- for use without a computer -
Important Safety Instructions .............................................................. 3
Copyright Notice.................................................................................. 4
Parts ....................................................................................................... 5
Control Panel Functions ...................................................................... 6
Selecting Paper.................................................................................... 8
Loading Paper...................................................................................... 8
Placing Originals on the Document Table ...................................... 10
Copying Documents ......................................................................... 11
Copying Photos.................................................................................. 11
Speeding Up Copying ....................................................................... 11
Handling a Memory Card ................................................................. 12
Printing All Photos or DPOF Photos ................................................... 15
Digital Camera Requirements .......................................................... 16
Connecting and Printing................................................................... 16
Replacing Ink Cartridges................................................................... 17
Checking and Cleaning the Print Head ......................................... 20
Aligning the Print Head...................................................................... 20
Cleaning This Product ........................................................................ 21
Transporting This Product................................................................... 21
Error Indicators .................................................................................... 22
Problems and Solutions ..................................................................... 24
Contacting Customer Support ......................................................... 26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stylus DX5000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Epson Stylus DX5000 Series

Summary of Contents for Epson Stylus DX5000 Series

  • Page 1: Table Of Contents

    User’s Guide – for use without a computer – Introduction Guide to Parts and Control Panel Functions Handling Paper Copying Printing from a Memory Card Printing from a Digital Camera Maintenance Solving Problems Important Safety Instructions ... 3 Copyright Notice... 4 Parts ...

  • Page 2: Where To Find Information

    Where to Find Information Paper manuals (this book) Online manuals Start Here Be sure to read this sheet first. This sheet tells you how to set up the product and install the software. It also includes instructions on loading paper and placing originals. User's Guide -for use without a computer- This book contains information on how to use the product without connecting your computer, such as instructions on copying and printing...

  • Page 3: Introduction

    Introduction Important Safety Instructions Before using this product, read and follow these safety instructions: ■ Use only the power cord that comes with the product. Use of another cord may cause fire or shock. Do not use the cord with any other equipment.

  • Page 4: Warnings, Cautions, And Notes

    Seiko Epson Corporation. The information contained herein is designed only for use with this product. Epson is not responsible for any use of this information as applied to other printers.

  • Page 5: Guide To Parts And Control Panel Functions

    Guide to Parts and Control Panel Functions Parts control panel external interface USB port memory card slot cover memory card slots AC inlet document cover edge guide document table USB port Guide to Parts and Control Panel Functions sheet feeder paper support extension paper support feeder guard...

  • Page 6: Control Panel Functions

    Control Panel Functions Buttons Guide to Parts and Control Panel Functions Button Function P On Press to turn the product on and off. Press to replace ink cartridges. Press and hold for three seconds to clean the print head (when the B light is off).
  • Page 7 Lights O = on k = flashing Light Error m [Print Index Sheet -A4-] i [Print From Index f/e/DPOF [Print All/DPOF/PictBridge] k [Copies] (window) g [Photo Paper] l [Plain Paper] 10 × 15 4" × 6" 13 × 18 5" × 7" o [Fit to Page] Pattern k (slow)

  • Page 8: Handling Paper

    If you are just making a copy or printing a rough draft of an image, plain paper is fine. However, for the best results, you will want to use one of Epson’s special ink jet papers designed for the product.
  • Page 9 Set the paper as shown in the following illustrations. 5. Flip the feeder guard back. The printable side is often whiter or brighter than the other side. place behind the tabs Also make sure the paper thickness lever is set down to the m position.

  • Page 10: Copying

    Copying You can copy documents and photos without a computer. Note the following when copying: ■ The copied image may not be exactly the same size as the original. ■ Depending on the type of paper used, print quality may decline in the top and bottom areas of the printout, or these areas may be smeared.

  • Page 11: Copying Documents

    Copying Documents Tip: Plain photocopier paper works well for making everyday copies. For crisper text and more vivid colors, try one of the special Epson papers (& “Selecting Paper” on page 8). 1. Load plain paper (& page 8). 2. Place your original on the document table (&...

  • Page 12: Printing From A Memory Card

    Printing from a Memory Card You can print photos directly from your digital camera's memory card. Just insert it into the memory card slot and you are ready to print. Handling a Memory Card Compatible cards Make sure your memory card meets the following requirements.

