SGC SG-2020 TEST DOCUMENT Test Manual page 3

4. SWR Shutdown:
Transmit 20 watts in CW mode with no antenna connected. You should get
less than 5 LED's on for forward power and full scale reading (all LED's on)
for reverse power. as indicated by the bargraph display.
