- Page 1 USER’S MANUAL L42H761 Thank you very much for choosing the AOC Envision Series LCD TV. We recommend that you take a few minutes to read carefully through this manual before installing and using the TV. Please keep this manual in a safe place for your future reference.
-
Page 2: Table Of Contents
USER’S MANUAL TABLE OF CONTENTS FOR YOUR SAFETY ------------------------------------------------------ 1 DECLARATION OF RoHs COMPLIANCE --------------------------- 3 PRECAUTIONS AND REMINDERS ----------------------------------- 4 IMPORTANT SAFETY INSTRUCTIONS ----------------------------- 6 MOUNTING THE TV BASE---------------------------------------------- PREPARATION ------------------------------------------------------------- 9 TO USE THE REMOTE CONTROL -----------------------------------11 Peripheral Connection Guide -----------------------------------------------------------13 To use the menus--------------------------------------------------------------------------15 TV menu-Installation ----------------------------------------------------------------------16 TV menu-Features ------------------------------------------------------------------------19... -
Page 3: For Your Safety
FOR YOUR SAFETY Before operating the TV please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Symbol Definition
SYMBOL DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons. SA 1965 INSTRUCTIONS: The exclamation point within on equilateral triangle to alert the User to the presence of important operating... -
Page 5: Declaration Of Rohs Compliance
DECLARATION OF RoHs COMPLIANCE This product has been designed and manufactured in compliance with Directive 2002/95/ EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance... -
Page 6: Precautions And Reminders
PRECAUTIONS AND REMINDERS Place unit on even surfaces. Unplug immediately if is malfunction like no picture, no video/audio,smoke and bad odor from TV. Don’t throw any object inside the TV box like metals or other flammable materials. Don’t place the TV in confined spaces or in a box when using it. - Page 7 Remember to unplug the AC cord from the AC outlet before cleaning. Do not use liquid cleaners or aerosol cleaners to clean the display. Make sure to unplug the unit when not in use for a long period of time (days). Do not cover or block any vents and openings.
-
Page 8: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. - Page 9 Tilt/Stability – All televisions must comply with recommended international global safety standards for tilt and stability properties of its cabinets design. Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet, which could ultimately overturn the product. Also, do not endanger yourself, or children, by placing electronic equipment/toys on the top of the cabinet.
-
Page 10: Mounting The Tv Base
MOUNTING THE TV BASE The TV base will be separated with the TV unit. You should Install the base before you use the TV unit. 1. Place the TV on its face on a soft blanket. 2. Install the base stand with three screws. 3. -
Page 11: Preparation
PREPARATION Please, make sure to connect the power plug to the wall outlet socket after connecting the TV to the power cord! 1. Install the base stand; place the TV on a solid surface. Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover. - Page 12 Remote control: Remove the cover of the battery compartment. Insert the 2 batteries supplied (Type AA 1.5V). Power: Insert the power cord in the wall socket having an AC power supply. You can see LED states at the front panel. If the LED color is Green, means the TV set is power on. If the LED color is Orange, which means this TV set is in standby state.
-
Page 13: To Use The Remote Control
TO USE THE REMOTE CONTROL POWER Press to power ON/OFF (standby) TV.(Note:1.TV is never completely power off. unless physically unplugged. 2.Press to turn on TV after the power on status LED had changed to the amber color and stopped flashing. ) VIDEO Press repeatedly to choose S-Video/ Composite source mode (Video... - Page 14 WIDE Press this button to display a list of available display for- mats. Available display formats are determined by the type of signal you are receiving. To choose the display format you prefer, press the WIDE button repeatedly: Automatic, Super Zoom, 4:3, Movie expand 14:9, Movie expand 16:9, 16:9 subtitle and widescreen.
-
Page 15: Peripheral Connection Guide
PERIPHERAL CONNECTION GUIDE AC POWER POWER HDMI 2 HDMI 1 RS-232 Line In Headphone HDMI S-Video PC L/R Once your equipment is connected, use the following procedure to view the input signal: Press the source button on the remote controller to select the relevant source to view. (ex: Press VIDEO button to select “Composite Rear”... -
Page 16: Operation Instructions
CAMERA CAMCORDER VIDEO GAME How to connect 1. Connect the camera, camcorder and game set to the ports of the audio/video set. 2. The camcorder may get better picture by connecting a S-VHS cable between the S terminal and the Audio set. How to use it 1. -
Page 17: To Use The Menus
To use the menus Introduction When you use a menu or take an action, convenient instructions, help texts and messages will be displayed on your TV. Please, follow the displayed instructions and read the help text on the specific item high- lighted. -
Page 18: Tv Menu-Installation
TV menu-Installation Settings Installation Language Language English Autoprogram Français Source Español Clock Current software info Reset AV settings Press the cursor right select your menu language. Settings Installation Autoprogram Cable Antenna Cable Start now Television installation You can now start automatic installation. This proceclure can take more than half an hour. -
Page 19: Weak Channel Installation
Note: Digital Channel selection delay Due to the tuning complexity of subchannel digital programming, the time to select and view a digital chan- nel may take slightly longer than what the viewer is normally accustomed to (as compared to analog channel programs). -
Page 20: Digital Audio Out
Settings Installation Source Language Autoprogram Component1 Source Component2 Clock Weak channel installation HDMI1 Current software info HDMI2 Reset AV settings Here you can select the accessory devices you have connected to the external inputs/outputs. HDMI2 HDMI1 VIDEO PC IN S-VIDEO HDMI AV3: Audio L/R... -
