  • Page 1 7-Port USB 2.0 & FireWire 400 Combo PCI Host Card User Manual Model: UGT-UF100 All brand names and trademarks are properties of their respective owners. w w w . v a n t e c u s a . c o m...
  • Page 2: Features And Benefits

    Features and Benefits Combo design adds four USB 2.0 (480Mbps) and three FireWire (400Mbps) ports into your system Hot-swapping feature allows you to connect/disconnect devices without first turning system off USB 2.0 interface: Compliant with USB specification rev. 2.0 Supports high-speed (480Mbps), full-speed (12Mbps), and low-speed(1.5Mbps) data transfer modes for simultaneous operation of multiple USB 2.0/1.1 devices Works with a various type of USB devices including hubs,...
  • Page 3: Package Contents

    Package Contents 1 x 7-Port USB 2.0 FireWire 400 Combo PCI Host Card 1x 1394a DV cable (6-pin to 4-pin) 1 x User’s Manual System Requirements Windows® 2000/XP/Server 2003/Vista Available PCI slot Hardware Description   Page 3  UGT-UF100 ...
  • Page 4: Hardware Installation

    Hardware Installation Turn Off the power to your computer. Unplug the power cord and remove your computer’s cover. Remove the slot bracket from an available PCI slot To install the card, carefully align the card’s bus connector with the selected PCI slot on the motherboard. Push the board down firmly.
  • Page 5: Driver Installation

    Replace the computer cover and reconnect the power cord. Driver Installation For Windows® XP/2000 Windows® 2000/XP will automatically detect and install the correct driver for the PCI USB 2.0 & IEEE 1394a Combo. However, please ensure you have the latest Service Pack Installed.
  • Page 6 To Verify Windows Installation Right click My Computer, then click Manage. Click Device Manager. Double click IEEE 1394 Bus host controllers option and a VIA OHCI Compliant IEEE 1394 Host Controller should be displayed Double click Universal Serial Bus controllers option. - USB Root Hub (USB 2.0 Root Hub in Windows®...
  • Page 7   Page 7  UGT-UF100 ...
