector
05. Fine Tuning Control
06. Volume Control
07. Tuning Control
08. Pause Button
09. Stop/Eject Button
10. Cassette Compartment
11. Fast Forward Button
12. Rewind Button
13. Play Button
14. Record Button
15. Battery Compartment
16. AC Input Socket
17. AC Voltage Selector
18. FM/SW Telescopic Rod Aerial
Notes:
G If the unit will not be used for a long period
of time, remove the AC power lead from the
AC socket.
G Connection of the AC power lead to the unit
disconnects the batteries.
G Use only the supplied AC power lead. Using
other power leads may cause an electric
shock or fire.
03.10.24, 11:55 AM
QT-222W(B) 92L20101550040
Wall socket
