Remote Management Frontend
3.2.2 Starting Remote Management Frontend via an
RSB/ RSB S2/ RSB S2 LP(3HU) or a BMC
Proceed as follows:
Ê In the ServerList window (see
server which you want to manage with the Remote Management Frontend:
– If the server can be managed via the Operations Manager (e.g. status
icon ), then the ServerView [server-name] window opens (see
the Remote Management Frontend for manageable servers" on
page 26).
– If the server cannot be managed via the Operations Manager but can be
accessed via the secondary channel (RSB mode or BMC mode, status
icon ), then the Remote Management view is opened (see
Remote Management Frontend for servers in RSB mode/BMC mode" on
page 29.)
Example:
Figure 7: Operations Manager: "Server List" window (server can be managed / cannot
be managed)
ServerView Remote Management Frontend
... starting via the Operations Manager
figure 2 on page 19), click the name of the
...
...
"Starting
"Starting the
