Right Side
Refer to the illustration below to identify the components on this
side of the Eee PC.
1
USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices,
cameras, and storage devices, connected in a series up to
12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). Also, the
USB supports hot-swapping function.
2
Microphone Jack
The microphone jack is designed to connect the
microphone used for Skype, voice narrations, or simple
audio recordings.
3
Headphone Output Jack
The 1/8" stereo headphone jack (3.5mm) connects the Eee
PC's audio out signal to amplified speakers or headphones.
Using this jack automatically disables the built-in speakers.
ASUS Eee PC
1
2
3
1-7
