Monogram.
ZGG36N30YSS–36" Outdoor Cooking Center
Dimensions and Specifications (in inches)
3" Min.
Lid Clearance
22-5/8"
25-3/8"
Note: Reference pub. no. 49-8843, Monogram Outdoor Cooking
Center Installation Instructions, for complete details. Reference
pub.no. 49-8841, Monogram Outdoor Cooking Center Cart
Installation Instructions, for complete details.
Created 7/97
35-7/8"
2"
36" Natural Gas Model:
3 Grill Burners
• Monogram Outdoor Cooking Centers are designed to be installed on a
grill cart or into an enclosure.
12-1/2"
• These cooking centers are designed for outdoor use only. Do not
locate the grill in a building, garage or other enclosed area.
• Ensure that fresh air ventilation is adequate.
• Consider exposure to wind and proximity to traffic paths.
• The minimum clearances to combustibles must be maintained at
9-1/2"
all times.
• Do not install a grill below overhead unprotected combustible
construction.
• The installation must conform to local codes or in the absence of local
codes, with the national fuel gas code, ANSI Z223 latest edition.
For answers to your GE Monogram,
GE, Hotpoint and RCA appliance questions, call
GE Answer Center
®
U L
Listed by
Underwriters
R
Laboratories
GE Profile,
service, 800.626.2000.
