Summary of Contents for Geemarc Ampli500
-
Page 2: Table Of Contents
CONTENTS CONTENTS VOLUME AND TONE Sending Level Adjustment Receiving Level Adjustment INTRODUCTION Handset Amplifier Unpacking the Ampli500™ DESCRIPTION PHONEBOOK Create a Phonebook Entry INSTALLATION Create and Entry from the Setting Up Caller Display Log Make a Call from a Phonebook Entry 23 SETTINGS Delete a Phonebook entry Ringer Volume... -
Page 3: Introduction
It also has the added benefits of outgoing voice amplification and receiving amplification. It is important that you read the instructions below in order to use your Geemarc Ampli500™ to its full potential. Keep this user guide in a safe place for future reference. With any questions please contact customer service at 1-888-864-2446 or RMA@sonicalert.info. -
Page 4: Description
Volume reception adjustment Direct memory Memory storing key SPEAKER PHONE Hands free microphone Last number redial Headset button (Compatible with Geemarc CLA3 headset accessory) Time break recall button Message waiting / new call Flashing incoming call Mute indicator (strobe light) - Page 5 DESCRIPTION Additional amplifier button Clip to return to wall mount Speaker Handset cord Speaker volume adjustment Tone & volume adjustment automatically activated each time you hang-up the phone Ringer / shaker / strobe select mode Sending volume adjustment Ringer level adjustment...
- Page 6 DESCRIPTION Screen example (On hook position) Minutes Power network icon Hours Month Cancel key Validation key Up/down keys OK button is used to confirm action or a choice on the screen. ▲ ▼ “UP / DOWN arrow” buttons are used to highlight or scroll through the menu.
- Page 7 DESCRIPTION Your Ampi500™ Phone has a screen with different icons, which help you to use the telephone The telephone is supplied by battery + battery indicator The telephone is powered by AC adapter. Memory storing is required. Screen contrast level. “Mute”...
- Page 8 Headset socket* Line cord socket* (Only Geemarc reference) (*) Classified TNV-3 according to EN60950 standard. (**) Classified „hazardous voltage“ according to EN60950 standard. Important: Only Shaker, Neckloop, Headset and Adaptor with Geemarc reference can be connected to the sockets.
-
Page 9: Installation
INSTALLATION Setting Up Connect the curly cord and the handset. Remove the screw of the battery compartment, using the screwdriver provided, and open the battery compartment. Insert 4 good quality alkaline batteries (AAA size, 1.5V type, not supplied) into the battery compart- ment located on the base of the telephone. -
Page 10: Settings
SETTINGS Ringer Volume The ringer volume can be adjusted as high as 95 +dB. A switch located on right side allows the ringer to be switched to OFF, LOW, HIGH. Your telephone comes with the ringer switched to ‘High’. Ringer Tones Press MUTE Use ▲... -
Page 11: Dialing Mode
SETTINGS Dialing Mode The Tone/Pulse switch is found on the base of the phone near the battery compartment. Set the switch to (T) if you have Touch Tone service. The Tone/Pulse switch is pre-set to Tone position (T). If your phone does not dial out, it is possibly being used from an older private switchboard. In this case, the Tone/Pulse switch must be moved to Pulse (P) Date &... -
Page 12: Language Setting
SETTINGS Hour Format You can choose between 12 hours or 24 hours. Press MUTE Use ▲ or ▼ to select ‘SET TIME’ Press OK Use ▲ or ▼ to select the desired digit Press OK to confirm and pass to next digit Press C twice to exit Language Setting You can choose between 16 different languages including English and French. -
Page 13: Screen Contrast Adjustment
SETTINGS Screen Contrast Adjustment Your screen has a backlight that automatically switches off after 15 seconds of inactivity. To decrease or increase the contrast of the backlight: Press MUTE Use ▲ or ▼ to select ‘SET PHONE’ Press OK Use ▲ or ▼ to select ‘LCD CONTRAST’ Press OK Use ▲... -
Page 14: Auto Screen Sizing
SETTINGS Auto Screen Sizing –DIM:X-->x The phone can show a maximum of 8 digits at full size. You can choose to see the complete number (up to a maximum of 18 digits) by selecting ‘Auto Screen Sizing’. When activated, the phone will display at full size but automatically switch to display small numbers when there is a number with more than 8 digits. - Page 15 SETTINGS Area and Long Distance Code Setting When you use your phone for the first time or if you have moved to a different area code, you need to enter your area code into the phone. This assures that when dialing a call out of memory or your phonebook, the number is formatted properly.