  • Page 13: Removing The Memory Card

    SD Memory Card SDHC Memory Card MultiMediaCard microSD card* microSDHC card* miniSD card* miniSDHC card* (* Adapter required) Memory Stick Memory Stick PRO MagicGate Memory Stick Memory Stick Duo* Memory Stick PRO Duo* MagicGate Memory Stick Duo* (* Adapter required) Caution: Make sure you check which direction the card should be inserted, and if the card needs an adapter make sure you...

  • Page 14: Selecting And Printing Photos Using An Index Sheet

    Selecting and Printing Photos Using an Index Sheet To select photos for printing, you can use an index sheet. First, print an index sheet which has small images of all the photos on your memory card. Then, mark the photos on the index sheet that you want to print, scan the sheet, and the selected photos will be printed automatically.

  • Page 15: Printing All Photos Or Dpof Photos

    3. Scanning the index sheet and printing the selected photos 1. Place the index sheet face-down on the document table, in the upper left corner, so that the top of the sheet is aligned against the left edge of the document table. 2.

  • Page 16: Printing From A Digital Camera

    [Copies] window, and the Error light and the f/e/DPOF [Print All/DPOF/PictBridge] light flash. Epson cannot guarantee the compatibility of any camera. ❏ Depending on the settings on this product and the digital camera, some combinations of paper type, size, and layout may not be supported.

  • Page 17: Maintenance

    T0714 T0734 Caution: Epson recommends the use of genuine Epson ink cartridges. The use of non-genuine ink may cause damage that is not covered by Epson’s warranties, and under certain circumstances, may cause erratic printer behavior. Epson cannot guarantee the quality or reliability of non-genuine ink.
  • Page 18 Dispose of it carefully. Caution: Do not refill the ink cartridge. Other products not manufactured by Epson may cause damage that is not covered by Epson's warranties, and under certain circumstances, may cause erratic printer behavior.
  • Page 19 ❏ If you have installed an ink cartridge without removing the yellow tape, take the cartridge out of the printer, remove the yellow tape, and then reinstall it. ❏ Do not remove the transparent seal from the bottom of the cartridge;...

  • Page 20: Checking And Cleaning The Print Head

    Checking and Cleaning the Print Head If your printouts are unexpectedly light, colors are missing, or you see light or dark lines across the page, you may need to clean the print head. This clears the print head nozzles, which can become clogged if you do not use the product for a long time.

  • Page 21: Cleaning This Product

    Cleaning This Product To keep the operation of the product at its best, clean it periodically using the following procedure. Unplug the power cord. 2. Remove all paper from the sheet feeder. 3. Use a soft brush to carefully clean away all dust and dirt from the sheet feeder.

  • Page 22: Solving Problems

    Solving Problems If you have a problem with the product, check the lights on the control panel and the code number or letter in the k [Copies] window to diagnose what may be causing the problem. You can also check “Problems and Solutions” on page 24 for troubleshooting suggestions on using the product without a computer.
  • Page 23 Code P double flashing Error The paper thickness lever is set to the ^ position. [Copies] Error Waste ink pad in the printer is saturated. k All other lights [Copies] k All lights There is a problem with the product. [Copies] Solution Remove the memory card and insert the card used to print the index sheet—or...

  • Page 24: Problems And Solutions

    Problems and Solutions Check the solutions below if you are having problems using the product. Setup problems The product makes noise after you turn it on. ■ Make sure the protective tape is not blocking the print head. After releasing the print head, turn off the power, wait a moment, then turn it back The product makes noise after ink cartridge installation.

  • Page 25: Print Quality Problems

    ■ Make several copies without placing a document on the document table. ■ Use only paper recommended by Epson and genuine Epson cartridges. ■ Set the paper thickness lever to the m position for most paper types. If you are printing on envelopes, set the lever to the ^ position.

  • Page 26: Other Problems

    Contacting Customer Support Regional customer services If your Epson product is not operating properly and you cannot solve the problem using the troubleshooting information in your product documentation, contact customer support services for assistance. If customer support for your area is not listed below, contact the dealer where you purchased your product.
  • Page 27 Solving Problems...

  • Page 28: Purchasing Ink Cartridges

    Purchasing ink cartridges Product name DX5000 series CX4900 series Black Cyan T0711 T0712 T0731 T0732 Yellow Magenta T0714 T0713 T0734 T0733...
