Threshold Naming Conventions

All threshold names consist of the following three items, with no separators:
• Abbreviation for the class name (alpha characters, lower case), as follows:
• Abbreviation for the area name (alpha characters, title case). For example, "Temp" for the
Temperature area.
• Index number for the number of the item within the series. Consists of three numbers, for
example: 000 for the first port, 001 for the next, etc. Index numbers for the Fabric, Port, E_Port,
F/FL_Port (Optical), and GBIC classes begin with 000, and index numbers for the Environment
class begin with 001.
Example of a Threshold Name:
The threshold corresponding to the first thermometer in the switch is in the Environment class,
Temperature area, and is therefore named envTemp001.

Events

An event is generated each time a boundary, as defined by the threshold, is crossed. Boundaries are
not inclusive, so events are generated only when a boundary is exceeded, not when the monitored
value has only reached them. If the event has an assigned alarm, an alarm is also generated. The
alarm can be designated as an SNMP trap, an entry in the switch error log, locking of the port log,
or a combination of these options.
When an item such as an E_Port, F/FL_Port (optical), Smart SFP, fan, or power supply is removed,
Fabric Watch may raise an event (such as a below event), then the threshold is hidden and disabled.
When an item is added, the threshold is displayed and enabled, and Fabric Watch may raise an
event.
Event policies control the generation of events, and can be configured for either triggered events or
continuous events.

Triggered Events

A triggered event results in a single event when a boundary is exceeded. The event is not generated
again until the threshold value has returned within the boundaries and then once again exceeded
them. For example, if the switch temperature exceeds the upper boundary, a triggered event is
generated at the point the boundary is crossed, but is not repeated while the temperature remains
above the upper boundary.
Fabric Watch User's Guide
Class Abbreviation
Fabric fabric
Environment env
Port port
E_Port eport
F/FL_Port (Optical) fopport
GBIC gbic
ALPA alpa
End-to-End ee
Filter flt
2
Using Fabric Watch
2-7
