GARDENA
D
Betriebsanleitung
Teichschlammsauger-Set / Teichschlammsauger-Vorsatz
GB
Operating Instructions
Pond Silt Remover Set / Pond Silt Remover Adapter
F
Mode d'emploi
Aspirateur de bassin – kit complet
NL
Instructies voor gebruik
Vijvervuilzuigerset / Vijvervuilzuiger-voorzetunit
S
Bruksanvisning
Slamsugarset för Damm / Slamsugardelar
I
Istruzioni per l'uso
Set pulitore per laghetti / Aspiratore per laghetti
E
Manual de instrucciones
Set de aspiración de lodos para estanque / Adaptador
P
Instruções de utilização
Conjunto de aspirador de limpeza para lago e bomba
DK
Brugsanvisning
Bassinstøvsuger komplet / Adapter
®
Art. 7940
Art. 7941
Advertisement
Table of Contents
Related Manuals for Gardena 7940
Summary of Contents for Gardena 7940
- Page 1 ® GARDENA Art. 7940 Art. 7941 Betriebsanleitung Teichschlammsauger-Set / Teichschlammsauger-Vorsatz Operating Instructions Pond Silt Remover Set / Pond Silt Remover Adapter Mode d’emploi Aspirateur de bassin – kit complet Instructies voor gebruik Vijvervuilzuigerset / Vijvervuilzuiger-voorzetunit Bruksanvisning Slamsugarset för Damm / Slamsugardelar Istruzioni per l’uso...
-
Page 2: Table Of Contents
The Pond Silt Remover can also be used to remove large particles of dirt from swimming pools. Attention The GARDENA Pond Silt Remover is not suitable for continuous use (e.g. industrial use, continuous suction). 2. Safety instructions V Please read the pump operating instructions carefully and observe the notes on safety. -
Page 3: Function
3. Function Suction unit (grey) " Pump § Motive water hose (red) Nozzle housing Filter trough & Dirty water float hose " § (transparent) & Adapter nozzles – for cleaning surfaces – for narrow places " The pump draws in the pond water via the suction unit Collecting basket §... -
Page 4: Assembly
4. Assembly Attach the filter trough : 1. Pull the side clips slightly away from the filter trough and remove the splashguard 2. Insert the filter sieves into the filter trough with the ridges facing downwards. 3. Install the collecting basket in the filter trough 4. -
Page 5: Before And During Operation
Attach the handle (only for set 7940) : 1. Push the 4 tubes and the tube with the locking screw into the connecting sleeves so that the holes are in alignment. 2. Fasten the connecting sleeves to the tubes with 2 screws each. - Page 6 Adjust the working angle to suit the pond you are working on. 8. Fill the GARDENA Garden Pump Art. 1426 provided in the Pond Silt Remover Set with 2 litres of water. (Operate other pumps according to their operating instructions.) 9.
-
Page 7: Cleaning
6. Cleaning Clean all dirty parts after use. Clean the dirty water hose : v Switch on the pump and hold the nozzle housing closed with your hand. The motive water is then directed into the dirty water hose and cleans it from the inside. v Remove silt from the outside of the dirty water hose rinse under running water. -
Page 8: Accessories
The collecting bag is full. v Empty the collecting bag. Pump is not working. Pump is defective. v See pump operating instructions. If other faults occur, please contact GARDENA Customer Service. 8. Accessories Recommended Accessories : GARDENA combisystem For reaching distances of Telescopic Handles up to 3.90 m... -
Page 9: Service
If you have any problems with your Pond Silt Remover Set, please contact our Customer Service or return the defective unit together with a short description of the problem directly to one of the GARDENA Service Centres listed on the back of this leaflet. Product Liability... - Page 10 DL5 6UP 1540 Vestby Turkey info.gardena husqvarna.co.uk info gardena.no Bulgaria GARDENA / Dost Diþ Ticaret Хускварна България ЕООД Greece Poland Mümessillik A.Þ. Sanayi 1799 София Agrokip GARDENA Polska Sp. z o.o. Çad. Adil Sokak No. 1 Бул. „Андрей Ляпчев” N º 72 Psomadopoulos S.A.
