Musical Fidelity V-LPSII Instructions

V-LPS
II
Instructions
Connections
All connections must be made before the
mains adaptor is plugged in, and before any
amplifier connected is switched on. Always
switch off the equipment attached to the V-
LPS before connecting/disconnecting
II
power, changing leads or inputs.
Inputs
Using good quality RCA leads
supplied), connect the left and right turntable
outputs to the correct V-LPS INPUT
II
sockets.
Use the phono MM input for moving magnet
cartridges. Make sure MM/MC switch is
OUT.
Use the phono MC input for moving coil
cartridges. Make sure MM/MC switch is IN.
An earthing terminal is provided. Connect
earth wire from turntable to this terminal if
hum is apparent. Other setups may work fine
with this terminal left disconnected and no
harm is done in doing so.
Phono Stage
Outputs
Connect the V-LPS left
II
OUTPUTS to the desired LINE LEVEL (e.g
AUX) inputs of the amplifier system.
Power
Plug the DC connector lead from the power
supply unit into the V-LPS power inlet
II
socket, and plug the adaptor itself into a
(not convenient wall mains outlet. The blue LED
will light to confirm the unit is ready for use.
Use
Turn the volume on amplifier to normal
listening levels, sit back and enjoy the music.
These products have been designed so that
it may be left on indefinitely, but please note
that the mains adapter may become warm to
the touch - this is normal.
Introduction
Thank you for purchasing the V-LPS
sincerely hope that it will bring you many
years of outstanding listening pleasure.
Installation Precautions
Your new V-LPS
II
provide trouble-free performance, but as with
all electronic devices, it is necessary to
observe a few precautions:
Do not use the V-LPS
must not be exposed to dripping or splashing
and no objects filled with liquids, such as
vases, must be placed on the unit.
Keep the V-LPS
II
radiators. No naked flame sources, such as
lighted candles, should be placed on the
unit.
Power Supply Note:
Only use approved
power supply. The use of other adaptors or
supplies could seriously damage the V-LPS
.
and right
Moving magnet (MM)/moving coil (MC) input select switch
Left (white) & right (red) RCA moving coil (MC) inputs
Left (white) & right (red) RCA moving magnet (MM) inputs
This Hi-fi product has been tested to ensure
. We
II
that its operation is not adversely affected by
normal background
Frequency Interference (R.F.I.), and that it
does not itself generate excessive amounts
is designed and built to of interference. However, if a problem
persists, please contact your Musical Fidelity
agent.
Never open the case of the V-LPS
as this will invalidate the guarantee.
near water. The unit
II
Place all connecting cables where they are
not likely to be walked on or trapped by
items placed on them.
away from heat such as The V-LPS
II
its specifications
environmental range:
Temperature 5 to 45 degrees Celsius
Humidity 10 to 90% non condensing
Musical Fidelity
DC
There are no user adjustments inside.
Please refer
II
authorised Musical Fidelity agent.
Front and back connections
Power input socket
4mm earth terminal
Power LED
Left (white) & right (red) RCA line outputs
levels of Radio
yourself,
II
will operate in accordance with
within the following
all service work to an
