4
Power (DC) Input
The supplied power adapter converts AC power to DC
power for use with this jack. Power supplied through this
jack supplies power to the Eee PC and charges the internal
battery pack. To prevent damage to the Eee PC and battery
pack, always use the supplied power adapter.
CAUTION: MAY BECOME WARM TO HOT WHEN IN USE. BE SURE
NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR
BODY.
5
Kensington® Lock Port
The Kensington® lock port allows the Eee PC to be secured
using Kensington® compatible security products. These
security products usually include a metal cable and lock
that prevent the Eee PC to be removed from a fixed object.
6
Air Vents
The air vents allow cool air to enter and warm air to exit the
Eee PC.
Ensure that pa per, books, clothing, cables, or other objects do not
block any of the air vents or else overheating may occur.
Battery Charge Indicator
7
The battery charge indicator (LED) shows the status of the
battery's power. Refer to the LED status table on pages 1-3
to 1-4.
8
Power Indicator
The power indicator lights when the Eee PC is turned ON
and blinks slowly when the Eee PC is in the Save-to-RAM
(Suspend) mode. This indicator is OFF when the Eee PC is
turned OFF.
ASUS Eee PC
1-9