-
Page 16: Using The Telephone
USING THE TELEPHONE Answering A Call During an incoming call, your phone will ring and then the number and/or the name of the caller will be displayed on the screen, if you have subscribed to a Caller I.D. service via your telephone provider. -
Page 17: Switching Between Speakerphone And Handset
To stop using speakerphone during a call, simply lift the handset. To activate speakerphone during a call, press SPKR and replace the headset on the cradle at the same time Hands free calls can also be made using an optional Geemarc headset –see Optional Accessories chapter Call Time Counter The call time counter will be displayed a few seconds after the phone number is connected and starts ringing. -
Page 18: Deleting Recent Numbers
USING THE TELEPHONE Deleting Recent Numbers Press OK Screen will display ‘DIALLED’, the last number dialled, total number of numbers dialled plus time and date of displayed number Use ▲ or ▼ to to select the number you wish to delete Press C, the screen will display ‘DEL?’... - Page 19 USING THE TELEPHONE To store a number Lift the handset Press PROG Dial the number you wish to store, checking on the display that you have keyed it in correctly.(30 digits per telephone number allowed) Press the one touch key button (Priority or Memory dial) where you wish to store it.
-
Page 20: Optional Accessories
OPTIONAL ACCESSORIES Headset You can also use your Ampli500™ in hands free mode with an optional Geemarc headset, this is ideal for use with a computer screen. To use the headset Connect the Geemarc headset into the headset socket located at the back of your telephone. -
Page 21: Volume And Tone
VOLUME AND TONE Sending Level Adjustment If your voice is quiet or the person you have called has difficulty hearing, you can increase the sending level volume with the switch located on the right side. You can also decrease the sending volume if required. -
Page 22: Phonebook
PHONEBOOK Create a Phonebook Entry You can store 99 entries into the phone book with the name and phone numbers of your correspon- dent. Press MUTE Use ▲ or ▼ to select ‘PHONEBOOK’ Press OK Use ▲ or ▼ to select ‘ADD’ Press OK Enter the number (30 digits max per memory) When the number is correct, press OK to confirm and enter the... -
Page 23: Create And Entry From The Caller Display Log
PHONEBOOK Use the C key to delete a wrong number or letter. Note : If you wish to insert a pause in the stored number, press the REDIAL key whilst entering (a P will be displayed on the screen). Create an Entry from the Caller I.D. Display Log You can store 99 entries into the phone book with the name and phone numbers of your correspon- dent. -
Page 24: Delete A Phonebook Entry
PHONEBOOK Delete a Phonebook Entry Press MUTE Use ▲ or ▼ to select ‘PHONEBOOK’ Press OK Use ▲ or ▼ to select ‘REVIEW’ Press OK Use ▲ or ▼ to select number you wish to delete Press C, the screen will display ‘DEL?’ Press C to confirm Press OK to exit Modify a Phonebook Entry... -
Page 25: Caller Display
CALLER I.D. DISPLAY LOG The features described in this section are only available if you subscribe to a Caller Display service from your network provider. Caller Display means you can see who is calling on your LCD display (provided the number is not withheld, unavailable or is an international call). -
Page 26: Delete A Number From The Caller Display Log
CALLER I.D. DISPLAY Delete a Number from the Caller I.D. Display Log to access the log and scroll until you Þnd the required number for deleting Press C, the screen will display ‘DEL?’ Press C to conÞrm Press OK to exit Delete all Numbers from the Caller I.D. - Page 27 CALLER I.D. DISPLAY Call Waiting in Practice When you are in conversation with caller no.1, their name and number will be displayed on the screen. A beep tone will be heard when a second call is incoming and their name and number will be displayed on the screen.
-
Page 28: New Call/Message Led
NEW CALL/MESSAGE LED The red LED on the front of the phone will flash to indicate missed calls. To cancel the flashing light, review your new calls. Simply use ▲ or ▼ to access the log and scroll through all the new calls. Alternatively, you can delete the log of unreviewed calls Use ▲... -
Page 29: Troubleshooting
TROUBLESHOOTING No display Make sure that the power adaptor is plugged in correctly and is not damaged Make sure the batteries are inserted correctly Make sure that the batteries are fully charged Telephone does not ring Make sure that the telephone line cord is plugged in correctly and is not damaged Connect another telephone to the telephone PTT socket or move your telephone to another socket to track if the failure is coming from your telephone or your PTT socket There may be too many communication devices connected to a single telephone line e.g. -
Page 30: Safety Information
SAFETY INFORMATION General Only use the correct Geemarc authorized power supply with the product. Do not open the unit (except to replace the batteries). Contact the helpline for all repairs. Never dispose of batteries in a fire. There is a serious risk of explosion and/ or the release of toxic chemicals. -
Page 31: Regulatory Compliance
Email at RMA@sonicalert.info. Allow up to 1 business day to receive a response via Email. (To setup the auto dial feature for Sonic Alert / Geemarc customer service the Green CS key must be programmed with the following phone number 1-888-864-2446. Follow the directions for the emergency key programming on page 18 to program the CS customer Service Key.) -
Page 32: Guarantee
GUARANTEE Sonic Alert warrants the phone against any defect in materials or workmanship for the period of one year from the date of purchase. Should you experience a problem, contact our customer service department Be sure to save your sales receipt as proof of purchase date should you need warranty service. Within a period of one year from purchase date, Sonic Alert will repair or replace (our discretion) your phone at no cost, if a defect in materials or workmanship is found.
