SGC SG-2020 TEST DOCUMENT Test Manual page 9

Spurious transmissions check( @ 20W USB)
9.4 While doing the power response test (above), compare any spurs trans-
mitted with the peak power signal. There should be none higher than -
40 dB.
9.5 Repeat the above steps for all the frequencies listed on the following
table.
FREQ. MHz
VDC
1.80 12 - 18
3.70 12 - 18
7.14 12 - 18
14.15 12 - 18
18.15 12 - 18
29.70 12 - 18
10.0 TRANSMIT QUALITY TEST
This will test for good quality of voice transmitted into a dummy load,
and received in a close-by radio set on the same frequency and mode.
10.1 Use a known good microphone and transmit a few phrases of test signal
to a near-by radio set on the same frequency.
10.2 Listen to the quality of the voice in the other radio while monitoring
modulation on the scope attached at the output of your radio's dummy
load.
11.0 RECEIVER CURRENT TEST
11.1 Connect RF Generator at the antenna connector, and an ammeter in series
with the radio.
11.2 Radio settings - 14150.0 KHz USB, AF max., RF max., BW 2.7 KHz.
11.3 Measure current readings on the ammeter for each of the situations:
Backlite
Standby
Max. Signal
Idle
