Summary of Contents for Gardena C 1030 plus
- Page 1 GARDENA ® C 1030 plus Art. 1862 Operating Instructions Water Computer Mode d’emploi Programmateur d’arrosage Instructies voor gebruik Besproeiingscomputer Bruksanvisning Bevattningscomputer Brugsanvisning Vandingscomputer Инструкция по эксплуатации...
-
Page 2: Table Of Contents
..........1. Where to Use Your GARDENA Water Computer Intended use : The GARDENA Water Computer is intended for private use in domestic and hobby gardens, exclusively for outdoor use, to control sprinklers and watering systems. -
Page 3: Function
The Water Computer may only be set up The minimum operating pressure is 0.5 bar, vertically with the sleeve nut to the top to the maximum operating pressure is 12 bar. prevent water penetrating into the battery Avoid tensile strain. compartment. - Page 4 You can change the display level at any time, even during pro- gramming. All the programme data which have been confirmed up to that point with the OK key are stored. Display Display Description Weekdays Current weekday or programmed (Mo), (Tu), ... watering days.
-
Page 5: Putting Your Water Computer Into Operation
(with extension cable if necessary) outside the watered area. 3. Insert the sensor in the sensor connection of the Water Computer. An adapter cable may be required to connect older sensors, which can be purchased from GARDENA Service, GARDENA Adapter cable Art. No. 1189-00.600.45. -
Page 6: Programming
The water computer has 2 watering modes : • Scheduled watering using the input programmes (watering starts depending on the watering start time) – or – • Soil moisture sensor-controlled watering using a GARDENA soil moisture sensor (watering begins when the soil moisture sensor registers dry). - Page 7 Entering watering Scheduled watering : programme : [Level 3] 1. Press Menu-key twice (not necessary if the current time and day of the week has been entered). Start Prog and the hours section flash on the display. 2. Set the watering start time hours with the rotary button (E.g. and confirm with the OK-key.
- Page 8 Even if Prog is selected watering can be done manually. Soil moisture sensor-controlled watering Condition : the GARDENA Soil Moisture Sensor Art. 1188 is connected. A previously set scheduled watering programme is retained but not carried out.
- Page 9 The watering duration is preset to 30 minutes at the factory. Emergency programme : If no sensor is inserted in sensor-con- trolled watering mode or if the connection cable is faulty, watering will take place every 24 hours. The watering duration depends on the run time but is limited to a maximum of 30 minutes.
-
Page 10: Putting Your Water Computer Out Of Operation
Important : Make sure that the unit is disposed of via your municipal recycling collection centre. Disposing of flat batteries : v Please return flat batteries to a GARDENA dealer or dispose of them properly at your nearest recycling centre. Only dispose of batteries when they are flat. -
Page 11: Troubleshooting
Check connection cable symbols flash connected. and sensor. In the event of other faults please contact GARDENA Service. Repairs should only be carried out by GARDENA service centres or dealers authorised by GARDENA. 9. Available accessories GARDENA Art. No. 1188... -
Page 12: Technical Data
If you have any problems with your Water Computer, please contact our Customer Service or return the defective unit together with a short description of the problem directly to one of the GARDENA Service Centres listed on the back of this leaflet. - Page 13 We expressly point out that, in accordance with the product liability law, we are not liable for any damage caused by our units if it is due to improper repair or if parts exchanged are not original GARDENA parts or parts approved by us, and, if the repairs were not carried out by a GARDENA Service Centre or an authorised specialist.
- Page 14 Toute modification portée sur ce produit sans l’accord express de EU Retningslinier : Husqvarna supprime la validité de ce certificat. Hinterlegte Dokumentation: GARDENA Technische Dokumentation EU-overeenstemmingsverklaring E. Renn 89079 Ulm Ondergetekende Husqvarna AB, 561 82 Huskvarna, Sweden, bevestigt, dat het...
- Page 15 Consumer Products Phone: (+ 39) 0341.203.111 Belgium Consumer Outdoor Products Industriestrasse 10 info @ gardenaitalia.it Poland GARDENA Belgium NV / SA Salgsafdelning Danmark 5506 Mägenwil Husqvarna Sterrebeekstraat 163 Box 9003 Japan Phone: (+ 41) (0) 848 800 464 Poland Spółka z o.o.
