Summary of Contents for Ricoh Caplio Utility for Macintosh
Page 1
Caplio Utility for Macintosh Operation Manual English To ensure correct use of the product, read this manual carefully before use. Keep the manual handy for future use.
Page 2
• Ricoh Co., Ltd. assumes no liability for data created by the user using this product. • Ricoh Co., Ltd. assumes no liability for damages caused by failure of the product, damages incurred due to loss of text or data, or any other damages arising from use of the product.
What You Can Do Using This Software Download images, Sound file and motion pictures and transfer files to the camera By connecting the camera to a Macintosh, you can download recorded images, Sound file and motion pictures onto the Macintosh, and you can also transfer images, Sound file (WAV files) and motion picture files (AVI file) stored in the Macintosh to the camera.
Contents What You Can Do Using This Software............1 Chapter 1 Preparing the Software ............ 3 Explanation of Software ................3 System Environment ..................5 Installing the Software...................6 Deleting the Software..................10 Chapter 2 Connecting the Camera to a Macintosh....... 11 Connecting the Camera to a Macintosh using the USB Cable ....11 Disconnecting the USB Cable..............12 Chapter 3 Using Caplio Utility ............
Chapter Preparing the Software This chapter explains the preparations required to use the supplied software, such as the necessary system environment, installation of Caplio Utility, etc. The following window is displayed when the CD-ROM is opened. Caplio RR1 Installer Explanation of Software I Caplio RR1 Installer Open the CD-ROM and you will find the [Caplio RR1 Software] Installer.
Page 6
I Other Folders Software Description QuickTime Folder QuickTime 4 This folder contains QuickTime 4.1.2. MGI Folder MGI PhotoSuite This folder contains MGI PhotoSuite. This software is a well-rounded photo editing package that delivers extensive multimedia file playback and online imaging service support.
Note • QuickTime 4.1.2 or later is required to open text mode files (TIFF-MMR) recorded with the Ricoh digital camera. • If you are using files containing a large volume of data such as motion picture or non- compressed files, allocate sufficient application memory for Caplio Utility.
Installing the Software This section explains how to install the necessary software, such as Caplio Utility and USB Driver for connecting the camera to a Macintosh. Exit all other applications before following the procedures below to install the software. I To install the Caplio RR1 Software Turn the Macintosh on.
Page 9
Click on [Caplio RR1 Software]. Select [Easy Install] and click on [Install]. 1 Easy Install Caplio Utility and USB Driver will be installed. 2 Custom Install Only the selected software will be installed. If you select [Custom Install], the Custom Install screen will be displayed. Choose the software that you want to install and select [Install].
Page 10
Select [Restart]. The Macintosh will be restarted. If you do not want to restart the Macintosh straightaway, select [Quit], and if you want to perform further installations, select [Continue]. If you select [Custom Install], the screen for selecting the software will be Tips displayed.
Page 11
Double-click on the [QuickTime Installer] icon in the [QuickTime Installer] folder. Installation of QuickTime will start. Proceed in accordance with the instructions displayed on the screen. When installation is finished, restart the Macintosh.
Deleting the Software To delete unwanted software from the Macintosh, use the drag & drop function to transfer the file to the trash can. The file names and installation folders are as follows. Caplio Utility Caplio RR1 Software File name Installation Folder Caplio Utility Caplio RR1 Software...
Chapter Connecting the Camera to a Macintosh This chapter explains how to connect the camera to a Macintosh using the USB cable in order to send and receive files. Connecting the Camera to a Macintosh using the USB Cable Turn the Macintosh on. Check that the camera is turned off and connect the AC adapter to the camera.
Disconnecting the USB Cable To disconnect the USB cable, press the sides of the USB cable connector to release the lock and pull the connector out. Turn the camera off. Press the sides of the USB cable connector to release the lock and detach the connector.
Chapter Using Caplio Utility This chapter explains how to use Caplio Utility. Caplio Utility enables you to save files recorded with the camera in the Macintosh, and transfer images from the Macintosh to the camera. Starting Caplio Utility Open the folder in which Caplio Utility is installed. Double-click on the Caplio Utility icon.
Saving Camera Files in the Macintosh (Camera ➝ Macintosh) You can save image, sound and motion picture files recorded with the camera to a specified folder in the Macintosh. Check that the camera is properly connected to the Macintosh before proceeding. Note •...
Page 18
Select files While viewing the monitor on the camera, use the forward button or backward button arrow to display the file to be downloaded, and then click on the [Select] button to select. To select all the files in the selected memory, click on [Select All]. If you click on [Save], the [Select Folder] dialog will be displayed.
Transferring Files From the Macintosh to the Camera (Macintosh ➝ Camera) You can transfer files recorded with the camera from the Macintosh to the camera. Check that the camera is properly connected to the Macintosh before proceeding. Check that the camera is properly connected to the Macintosh.
