Grindmaster 810 Operation And Instruction Manual

Grindmaster 810 Operation And Instruction Manual

800 series coffee grinders
Hide thumbs Also See for 810:

Advertisement

Operation and Instruction Manual
Models 810, 835, 865, 875 and 890

Table of Contents

Installation ....................................................3
Operating Instructions ..................................3
Grind Adjustment ..........................................4
Shear Disc Replacement ..........................4-5
Cleaning Instructions ....................................5
Lubrication ....................................................5
Troubleshooting Guide ................................6
Exploded View ..........................................7-9
Wiring Diagrams ........................................10
Prior authorization must be obtained
from Grindmaster Corporation for
all warranty claims.
PRINTED IN USA
Grindmaster Corporation
800 Series Coffee Grinders
for
Model 890
Grindmaster Corporation
4003 Collins Lane
Louisville, Kentucky 40245 USA
(800) 695-4500 (USA & Canada only)
(502) 425-4776
FAX: (502) 425-4664
www.grindmaster.com
0509 Form # GR-380-16
Part# 83427

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 810 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grindmaster 810

  • Page 1: Table Of Contents

    Cleaning Instructions ........5 Lubrication ............5 Troubleshooting Guide ........6 Exploded View ..........7-9 Wiring Diagrams ........10 Prior authorization must be obtained from Grindmaster Corporation for Model 890 all warranty claims. Grindmaster Corporation 4003 Collins Lane Louisville, Kentucky 40245 USA (800) 695-4500 (USA & Canada only)
  • Page 3: Installation

    Grind a small amount of whole bean coffee following operating instructions as described in this manual. If there is any problem, consult the Troubleshooting Guide in this manual, (also on back of grinder.) If you still cannot correct a problem, call Grindmaster’s Service Department for help, (800) 568-5715 M-F 8 AM - 6 PM EST Operating Instructions Your new coffee grinder is easy to operate and maintain.
  • Page 4: Grind Adjustment

    Protection The grinder is equipped with both a circuit breaker and a shear disc release to protect the motor and burrs if a foreign object, such as a nail or rock, gets into the coffee. Grind Adjustment Tools required: Large blade and medium Phillips head screwdrivers In order to adjust the grind, follow these steps (Refer to figure A): Remove all coffee from the hopper.
  • Page 5: Cleaning Instructions

    FEEDWORM & ROTARY BURR GRIND CAP (ASSEMBLED) SHEAR DRIVE GRIND HEAD DWG NO.: 83457 REVISION: REL SHEAR DISC SHEAR COVER SCREW, 5/16 X 1” LG Model 865/890 GRIND HEAD GRIND HEAD GRIND HEAD FEEDWORM & ROTARY BURR FEEDWORM & ROTARY BURR FEEDWORM &...
  • Page 6: Troubleshooting Guide

    (Monday through Friday 8am-6pm EST) or an authorized service center in your area. Please have the model and serial number ready so that accurate information can be given. Prior authorization must be obtained from Grindmaster Corporation’s Technical Services Department for all warranty claims.
  • Page 7: Exploded View

    800 Series Exploded View 800 Series Coffee Grinders Page 7...
  • Page 8 800 Series Parts List - 120V ITEM # DESCRIPTION 120V GROCERY GRINDER PART NUMBERS FOR THESE MODELS: 810A 810 TALL Washer, #8 internal tooth 86822 Top,800 series sanitation * 83451RK and 83451BK - all models Lid, 800 series sanitation * 83450RK and 83450BK - all models Screw, #8 x 1/4 ph truss hd 86875...
  • Page 9 800 Series Parts List - 230V ITEM # DESCRIPTION 230V GROCERY GRINDER PART NUMBERS FOR THESE MODELS: 810 TALL Washer, #8 internal tooth 86822 Top,800 series sanitation * 83451RK and 83451BK - all models Lid, 800 series sanitation * 83450RK and 83450BK - all models Screw, #8 x 1/4 ph truss hd 86875 86875...
  • Page 10: Wiring Diagrams

    Wiring Diagrams for 120 Volt 60Hz Units Page 10 800 Series Coffee Grinders...
  • Page 12: Grindmaster Corporation

    Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only) P.O.

This manual is also suitable for:

835865875890

Table of Contents
