Vantec UGT-UC302CB User Manual

2-port superspeed usb 3.0 expresscard/34

Advertisement

Quick Links

2-Port SuperSpeed USB 3.0
ExpressCard/34
User's Manual
Model: UGT-UC302CB
Rev. 1.0
All brand names and trademarks are properties of their respective owners.
w w w . v a n t e c u s a . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UGT-UC302CB and is the answer not in the manual?

Questions and answers

Summary of Contents for Vantec UGT-UC302CB

  • Page 1 2-Port SuperSpeed USB 3.0 ExpressCard/34 User’s Manual Model: UGT-UC302CB Rev. 1.0 All brand names and trademarks are properties of their respective owners. w w w . v a n t e c u s a . c o m...
  • Page 2: Features And Benefits

    USB 2.0 and USB 1.1 devices making this card truly versatile. Upgrading your laptop to the newest USB 3.0 technology has never been so easy with the Vantec 2-Port SuperSpeed USB 3.0 ExpressCard/34. Features and Benefits Blazing Fast Tranfer Speeds of up to 5Gbps 10x Faster than USB 2.0...
  • Page 3: System Requirements

    Specifications Model: UGT-UC302CB Ports: 2 x External USB 3.0 Ports (Backwards Compatible with USB 2.0 & 1.1) Dimensions: 116 x 40 x 15mm (w/o ExpressCard/54 Adapter) 116 x 54 x 18mm (w/ ExpressCard/54 Adapter) OS Support: Microsoft Windows® XP/Vista/7 (32/64 bit) System Requirements Windows®...
  • Page 4: Hardware Installation

    Layout Before installing the Vantec 2-Port SuperSpeed USB 3.0 ExpressCard/34, please see the photo below highlighting the available USB 3.0 ports of the card. P1 & P2: USB 3.0 Ports P3: ExpressCard Connector P4: 34mm to 54mm Adapter P5: Standard 5V Power Port (optional) Hardware Installation Before installing the 2-Port SuperSpeed USB 3.0...
  • Page 5 Hardware Installation If you have an ExpressCard/34 slot, please proceed and skip to Step 5. If you have an ExpressCard54 Slot please be sure to install the adapter that is provided. Take the adapter and slide the metal latch out and attach the adapter to the 2-Port SuperSpeed USB 3.0 ExpressCard/34.
  • Page 6: Driver Installation

    Hardware Installation You have successfully installed the 2-Port SuperSpeed USB 3.0 ExpressCard/34. Driver Installation Please follow the following steps for driver installation. When you are booting up the laptop with the new hardware installed, Windows will automatically detect and display the 'Found New Hardware Wizard'. Cancel the automatic driver installation and run the Setup.exe located on the Driver CD.
  • Page 7 If any parts are missing or if there are cosmetic defects, please contact the retailer from which you purchased the unit immediately and ask for a replacement. Vantec Thermal Technologies 43951 Boscell Rd., Fremont, CA 94538 tel: 510-668-0368 fax: 510-668-0367 website: www.vantecusa.com...