Page 21: Tv Menu-Features
TV menu-Features Settings Features Picture Closed captions Caption service Sound Features Digital caption service Digital caption options Parental Control Preferred channels Installation Exit Sleeptimer The features menu gives you control over special. additional functions. Settings Features Closed captions Closed captions Caption service Digital caption service On during mute... -
Page 22: Digital Caption Service
Settings Features Digital caption serv Closed captions CS-1 Caption service CS-2 Digital caption service CS-3 Digital caption options CS-4 Preferred channels CS-5 Sleeptimer CS-6 This allows you to select one of the digital service channel made available by the individual caption provider. Settings Features Digital caption options... -
Page 23: Preferred Channels
Settings Features Preferred channels Closed captions Caption service Digital caption service Digital caption options Preferred channels Sleeptimer You can browse through the TV channels with the -P+button. Only those channels which are in the preferred list, will be displayed. Settings Features Sleeptimer Closed captions... -
Page 24: Tv Menu-Picture & Sound
TV menu-Picture & Sound Settings Picture Picture Smart picture Sound Contrast Brightness Features Color Parental Control Installation Sharpness Exit Color temperature Tint Noise reduction The picture menu contains the settings that affect the quality of the picture. Settings Picture Smart Picture Smart picture Personal Contrast... -
Page 25: Color Temperature
Settings Sound Picture Smart sound Sound Sound mode Features Alternate audio Parental Control Digital audio language Installation Exit The sound menu contains the settings that affect the reproduction of the sound. Settings Sound Smart sound Smart sound Personal Speech Sound mode Alternate audio Movies Digital audio language... -
Page 26: Sound Mode
Settings Sound Sound mode Smart sound Mono Sound mode Stereo Alternate audio Virtual Surround Digital audio language This selects the modes for more spatial or surround sound reproduction. Settings Sound Alternate audio Smart sound Main Sound mode Alternate audio Digital audio language This gives you the possibility to swap tetween the Main and Second Audio program(SAP) when it is available. -
Page 27: Tv Menu-Parental Control
TV menu-Parental Control Settings Parental Control Picture Channel lock Sound TV ratings lock Features Movie ratings lock Region ratings lock Parental Control Installation Clear regions lock Exit Change PIN This menu can control special functions for the TV channels. Settings Parental control Channel lock Channel lock... - Page 28 Age-based Content-based Rating Rating none None none TV-Y none TV-Y7 (FV) Fantasy Violence TV-G none TV-PG (D) Dialog (L) Language (S) Sex (V) Violence TV-14 (D) Dialog (L) Language (S) Sex (V) Violence TV-MA (L) Language (S) Sex (V) Violence When All has been selected, all items in the age-based and in the contents-based lists are locked.
- Page 29 Settings Parental control Movie ratings Channel lock TV ratings lock Movie ratings lock Region ratings lock Clear regions lock PG-13 Change PIN NC-17 This allows you to limit access to individual programs based on their MPAA ratings. Movie Ratings Lock This function allows you to control access to individual movies based on their MPAA ratings (Motion Picture As- sociation of America).
-
Page 30: Region Ratings Lock
Settings Parental control Region ratings lock EntireAudience EntireAudience None Dialogue TV-G Language TV-PG TV-14 Violence TV-MA Children FantasyViolence MPAA This allows you to control access to individual programs based on their broadcasted regional rating. Settings Parental control Clear regions lock Channel lock TV ratings lock Start now... -
Page 31: Pc Menu-Installation
PC menu-Installation Settings Installation Language Language English Français Source Picture adjustment Español Factory reset Select your menu language with the cursor up/down. Press the OK key on the remote control to confirm. Settings Installation Source Language Source Component1 Picture adjustment Component2 Factory reset HDMI1... -
Page 32: Pc Menu-Picture
PC menu-Picture Settings Picture Picture Contrast Sound Brightness Installation Color temperature Exit Picture format The picture menu contains the settings that affect the quality of the picture. Settings Picture Color temperature Contrast Normal Brightness Warm Color temperature Cool Picture format Easy selection of uptimized predefined picture settings.The TV will return to the last selected setting after start-up. -
Page 33: Pc Menu-Sound
PC menu-Sound Settings Sound Picture Smart sound Sound Virtual surround Installation Exit The sound menu contains the settings that affect the reproduction of the sound. Settings Sound Smart sound Smart sound Personal Virtual surround Speech Movies This gives you the possibility to select the preferred sound trequencies which correspond with your personal sound settings. -
Page 34: Care Of The Screen
TIPS Care of the screen Do not rub or strike the screen with anything hard as this may scratch, mar, or damage the screen permanently. Unplug the power socket before cleaning the screen. Dust the TV by wiping the screen and the cabinet with a soft, clean cloth. -
Page 35: Before Calling Service
BEFORE CALLING SERVICE Please make these simple checks before calling service. These tips may save you time and money since charges for receiver installation and adjustments of customer controls are not covered under your warranty. Symptoms “Ghost ” or double image No power No picture Good picture but no sound... -
Page 36: Glossary
GLOSSARY Audio / Video Inputs Located on the rear and the front of the receiver these connectors (RCA phono type plug) are used for the input of audio and video signals. Designed for use with VCRs (or other accessories) in order to receive higher picture resolution and offer sound connection options. -
Page 37: Product Specification
PRODUCT SPECIFICATION 42” Wide screen Full HD (1920x 1080) Resolution High Brightness (500 cd/m2) High Contrast Ratio (1500:1) Feature Wide Viewing Angle (176 H / 176 V) Analog TV: Built-in 181 channel Tuner with MTS, SAP, Closed Caption & V-chip Digital TV: ATSC 8-VSB Items LCD Panel...
